南海东北部夏季叶绿素a浓度垂向变化特征及其对水动力过程的响应*

doi:10.11978/2017121

热带海洋学报 ›› 2018, Vol. 37 ›› Issue (5): 62-73.doi: 10.11978/2017121

所属专题：南海专题

南海东北部夏季叶绿素a浓度垂向变化特征及其对水动力过程的响应^*

徐文龙^1,²(), 王桂芬^1,³(), 周雯¹, 许占堂¹, 曹文熙¹

1. 热带海洋环境国家重点实验室(中国科学院南海海洋研究所), 广东广州 510301
2. 中国科学院大学, 北京100049
3. 河海大学海洋学院, 江苏南京 210098;

收稿日期:2017-11-10 修回日期:2018-03-07 出版日期:2018-09-20 发布日期:2018-10-13
作者简介:
作者简介: 徐文龙(1991—), 男, 山东省枣庄市人, 硕士研究生, 主要从事海洋光学研究。E-mail: wenlongxu@scsio.ac.cn
基金资助:
国家自然科学基金(41776045、41376042、41576030、41776044);热带海洋环境国家重点实验室自主研究项目(LTOZZ1602)

Vertical variability of chlorophyll a concentration and its responses to hydrodynamic processes in the northeastern South China Sea in summer

Wenlong XU^1,²(), Guifen WANG^1,³(), Wen ZHOU¹, Zhantang XU¹, Wenxi CAO¹

1. State Key Laboratory of Tropical Oceanography (South China Sea Institute of Oceanology, Chinese Academy of Sciences), Guangzhou 510301, China
2. University of Chinese Academy of Sciences, Beijing 100049, China
3. College of Oceanography, Hohai University, Nanjing 210098, China;

Received:2017-11-10 Revised:2018-03-07 Online:2018-09-20 Published:2018-10-13
Supported by:
National Natural Science Foundation of China (41776045, 41376042, 41576030, 41776044);Open Project Program of the State Key Laboratory of Tropical Oceanography (South China Sea Institute of Oceanology, Chinese Academy of Sciences) (LTOZZ1602)

摘要/Abstract

摘要：

叶绿素a浓度是估算海洋初级生产力的一个重要参数, 在海洋中垂向分布极不均匀, 其分布特征及影响机制是海洋生态学研究的重要基础问题。利用海洋光学观测的高垂向分辨率剖面数据, 系统地研究叶绿素a浓度垂向剖面的时空分布特征及其与海洋动力环境要素的关系, 可为揭示南海典型动力过程的生态环境效应提供重要基础。文章基于2015年夏季黑潮调查航次实测生物光学剖面, 利用676nm处吸收基线高度(a_LH(676))与叶绿素a浓度(Chla)之间的关系, 建立了具有较高反演精度的叶绿素a浓度反演算法(Chla=49.96×(a_LH(676))^0.9339, 决定系数R²=0.87和均方根误差RMSE=0.16mg·m^-3); 进一步结合观测期间物理过程, 揭示了叶绿素垂向分布对不同水动力过程的响应特征。研究结果表明, 近岸区域表层叶绿素a浓度变化范围为0.42~1.57mg·m^-3, 随着水深增加, 叶绿素a浓度逐渐降低, 在沿岸上升流影响区域, 叶绿素a浓度明显增高, 垂向上相对趋于均一分布; 次表层叶绿素极大值(Subsurface Chlorophyll Maximum, SCM)现象在外海显著存在, 受中尺度过程影响明显, SCM深度在34m到100m之间变化, 在吕宋岛以西海域, 黑潮入侵加速了上层水体的混合, SCM所在水层被显著抬升至34m左右; 在冷涡影响区域, 次表层叶绿素极大值层被抬升, 涡旋中心比涡旋边缘抬升更为显著, 同时SCM的厚度增大。

关键词: 南海东北部, 叶绿素a垂向变化, 次表层叶绿素极大值, 吸收基线高度, 水动力过程

Abstract:

Chlorophyll a (Chla) concentration is an important indicator of phytoplankton biomass for estimating primary production, which exhibits inhomogeneous vertical distribution. In this study, optical measurements with high vertical resolution were used for studying the spatio-temporal variability of Chla profiles and its influencing mechanism, providing us much insights for understanding marine environmental dynamics in the South China Sea. In this study, an optical inversion method was proposed to retrieve Chla profiles from in situ measurements with high-spectral absorption/attenuation spectrophotometer in the northeastern South China Sea. Based on the in situ data of the Kuroshio Cruise in summer 2015, an empirical relationship between the absorption line height at 676 nm and Chla was developed for inverting Chla with a high accuracy (Chla=49.96×(a_LH(676) (676))^0.9339, the coefficient of determination R²=0.87, the root mean square error RMSE=0.16 mg·m^-3). Moreover, the response characteristics of Chla profiles to different hydrodynamic processes were studied. Results showed that large spatial differences existed in the vertical distribution of Chla. In the nearshore area, surface Chla varied from 0.42 to 1.57 mg·m^-3, which generally followed a decreasing trend with depth. Uniform vertical distribution of Chla in upper ocean was observed in the coastal upwelling region. The Subsurface Chlorophyll Maximum (SCM) layer is nearly ubiquitous in stratified waters of the open ocean, with its vertical structure being influenced by mesoscale processes. The depth of SCM ranged between 34 and 100 m, which showed consistent variability with the isopycnal depth of 1023 kg·m^-3. The SCM layer was uplifted to about 34 m due to the mixing effect in the upper ocean caused by Kuroshio intrusion in the western area of Luzon Island. The uplifting and widening of the SCM layer were also observed in the area affected by a cold eddy, with obviously different features in the eddy center from that on the eddy edge.

Key words: the northeastern South China Sea, vertical distribution of chlorophyll a concentration, Subsurface Chlorophyll Maximum, absorption line height, hydrodynamic processes

中图分类号:

P733.3

徐文龙, 王桂芬, 周雯, 许占堂, 曹文熙. 南海东北部夏季叶绿素a浓度垂向变化特征及其对水动力过程的响应^*[J]. 热带海洋学报, 2018, 37(5): 62-73.

Wenlong XU, Guifen WANG, Wen ZHOU, Zhantang XU, Wenxi CAO. Vertical variability of chlorophyll a concentration and its responses to hydrodynamic processes in the northeastern South China Sea in summer[J]. Journal of Tropical Oceanography, 2018, 37(5): 62-73.

图/表 10

图1

图2

图3

图4

图5

图6

图7

图8

图9

图10

参考文献 42

[1]	陈纪新, 黄邦钦, 刘媛, 等, 2006. 应用特征光合色素研究东海和南海北部浮游植物的群落结构[J]. 地球科学进展, 21(7): 738-746.
	CHEN JIXIN, HUANG BANGQIN, LIU YUAN, et al, 2006. Phytoplankton community structure in the transects across east China and northern South China Sea determined by analysis of HPLC photosynthetic pigment signatures[J]. Advance in Earth Science, 21(7): 738-746 (in Chinese with English abstract).
[2]	陈纪新, 黄邦钦, 柳欣, 2013. 海洋浮游生物原位观测技术研究进展[J]. 地球科学进展, 28(5): 572-576.
	CHEN JIXIN, HUANG BANGQIN, LIU XIN, 2013. The progress of in situ observation of marine plankton[J]. Advances in Earth Science, 28(5): 572-576 (in Chinese with English abstract).
[3]	傅明珠, 王宗灵, 孙萍, 等, 2009. 2006年夏季南黄海浮游植物叶绿素a分布特征及其环境调控机制[J]. 生态学报, 29(10): 5366-5375.
	FU MINGZHU, WANG ZONGLING, SUN PING, et al, 2009. Spatial distribution characteristics and the environmental regulation mechanisms of phytoplankton chlorophyll a in Southern Yellow Sea during summer 2006[J]. Acta Ecologica Snica, 29(10): 5366-5375 (in Chinese with English abstract).
[4]	高姗, 王辉, 刘桂梅, 等, 2010. 南海叶绿素a浓度垂直分布的统计估算[J]. 海洋学报, 32(4): 168-176. GAO
	SHAN, WANG HUI, LIU GUIMEI, et al, 2010. The statistical estimation of the vertical distribution of chlorophyll a concentration in the South China Sea[J]. Acta Oceanologica Sinica, 32(4): 168-176 (in Chinese with English abstract).
[5]	宫响, 史洁, 高会旺, 2012. 海洋次表层叶绿素最大值的特征因子及其影响因素[J]. 地球科学进展, 27(5): 539-548.
	GONG XIANG, SHI JIE, GAO HUIWANG, 2012. Subsurface chlorophyll maximum in ocean: its characteristics and influencing factors[J]. Advances in Earth Science, 27(5): 539-548 (in Chinese with English abstract).
[6]	黄邦钦, 刘媛, 陈纪新, 等, 2006. 东海、黄海浮游植物生物量的粒级结构及时空分布[J]. 海洋学报, 28(2): 156-164.
	HUANG BANQING, LIU YUAN, CHEN JIXIN, et al, 2006. Temporal and spatial distribution of size-fractionized phytoplankton biomass in East China Sea and Huanghai Sea[J]. Acta Oceanologica Sinica, 28(2): 156-164 (in Chinese with English abstract).
[7]	柯志新, 黄良民, 谭烨辉, 等, 2013. 2008年夏末南海北部叶绿素a的空间分布特征及其影响因素[J]. 热带海洋学报, 32(4): 51-57.
	KE ZHIXIN, HUANG LIANGMIN, TAN YEHUI, et al, 2013. Spatial distribution of chlorophyll a and its relationships with environmental factors in northern South China Sea in late summer 2008[J]. Journal of Tropical Oceanography, 32(4): 51-57 (in Chinese with English abstract).
[8]	马翱慧, 刘湘南, 李婷, 等, 2013. 南海北部海域叶绿素a浓度时空特征遥感分析[J]. 海洋学报, 35(4): 98-105.
	MA AOHUI, LIU XIANGNAN, LI TING, et al, 2013. The satellite remotely-sensed analysis of the temporal and spatial variability of chlorophyll a concentration in the northern South China Sea[J]. Acta Oceanologica Sinica, 35(4): 98-105 (in Chinese with English abstract).
[9]	吴日升, 李立, 2003. 南海上升流研究概述[J]. 应用海洋学学报, 22(2): 269-277.
	WU RISHENG, LI LI, 2003. Summarization of study on upwelling system in the South China Sea[J]. Journal of Oceanography in Taiwan Strait, 22(2): 269-277 (in Chinese with English abstract).
[10]	邢小罡, 赵冬至, CLAUSTRE H, 等, 2012. 一种新的海洋生物地球化学自主观测平台: Bio-Argo浮标[J]. 海洋环境科学, 31(5): 733-739.
	XING XIAOGANG, ZHAO DONGZHI, CLAUSTRE H, et al, 2012. A new autonomous observation platform of marine biogeochemistry: Bio-Argo floats[J]. Marine Environmental Science, 31(5): 733-739 (in Chinese with English abstract).
[11]	BOSS E, PICHERAL M, LEEUW T, et al, 2013. The characteristics of particulate absorption, scattering and attenuation coefficients in the surface ocean; Contribution of the Tara Oceans expedition[J]. Methods in Oceanography, 7: 52-62.
[12]	CHEN C T A, HUANG M H, 1996. A mid-depth front separating the South China Sea water and the Philippine sea water[J]. Journal of Oceanography, 52(1): 17-25.
[13]	CHEN C T A, JAN S, HUANG T H, et al, 2010. Spring of no Kuroshio intrusion in the southern Taiwan Strait[J]. Journal of Geophysical Research: Oceans, 115(C8): C08011.
[14]	CHEN Y L L, CHEN H Y, LIN I I, et al, 2007. Effects of cold eddy on phytoplankton production and assemblages in Luzon strait bordering the South China Sea[J]. Journal of Oceanography, 63(4): 671-683.
[15]	CHU P C, LI RONGFENG, 2000. South China Sea isopycnal-surface circulation[J]. Journal of Physical Oceanography, 30(9): 2419-2438.
[16]	CULLEN J J, LEWIS M R, 1995. Biological processes and optical measurements near the sea surface: Some issues relevant to remote sensing[J]. Journal of Geophysical Research, 100(C7): 13255.
[17]	GAN JIANPING, CHEUNG A, GUO XIAOGANG, et al, 2009. Intensified upwelling over a widened shelf in the northeastern South China Sea[J]. Journal of Geophysical Research: Oceans, 114(C9): C09019.
[18]	GONG X, SHI J, GAO H W, et al, 2015. Steady-state solutions for subsurface chlorophyll maximum in stratified water columns with a bell-shaped vertical profile of chlorophyll[J]. Biogeosciences, 12(4): 905-919.
[19]	GUO LIN, XIU PENG, CHAI FEI, et al, 2017. Enhanced chlorophyll concentrations induced by Kuroshio intrusion fronts in the northern South China Sea[J]. Geophysical Research Letters, 44(22): 11565-11572.
[20]	HAN AIQIN, DAI MINHAN, KAO S J, et al, 2012. Nutrient dynamics and biological consumption in a large continental shelf system under the influence of both a river plume and coastal upwelling[J]. Limnology and Oceanography, 57(2): 486-502.
[21]	HE QINGYOU, ZHAN HAIGANG, CAI SHUQUN, et al, 2016. Eddy effects on surface chlorophyll in the northern South China Sea: Mechanism investigation and temporal variability analysis[J]. Deep Sea Research Part I: Oceanographic Research Papers, 112: 25-36.
[22]	HU JIANYU, GAN JIANPING, SUN ZHENYU, et al, 2011. Observed three-dimensional structure of a cold eddy in the southwestern South China Sea[J]. Journal of Geophysical Research: Oceans, 116(C5): C05016.
[23]	JING ZHIYOU, QI YIQUAN, HUA ZULIN, et al, 2009. Numerical study on the summer upwelling system in the northern continental shelf of the South China Sea[J]. Continental Shelf Research, 29(2): 467-478.
[24]	LIN JIANFANG, CAO WEIXI, WANG GUIFEN, et al, 2014. Inversion of bio-optical properties in the coastal upwelling waters of the northern South China Sea[J]. Continental Shelf Research, 85: 73-84.
[25]	LIU K K, CHAO S Y, SHAW P T, et al, 2002. Monsoon-forced chlorophyll distribution and primary production in the South China Sea: observations and a numerical study[J]. Deep Sea Research Part I: Oceanographic Research Papers, 49(8): 1387-1412.
[26]	LU ZHONGMING, GAN JIANPING, DAI MINHAN, et al, 2010. The influence of coastal upwelling and a river plume on the subsurface chlorophyll maximum over the shelf of the northeastern South China Sea[J]. Journal of Marine Systems, 82(1-2): 35-46.
[27]	MAHADEVAN A, 2016. The Impact of Submesoscale Physics on Primary Productivity of Plankton[J]. Annual Review of Marine Science, 8(1): 161-84.
[28]	MCGILLICUDDY D J Jr, 2016. Mechanisms of Physical- Biological-Biogeochemical Interaction at the Oceanic Mesoscale[J]. Annual Review of Marine Science, 8(1): 125-159.
[29]	MCGILLICUDDY D J Jr, ROBINSON A R, SIEGEL D A, et al, 1998. Influence of mesoscale eddies on new production in the Sargasso Sea[J]. Nature, 394(6690): 263-266.
[30]	MUÑOZ-ANDERSON M, MILLÁN-ÚÑEZ R, HERNÁNDEZ- WALLS R, et al, 2015. Fitting vertical chlorophyll profiles in the California Current using two Gaussian curves[J]. Limnology and Oceanography: Methods, 13(8): 416-424.
[31]	NING X, CHAI F, XUE H, et al, 2004. Physical-biological oceanographic coupling influencing phytoplankton and primary production in the South China Sea[J]. Journal of Geophysical Research: Oceans, 109(C10): C10005.
[32]	PARSONS T R, MAITA Y, LALLI C M, 1984. A manual of chemical and biological methods for seawater analysis[M]. New York: Pergamon Press.
[33]	ROESLER C S, BARNARD A H.2013. Optical proxy for phytoplankton biomass in the absence of photophysiology: Rethinking the absorption line height[J]. Methods in Oceanography, 7: 79-94.
[34]	SIEGEL D A, COURT D B, MENZIES D W, et al, 2008. Satellite and in situ observations of the bio-optical signatures of two mesoscale eddies in the Sargasso Sea[J]. Deep Sea Research Part II: Topical Studies in Oceanography, 55(10-13): 1218-1230.
[35]	SULLIVAN J M, TWARDOWSKI M S, ZANEVELD J R, et al, 2006. Hyperspectral temperature and salt dependencies of absorption by water and heavy water in the 400-750 nm spectral range[J]. Applied Optics, 45(21): 5294-5309.
[36]	UITZ J, CLAUSTRE H, MOREL A, et al, 2006. Vertical distribution of phytoplankton communities in open ocean: An assessment based on surface chlorophyll[J]. Journal of Geophysical Research: Oceans, 111(C8): C08005.
[37]	WANG GUIHUA, SU JILAN, CHU P C, 2003. Mesoscale eddies in the South China Sea observed with altimeter data[J]. Geophysical Research Letters, 30(21): 2121.
[38]	WONG G T F, PAN X J, LI K Y, et al, 2015. Hydrography and nutrient dynamics in the Northern South China Sea Shelf-sea (NoSoCS)[J]. Deep Sea Research Part II: Topical Studies in Oceanography, 117: 23-40.
[39]	XIU PENG, CHAI FEI, 2011. Modeled biogeochemical responses to meso-scale eddies in the South China Sea[J]. Journal of Geophysical Research: Oceans, 116(C10): C10006.
[40]	XU JIANPING, XUE HUIJIE, SHI MAOCHONG, et al, 2002. Study on circulation and meso-scale eddies in the South China Sea in summer of 1998[J]. Acta Oceanologica Sinica, 21(4): 469-481.
[41]	YENTSCH C S, MENZEL D W, 1963. A method for the determination of phytoplankton chlorophyll and phaeophytin by fluorescence[J]. Deep Sea Research and Oceanographic Abstracts, 10(3): 221-231.
[42]	ZHANG WENZHOU, WANG HAILI, CHAI FEI, et al, 2016. Physical drivers of chlorophyll variability in the open South China Sea[J]. Journal of Geophysical Research: Oceans, 121(9): 7123-7140.
