基于浮游植物吸收系数和光合有效辐射的南海区域性分粒级初级生产力算法初探

doi:10.11978/2022019

热带海洋学报 ›› 2023, Vol. 42 ›› Issue (1): 43-55.doi: 10.11978/2022019CSTR: 32234.14.2022019

基于浮游植物吸收系数和光合有效辐射的南海区域性分粒级初级生产力算法初探

赵红五一¹^,²(), 周雯¹^,³(), 曾凯¹^,², 邓霖⁴, 廖健祖⁵, 曹文熙¹^,³()

1.中国科学院南海海洋研究所, 热带海洋学国家重点实验室, 广东广州 510301
2.中国科学院大学地球与行星科学学院, 北京 100049
3.南方海洋科学与工程广东省实验室(广州), 广东广州 511458
4.中山大学海洋科学学院, 广东广州 510275
5.广东海洋大学化学与环境学院, 广东湛江 524088

收稿日期:2022-01-29 修回日期:2022-05-29 出版日期:2023-01-10 发布日期:2022-05-31
通讯作者: 周雯, email: wenzhou@scsio.ac.cn;曹文熙, wxcao@scsio.ac.cn
作者简介:
赵红五一(1996—), 女, 硕士研究生, 从事海洋光学遥感研究。email: liuliujiangzhao@gmail.com
基金资助:
南方海洋科学与工程广东省实验室(广州)重大专项创新团队项目(GML2019ZD0305); 南方海洋科学与工程广东省实验室(广州)重大专项创新团队项目(GML2019ZD0602); 国家自然科学基金(41976170); 国家自然科学基金(41976172); 国家自然科学基金(42276181); 国家自然科学基金(41976181)

A study of the regional size-fractionated primary production algorithm based on phytoplankton absorption coefficient and photosynthetically active radiation in the South China Sea

ZHAO Hongwuyi¹^,²(), ZHOU Wen¹^,³(), ZENG Kai¹^,², DENG Lin⁴, LIAO Jianzu⁵, CAO Wenxi¹^,³()

1. State Key Laboratory of Tropical Oceanography, South China Sea Institute of Oceanology, Chinese Academy of Sciences, Guangzhou 510301, China
2. College of Earth and Planetary Sciences, University of Chinese Academy of Sciences, Beijing 100049, China
3. Southern Marine Science and Engineering Guangdong Laboratory (Guangzhou), Guangzhou 511458, China
4. School of Marine Sciences, Sun Yat-sen University, Guangzhou 519082, China
5. School of Chemistry and Environmental Sciences, Guangdong Ocean University, Zhanjiang 524088, China

Received:2022-01-29 Revised:2022-05-29 Online:2023-01-10 Published:2022-05-31
Contact: ZHOU Wen, email: wenzhou@scsio.ac.cn;CAO Wenxi, wxcao@scsio.ac.cn
Supported by:
Major Special Innovation Team Project of Guangdong Provincial Laboratory of Southern Ocean Science and Engineering(Guangzhou)(GML2019ZD0305); Major Special Innovation Team Project of Guangdong Provincial Laboratory of Southern Ocean Science and Engineering(Guangzhou)(GML2019ZD0602); National Natural Science Foundation of China(41976170); National Natural Science Foundation of China(41976172); National Natural Science Foundation of China(42276181); National Natural Science Foundation of China(41976181)

摘要/Abstract

摘要：

海洋初级生产过程是海洋碳循环的重要组成部分, 影响生物地球化学循环和全球气候变化。浮游植物作为海洋初级生产的主要贡献者, 按粒径大小可分为小型(micro粒级, >20μm)、微型(nano粒级, 2~20μm)和微微型(pico粒级, <2μm)。不同粒级浮游植物初级生产力(size-fractionated primary production, PP_size)对总初级生产力贡献不同, 在海洋物质能量流动及碳循环中扮演着不同角色。本文基于2019年南海西部夏季航次12个站位的生物光学剖面数据, 研究了南海西部分粒级浮游植物叶绿素a浓度和初级生产力的空间分布及它们对总叶绿素a浓度和总初级生产力的贡献百分比。利用各粒级670nm波段的浮游植物吸收系数[size-fractionated phytoplankton absorption coefficient at 670nm, a_ph-size(670)]与光合有效辐射(photosynthetically active radiation, PAR)的乘积[a_ph-size(670)×PAR]建立了南海分粒级初级生产力算法, 对于小型、微型和微微型浮游植物数据集, log[a_ph-size(670)×PAR]与log(PP_size)之间的决定系数R²分别为0.64、0.76和0.67。交叉验证的结果表明, 该算法具有良好的泛化性能。其性能显著优于仅利用浮游植物吸收系数估算分粒级初级生产力的算法, 表明PAR是影响分粒级初级生产力变化的重要因素之一。采用基于叶绿素a浓度的算法估算各粒级初级生产力时, 针对小型和微微型浮游植物数据集, 该算法的性能与本文构建的算法近似; 但针对微型浮游植物数据集时, 基于叶绿素a浓度的算法性能显著较低, 这可能归因于微型浮游植物吸收系数与叶绿素a浓度间的弱相关性。

关键词: 分粒级浮游植物吸收系数, 分粒级浮游植物初级生产力, 光合有效辐射, 分粒级叶绿素a

Abstract:

Marine primary production is an important part of the ocean carbon cycle, affecting biogeochemical cycles and global climate change. Phytoplankton, as the main contributor to marine primary production, can be classified as micro- (>20μm), nano- (2~20μm), and pico- (<2μm) phytoplankton depending on particle size. Different phytoplankton size classes contribute differently to primary production (PP_size) and thus play different roles in the oceanic circulation of matter or energy and ocean carbon cycle. Based on the bio-optical dataset collected at 12 stations in the western South China Sea in 2019, this study presented the spatial variability of size-fractionated primary production and chlorophyll a concentration of phytoplankton and their percentage contribution. The size-fractionated primary productivity of phytoplankton was well estimated from the product of size-fractionated phytoplankton absorption coefficient at 670nm [a_ph-size(670)] and photosynthetically active radiation (PAR) [a_ph-size(670)×PAR]. The coefficients of determination R² between log[a_ph-size(670)×PAR] and log(PP_size) were 0.64, 0.76, and 0.67 for the micro-, nano-, and pico-phytoplankton dataset, respectively. The cross-validation of the algorithm based on the size-fractionated phytoplankton absorption coefficient and PAR has shown a good generalization performance. This algorithm could better predict the size-fractionated primary productivity compared to the size-fractionated phytoplankton absorption coefficient as the only input. This result indicates that PAR is one of the important factors to estimate the size-fractionated primary productivity. Meanwhile, the performance of the chlorophyll a concentration-based algorithm for estimating primary productivity at each size was closer to that of the algorithm constructed in this paper for both micro- and pico- phytoplankton dataset, but significantly lower for the nano-phytoplankton, probably due to the weak correlation between the absorption coefficients and chlorophyll a concentration of nano-phytoplankton.

Key words: size-fractionated phytoplankton absorption coefficient, size-fractionated primary production, photosynthetically active radiation, size-fractionated chlorophyll a

赵红五一, 周雯, 曾凯, 邓霖, 廖健祖, 曹文熙. 基于浮游植物吸收系数和光合有效辐射的南海区域性分粒级初级生产力算法初探[J]. 热带海洋学报, 2023, 42(1): 43-55.

ZHAO Hongwuyi, ZHOU Wen, ZENG Kai, DENG Lin, LIAO Jianzu, CAO Wenxi. A study of the regional size-fractionated primary production algorithm based on phytoplankton absorption coefficient and photosynthetically active radiation in the South China Sea[J]. Journal of Tropical Oceanography, 2023, 42(1): 43-55.

图/表 11

表1

图1

表2

图2

表3

图3

图4

图 5

图6

表 4

图7

参考文献 68

[1]	傅明珠, 王宗灵, 李艳, 等, 2009. 胶州湾浮游植物初级生产力粒级结构及固碳能力研究[J]. 海洋科学进展, 27(3): 357-366.
	FU MINGZHU, WANG ZONGLING, LI YAN, et al, 2009. Study on size-fraction and carbon fixation of phytoplankton primary productivity in Jiaozhou Bay[J]. Advances in Marine Science, 27(3): 357-366. (in Chinese with English abstract)
[2]	龚祝清, 2020. 北部湾近岸海洋初级生产力遥感估算研究[D]. 南宁: 广西大学.
	GONG ZHUQING, 2020. Study of remote sensing estimation of primary productivity in coastal marine waters of Beibu Gulf[D]. Nanning: Guangxi University. (in Chinese with English abstract)
[3]	黄邦钦, 洪华生, 柯林, 等, 2005. 珠江口分粒级叶绿素a和初级生产力研究[J]. 海洋学报, 27(6): 180-186.
	HUANG BANGQIN, HONG HUASHENG, KE LIN, et al, 2005. Size-fractionated phytoplankton biomass and productivity in the Zhujiang River Estuary in China[J]. Acta Oceanologica Sinica, 27(6): 180-186. (in Chinese with English abstract)
[4]	金松, 韩震, 李雪娜, 等, 2017. 叶绿素浓度和海表温度与黄海绿潮海洋初级生产力关系的研究[J]. 海洋湖沼通报, 39(3): 131-138.
	JIN SONG, HAN ZHEN, LI XUENA, et al, 2017. Preliminary studies on the relationship between chlorophyll a, sea surface temperature and primary productivity of Yellow Sea green tide[J]. Transactions of Oceanology and Limnology, 39(3): 131-138. (in Chinese with English abstract)
[5]	孙强, 洪娅岚, 鹿凤, 2019. 珠江口邻域海洋初级生产力与人类活动相关性研究[J]. 科技创新与生产力, (3): 12-15.
	SUN QIANG, HONG YALAN, LU FENG, 2019. A study on the correlation between the marine primary productivity of Pearl River Estuary and human activities[J]. Sci-tech Innovation and Productivity, (3): 12-15. (in Chinese with English abstract)
[6]	唐世林, 陈楚群, 詹海刚, 2006. 海洋初级生产力的遥感研究进展[J]. 台湾海峡, 25(4): 591-598.
	TANG SHILIN, CHEN CHUQUN, ZHAN HAIGANG, 2006. Retrieval progress of ocean primary production by remote sensing[J]. Journal of Oceanography in Taiwan Strait, 25(4): 591-598. (in Chinese with English abstract)
[7]	王荣, 焦念志, 李超伦, 等, 1995. 胶州湾的初级生产力和新生产力[J]. 海洋科学集刊, 995(1): 181-194.
	WANG RONG, JIAO NIANZHI, LI CHAOLUN, et al, 1995. Primary production and new production in Jiaozhou Bay[J]. Studia Marina Sinica: 181-194. (in Chinese with English abstract)
[8]	薛冰, 孙军, 李婷婷, 2016. 2014年夏季南海北部浮游植物群落结构[J]. 海洋学报, 38(4): 54-65.
	XUE BING, SUN JUN, LI TINGTING, 2016. Phytoplankton community structure of northern South China Sea in summer of 2014[J]. Haiyang Xuebao, 38(4): 54-65. (in Chinese with English abstract)
[9]	杨威, 董园, 俎婷婷, 等, 2019. 南海北部夏季叶绿素a分布规律及影响因素[J]. 热带海洋学报, 38(6): 9-20. doi: 10.11978/2019018
	YANG WEI, DONG YUAN, ZU TINGTING, et al, 2019. Distribution of Chlorophyll-a and its influencing factors in the northern South China Sea in summer[J]. Journal of Tropical Oceanography, 38(6): 9-20. (in Chinese with English abstract) doi: 10.11978/2019018
[10]	翟红昌, 2010. 基于HPLC技术的南海北部浮游植物色素与群落结构研究[D]. 青岛: 中国海洋大学.
	ZHAI HONGCHANG, 2010. Phytoplankton pigment patterns and community composition in the northern South China Sea determined by HPLC method[D]. Qingdao: Ocean University of China. (in Chinese with English abstract)
[11]	BANNISTER T T, 1974. Production equations in terms of chlorophyll concentration, quantum yield, and upper limit to production[J]. Limnology and Oceanography, 19(1): 1-12. doi: 10.4319/lo.1974.19.1.0001
[12]	BARNES M K, TILSTONE G H, SMYTH T J, et al, 2014. Absorption-based algorithm of primary production for total and size-fractionated phytoplankton in coastal waters[J]. Marine Ecology Progress Series, 504: 73-89. doi: 10.3354/meps10751
[13]	BEHRENFELD M J, FALKOWSKI P G, 1997a. A consumer's guide to phytoplankton primary productivity models[J]. Limnology and Oceanography, 42(7): 1479-1491. doi: 10.4319/lo.1997.42.7.1479
[14]	BEHRENFELD M J, FALKOWSKI P G, 1997b. Photosynthetic rates derived from satellite-based chlorophyll concentration[J]. Limnology and Oceanography, 42(1): 1-20. doi: 10.4319/lo.1997.42.1.0001
[15]	BEHRENFELD M J, BOSS E, SIEGEL D A, et al, 2005. Carbon-based ocean productivity and phytoplankton physiology from space[J]. Global Biogeochemical Cycles, 19(1): GB1006.
[16]	BREWIN R J W, DEVRED E, SATHYENDRANATH S, et al, 2011. Model of phytoplankton absorption based on three size classes[J]. Applied Optics, 50(22): 4535-4549. doi: 10.1364/AO.50.004535
[17]	BREWIN R J W, TILSTONE G H, JACKSON T, et al, 2017. Modelling size-fractionated primary production in the Atlantic Ocean from remote sensing[J]. Progress in Oceanography, 158: 130-149. doi: 10.1016/j.pocean.2017.02.002
[18]	BREWIN R J W, MORÁN X A G, RAITSOS D E, et al, 2019. Factors regulating the relationship between total and size-fractionated chlorophyll-a in coastal waters of the red sea[J]. Frontiers in Microbiology, 10: 1964. doi: 10.3389/fmicb.2019.01964
[19]	BRICAUD A, STRAMSKI D, 1990. Spectral absorption coefficients of living phytoplankton and nonalgal biogenous matter: a comparison between the Peru upwelling areaand the Sargasso Sea[J]. Limnology and Oceanography, 35(3): 562-582. doi: 10.4319/lo.1990.35.3.0562
[20]	BRICAUD A, CLAUSTRE H, RAS J, et al, 2004. Natural variability of phytoplanktonic absorption in oceanic waters: influence of the size structure of algal populations[J]. Journal of Geophysical Research: Oceans, 109(C11): C11010.
[21]	CAI WEIJUN, DAI MINHAN, WANG YONGCHEN, et al, 2004. The biogeochemistry of inorganic carbon and nutrients in the Pearl River estuary and the adjacent Northern South China Sea[J]. Continental Shelf Research, 24(12): 1301-1319. doi: 10.1016/j.csr.2004.04.005
[22]	CAO WENXI, YANG YUEZHONG, LIU SHENG, et al, 2005. Spectral absorption coefficient of phytoplankton and its relation to chlorophyll a and remote sensing reflectance in coastal waters of southern China[J]. Progress in Natural Science, 15(4): 342-350. doi: 10.1080/10020070512331342210
[23]	CHEN YING, ZHAO HUI, 2021. Spatial distribution of the summer subsurface chlorophyll maximum in the North South China Sea[J]. PLoS One, 16(4): e0248715. doi: 10.1371/journal.pone.0248715
[24]	CLAUSTRE H, BABIN M, MERIEN D, et al, 2005. Toward a taxon-specific parameterization of bio-optical models of primary production: a case study in the North Atlantic[J]. Journal of Geophysical Research: Oceans, 110(C7): C07S12.
[25]	CURRAN K, BREWIN R J W, TILSTONE G H, et al, 2018. Estimation of size-fractionated primary production from satellite ocean colour in UK shelf seas[J]. Remote Sensing, 10(9): 1389. doi: 10.3390/rs10091389
[26]	DENG LIN, ZHOU WEN, XU JIE, et al, 2022. Estimation of vertical size-fractionated phytoplankton primary production in the northern South China Sea[J]. Ecological Indicators, 135: 108546. doi: 10.1016/j.ecolind.2022.108546
[27]	FALKOWSKI P G, BARBER R T, SMETACEK V, 1998. Biogeochemical controls and feedbacks on ocean primary production[J]. Science, 281(5374): 200-206. pmid: 9660741
[28]	FRIEDRICHS M A M, CARR M E, BARBER R T, et al, 2009. Assessing the uncertainties of model estimates of primary productivity in the tropical Pacific Ocean[J]. Journal of Marine Systems, 76(1-2): 113-133. doi: 10.1016/j.jmarsys.2008.05.010
[29]	GROB C, HARTMANN M, ZUBKOV M V, et al, 2011. Invariable biomass-specific primary production of taxonomically discrete picoeukaryote groups across the Atlantic Ocean[J]. Environmental Microbiology, 13(12): 3266-3274. doi: 10.1111/j.1462-2920.2011.02586.x pmid: 21951381
[30]	GUIDI L, STEMMANN L, JACKSON G A, et al, 2009. Effects of phytoplankton community on production, size, and export of large aggregates: a world-ocean analysis[J]. Limnology and Oceanography, 54(6): 1951-1963. doi: 10.4319/lo.2009.54.6.1951
[31]	HIRATA T, HARDMAN-MOUNTFORD N J, BARLOW R, et al, 2009. An inherent optical property approach to the estimation of size-specific photosynthetic rates in eastern boundary upwelling zones from satellite ocean colour: an initial assessment[J]. Progress in Oceanography, 83(1-4): 393-397. doi: 10.1016/j.pocean.2009.07.019
[32]	KAHRU M, 2017. Ocean productivity from space: commentary[J]. Global Biogeochemical Cycles, 31(1): 214-216. doi: 10.1002/2016GB005582
[33]	KAMEDA T, ISHIZAKA J, 2005. Size-fractionated primary production estimated by a two-phytoplankton community model applicable to ocean color remote sensing[J]. Journal of Oceanography, 61(4): 663-672. doi: 10.1007/s10872-005-0074-7
[34]	KEENE O N, 1995. The log transformation is special[J]. Statistics in Medicine, 14(8): 811-819. doi: 10.1002/sim.4780140810 pmid: 7644861
[35]	KIEFER D A, MITCHELL B G, 1983. A simple, steady state description of phytoplankton growth based on absorption cross section and quantum efficiency[J]. Limnology and Oceanography, 28(4): 770-776. doi: 10.4319/lo.1983.28.4.0770
[36]	KISHINO M, TAKAHASHI M, OKAMI N, et al, 1985. Estimation of the spectral absorption coefficients of phytoplankton in the sea[J]. Bulletin of Marine Science, 37(2): 634-642.
[37]	KNAP A, MICHAELS A, CLOSE A, et al, 1996. Protocols for the joint global ocean flux study (JGOFS) core measurements[R]. Paris: UNESCO, 1994.
[38]	KULK G, PLATT T, DINGLE J, et al, 2021. Correction: Kulk et al. Primary production, an index of climate change in the ocean: satellite-based estimates over two decades. Remote Sens. 2020, 12, 826[J]. Remote Sensing, 13(17): 3462. doi: 10.3390/rs13173462
[39]	KYEWALYANGA M N, PLATT T, SATHYENDRANATH S, 1997. Estimation of the photosynthetic action spectrum: implication for primary production models[J]. Marine Ecology Progress Series, 146: 207-223. doi: 10.3354/meps146207
[40]	LEE Y J, MATRAI P A, FRIEDRICHS M A M, et al, 2015. An assessment of phytoplankton primary productivity in the Arctic Ocean from satellite ocean color/in situ chlorophyll-a based models[J]. Journal of Geophysical Research: Oceans, 120(9): 6508-6541. doi: 10.1002/jgrc.v120.9
[41]	LI W K W, 1994. Primary production of prochlorophytes, cyanobacteria, and eucaryotic ultraphytoplankton: measurements from flow cytometric sorting[J]. Limnology and Oceanography, 39(1): 169-175. doi: 10.4319/lo.1994.39.1.0169
[42]	LIAO JIANZU, XU JIE, LI RUIHUAN, et al, 2021. Photosynthesis-irradiance response in the eddy dipole in the Western South China Sea[J]. Journal of Geophysical Research: Oceans, 126(5): e2020JC016986.
[43]	MARRA J, TREES C C, O’REILLY J E, 2007. Phytoplankton pigment absorption: a strong predictor of primary productivity in the surface ocean[J]. Deep Sea Research Part I: Oceanographic Research Papers, 54(2): 155-163. doi: 10.1016/j.dsr.2006.12.001
[44]	MOREL A, 1991. Light and marine photosynthesis: a spectral model with geochemical and climatological implications[J]. Progress in Oceanography, 26(3): 263-306. doi: 10.1016/0079-6611(91)90004-6
[45]	MOUW C B, YODER J A, 2005. Primary production calculations in the Mid-Atlantic Bight, including effects of phytoplankton community size structure[J]. Limnology and Oceanography, 50(4): 1232-1243. doi: 10.4319/lo.2005.50.4.1232
[46]	NIELSEN E S, 1952. The use of radio-active carbon (C¹⁴) for measuring organic production in the sea[J]. ICES Journal of Marine Science, 18(2): 117-140. doi: 10.1093/icesjms/18.2.117
[47]	PLATT T, SATHYENDRANATH S, 1988. Oceanic primary production: estimation by remote sensing at local and regional scales[J]. Science, 241(4873): 1613-1620. doi: 10.1126/science.241.4873.1613 pmid: 17820892
[48]	PLATT T, SATHYENDRANATH S, FORGET M H, et al, 2008. Operational estimation of primary production at large geographical scales[J]. Remote Sensing of Environment, 112(8): 3437-3448. doi: 10.1016/j.rse.2007.11.018
[49]	RAVEN J A, 1998. The twelfth tansley lecture. Small is beautiful: the picophytoplankton[J]. Functional Ecology, 12(4): 503-513. doi: 10.1046/j.1365-2435.1998.00233.x
[50]	RYTHER J H, YENTSCH C S, 1957. The estimation of phytoplankton production in the ocean from chlorophyll and light data[J]. Limnology and Oceanography, 2(3): 281-286. doi: 10.1002/lno.1957.2.3.0281
[51]	SATHYENDRANATH S, STUART V, IRWIN B D, et al, 1999. Seasonal variations in bio-optical properties of phytoplankton in the Arabian Sea[J]. Deep Sea Research Part II: Topical Studies in Oceanography, 46(3-4): 633-653. doi: 10.1016/S0967-0645(98)00121-0
[52]	SATHYENDRANATH S, COTA G, STUART V, et al, 2001. Remote sensing of phytoplankton pigments: a comparison of empirical and theoretical approaches[J]. International Journal of Remote Sensing, 22(2-3): 249-273. doi: 10.1080/014311601449925
[53]	SATHYENDRANATH S, AIKEN J, ALVAIN S, et al, 2014. Phytoplankton functional types from space[R]. Dartmouth: International Ocean-Colour Coordinating Group.
[54]	SIEBURTH J M, SMETACEK V, LENZ J, 1978. Pelagic ecosystem structure: heterotrophic compartments of the plankton and their relationship to plankton size fractions[J]. Limnology and Oceanography, 23(6): 1256-1263. doi: 10.4319/lo.1978.23.6.1256
[55]	SILSBE G M, BEHRENFELD M J, HALSEY K H, et al, 2016. The CAFE model: a net production model for global ocean phytoplankton[J]. Global Biogeochemical Cycles, 30(12): 1756-1777. doi: 10.1002/gbc.v30.12
[56]	STRAMSKI D, REYNOLDS R A, KACZMAREK S, et al, 2015. Correction of pathlength amplification in the filter-pad technique for measurements of particulate absorption coefficient in the visible spectral region[J]. Applied Optics, 54(22): 6763-6782. doi: 10.1364/AO.54.006763
[57]	TAO ZUI, WANG YAN, MA SHENG, et al, 2017, A phytoplankton class-specific marine primary productivity model using MODIS data[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 10(12): 5519-5528. doi: 10.1109/JSTARS.4609443
[58]	TREMBLAY J E, LEGENDRE L, 1994. A model for the size-fractionated biomass and production of marine phytoplankton[J]. Limnology and Oceanography, 39(8): 2004-2014. doi: 10.4319/lo.1994.39.8.2004
[59]	UITZ J, CLAUSTRE H, MOREL A, et al, 2006. Vertical distribution of phytoplankton communities in open ocean: an assessment based on surface chlorophyll[J]. Journal of Geophysical Research: Oceans, 111(C8): C08005.
[60]	UITZ J, CLAUSTRE H, GENTILI B, et al, 2010. Phytoplankton class-specific primary production in the world’s oceans: seasonal and interannual variability from satellite observations[J]. Global Biogeochemical Cycles, 24(3): GB3016.
[61]	UITZ J, STRAMSKI D, GENTILI B, et al, 2012. Estimates of phytoplankton class-specific and total primary production in the Mediterranean Sea from satellite ocean color observations[J]. Global Biogeochemical Cycles, 26(2): GB2024.
[62]	VAULOT D, EIKREM W, VIPREY M, et al, 2008. The diversity of small eukaryotic phytoplankton (≤3 μm) in marine ecosystems[J]. FEMS Microbiology Reviews, 32(5): 795-820. doi: 10.1111/j.1574-6976.2008.00121.x
[63]	WESTBERRY T, BEHRENFELD M, SIEGEL D, et al, 2008. Carbon-based primary productivity modeling with vertically resolved photoacclimation[J]. Global Biogeochemical Cycles, 22(2): GB2024.
[64]	XIE YUYUAN, HUANG BANGQIN, LIN LIZHEN, et al, 2015. Photosynthetic parameters in the northern South China Sea in relation to phytoplankton community structure[J]. Journal of Geophysical Research: Oceans, 120(6): 4187-4204. doi: 10.1002/jgrc.v120.6
[65]	XUITZ J U, HUOT Y, BRUYANT F, et al, 2008. Relating phytoplankton photophysiological properties to community structure on large scales[J]. Limnology and Oceanography, 53(2): 614-630. doi: 10.4319/lo.2008.53.2.0614
[66]	YACOBI Y Z, KÖHLER J, LEUNERT F, et al, 2015. Phycocyanin-specific absorption coefficient: eliminating the effect of chlorophylls absorption[J]. Limnology and Oceanography: Methods, 13(4): e10015. doi: 10.1002/lom3.10015
[67]	YENTSCH C S, 1962. Measurement of Visible light absorption by particulate matter in the ocean[J]. Limnology and Oceanography, 7(2): 207-217. doi: 10.4319/lo.1962.7.2.0207
[68]	ZAPATA M, RODRíGUEZ F, GARRIDO J L, 2000. Separation of chlorophylls and carotenoids from marine phytoplankton: a new HPLC method using a reversed phase C₈ column and pyridine-containing mobile phases[J]. Marine Ecology Progress Series, 195: 29-45. doi: 10.3354/meps195029

初级生产力算法类型	公式	参量意义
基于浮游植物叶绿素a浓度	PP=Chl a×Q×R/K	PP为浮游植物初级生产力; Chl a为浮游植物叶绿素a浓度; Q为在光饱和情况下, 单位时间内单位质量叶绿素a同化的碳量; R是相对光合速率, 随海表光照强度变化; K是每米水层消光系数
基于浮游植物吸收系数	PP=ϕ×a_ph×E	PP为浮游植物初级生产力; a_ph为浮游植物吸收系数; ϕ为光合作用光量子产率; E为光照强度
基于浮游植物碳	PP=C×μ×Z_eu×f(I₀)	PP为浮游植物初级生产力; C为浮游植物碳; μ为生长速率; Z_eu为真光层深度; f(I₀)是表面光强的函数, 描述了固碳速率的剖面分布

	PAR衰减百分比	近岸珠江口海域						外海海域
		micro占比/%		nano占比/%		pico占比/%		micro占比/%		nano占比/%		pico占比/%
		均值±$\sigma$	范围	均值±$\sigma$	范围	均值±$\sigma$	范围	均值±$\sigma$	范围	均值±$\sigma$	范围	均值±$\sigma$	范围
初级生产力	0%	36±2	19~51	31±0.4	20~42	33±1	18~52	6±0.05	2~8	28±0.6	23~41	67±0.7	54~74
	44%	21±0.4	15~28	30±2	16~37	49±3	35~69	3±0.006	2~4	20±0.2	14~28	77±0.3	68~83
	78%	25±3	3~38	25±1	11~39	50±5	22~86	3±0.01	1~5	15±0.1	13~21	82±0.1	76~84
	93%	16±2	2~36	20±1	9~33	63±6	31~89	18±2	2~41	22±2	8~40	60±9	19~90
	99%	21±1	9~42	30±1	19~48	48±1	38~69	18±1	9~38	27±2	15~50	55±5	29~75
叶绿素a	0%	74±1	58~88	11±0.1	7~16	16±0.8	5~28	11±0.03	8~13	23±0.2	18~28	66±0.4	60~73
	44%	57±2	50~71	16±0.2	12~20	26±0.7	17~33	10±0.008	9~11	23±0.06	20~26	67±0.1	63~71
	78%	55±1	17~84	18±0.9	7~30	27±3	9~54	11±0.02	9~12	24±0.03	23~26	65±0.1	62~69
	93%	53±10	13~92	21±2	1~42	26±3	7~45	32±4	17~64	31±0.2	22~34	37±3	14~50
	99%	57±7	28~91	19±2	2~34	24±3	6~47	39±3	19~61	29±0.2	23~34	32±2	16~50

参与建模的波段	回归参数和评价指标	micro	nano	pico
443nm	$\quad\textit{R}^2_{443}$	0.57	0.72	0.66
	k₄₄₃	0.69	0.56	0.59
	b₄₄₃	-2.8	-3.1	-3.0
670nm	$\quad\textit{R}^2_{670}$	0.64	0.76	0.67
	k₆₇₀	0.72	0.57	0.60
	b₆₇₀	-2.4	-2.8	-2.6
线性拟合最高R²及对应的k、b	$\quad\textit{R}^2_{max}$	0.65(667nm)	0.78(688nm)	0.68(684nm)
	k_max	0.73(667nm)	0.59(688nm)	0.58(684nm)
	b_max	-2.4(667nm)	-2.6(688nm)	-2.6(684nm)

基于浮游植物吸收系数和光合有效辐射的南海区域性分粒级初级生产力算法初探

A study of the regional size-fractionated primary production algorithm based on phytoplankton absorption coefficient and photosynthetically active radiation in the South China Sea

RichHTML

PDF (PC)

赞

可视化

摘要/Abstract

引用本文

使用本文

图/表 11

参考文献 68

相关文章 2

Metrics

本文评价

推荐阅读 0

算法	micro			nano			pico
算法	R²	RMSE	N	R²	RMSE	N	R²	RMSE	N
$\log(\mathrm{PP})=k\log\left[a_{\mathrm{bh}}(\lambda_0)\times\mathrm{PAR}\right]+b$	0.64	0.61	25	0.76	0.43	28	0.67	0.42	47
$\log(\mathrm{PP})=k\log\left[a_{\mathrm{bh}}(\lambda_0)\times\mathrm{PAR}\right]+b$	0.54	0.69	25	0.58	0.56	28	0.14	0.67	47
$\log(\mathrm{PP}_2)=k_2\log(\mathrm{Chl}a\times\mathrm{PAR})+b_2$	0.69	0.56	25	0.50	0.61	28	0.65	0.43	47
