基于高频地波雷达观测的粤西近海潮流潮能分析

doi:10.11978/2017124

热带海洋学报 ›› 2018, Vol. 37 ›› Issue (5): 25-32.doi: 10.11978/2017124CSTR: 32234.14.2017124

基于高频地波雷达观测的粤西近海潮流潮能分析

朱怀鑫^1,²(), 俎婷婷¹(), 李健¹, 舒业强¹, 陈举¹, 王东晓¹

1. 热带海洋环境国家重点实验室(中国科学院南海海洋研究所), 广东广州 510301
2. 中国科学院大学, 北京 100049;

收稿日期:2017-11-15 修回日期:2017-12-19 出版日期:2018-09-20 发布日期:2018-10-13
作者简介:
作者简介: 朱怀鑫, 男(1994—), 安徽省宿州市人, 硕士研究生, 主要从事高频地波雷达研究。E-mail: hxzhu@scsio.ac.cn
基金资助:
国家重大科学仪器设备开发专项(2013YQ16079303);中国科学院前沿科学重点研究项目(QYZDJ-SSW-DQC022);国家自然科学基金(41576003,41506022);广东省科技计划项目(2016A020224003)

Analysis of tidal current and tidal energy on the west coast of Guangdong Province based on High Frequency Ground Wave Radar observation

Huaixin ZHU^1,²(), Tingting ZU¹(), Jian LI¹, Yeqiang SHU¹, Ju CHEN¹, Dongxiao WANG¹

1. State Key Laboratory of Tropical Oceanography (South China Sea Institute of Oceanology, Chinese Academy of Sciences), Guangzhou 510301, China
2. University of Chinese Academy of Sciences, Beijing 100049, China;

Received:2017-11-15 Revised:2017-12-19 Online:2018-09-20 Published:2018-10-13
Supported by:
National Special Scientific Equipment Development Project (2013YQ16079303);Frontier Science Research Project of Chinese Academy of Sciences (Grant No. QYZDJ-SSW-DQC022);National Natural Science Foundation of China (41576003, 41506022);Science and Technology Planning Project of Guangdong Province (2016A020224003)

摘要/Abstract

摘要：

利用粤西海域高频地波雷达观测得到的表层海流资料进行潮流调和分析。结果表明: 粤西近海主要属于不正规半日分潮, 浅水分潮较强。以M₂分潮为例, 潮流运动形式主要为逆时针的往复流为主, 方向沿西北—东南方向。粤西近海的潮能主要由东部陆架输送进来, 潮能自东向西传播, 在大潮期间, 粤西的潮能出现向岸方向分量, 表现为从东南向西北方向传播, 在近岸区域潮能通量传播的方向会发生一个向岸的偏转。通过潮能收支方程计算潮能耗散, 发现粤西近海潮能耗散的高值区在西部岛屿密集区域, 与琼州海峡的存在和琼州海峡东北处地形变化存在明显的相关关系。

关键词: 粤西, 高频地波雷达, 潮流, 潮能耗散

Abstract:

We study the characteristics of tidal current on the west coast of Guangdong Province using the surface current data observed by a High Frequency Ground Wave Radar (HF radar). Tidal harmonic analysis results show that the tide in this area mostly belongs to irregular semidiurnal tide, and the shallow water components are not negligible. The M₂ tidal current is mainly counterclockwise reciprocating flow. The direction is along the northwest-southeast. In the near-shore region, tidal energy flux spreads to the shore. The tidal energy flux is from east to west in the east part of the study area. Through tidal energy budget analysis, we found that high dissipation appears in the west part of the study area, which has a lot of islands there is related to the existence of the Qiongzhou Strait and the topography on the west coast of Guangdong Province.

Key words: west coast of Guangdong Province, High Frequency Ground Wave Radar, tidal current, tidal energy, tidal dissipation

中图分类号:

P731.23

朱怀鑫, 俎婷婷, 李健, 舒业强, 陈举, 王东晓. 基于高频地波雷达观测的粤西近海潮流潮能分析[J]. 热带海洋学报, 2018, 37(5): 25-32.

Huaixin ZHU, Tingting ZU, Jian LI, Yeqiang SHU, Ju CHEN, Dongxiao WANG. Analysis of tidal current and tidal energy on the west coast of Guangdong Province based on High Frequency Ground Wave Radar observation[J]. Journal of Tropical Oceanography, 2018, 37(5): 25-32.

图/表 7

图1

图2

图3

表1

图4

图5

图6

参考文献 24

[1]	丁文兰, 1986. 南海潮汐和潮流的分布特征[J]. 海洋与湖沼, 17(6): 468-480.
	DING WENLAN, 1986. Distribution of tides and tidal currents in the South China Sea[J]. Oceanologia et Limnologia Sinica, 17(6): 468-480 (in Chinese with English abstract).
[2]	方国洪, 曹德明, 黄企洲, 1994. 南海潮汐潮流的数值模拟[J]. 海洋学报, 16(4): 1-12.
	FANG GUOHONG, CAO DEMING, HUANG QIZHOU, 1994. Numerical simulation of tidal currents in South China Sea[J]. Acta Oceanologica Sinica, 16(4): 1-12 (in Chinese).
[3]	何洪钜, 1987. 华南沿海潮汐基本特征[J]. 热带海洋学报, 6(2): 37-45.
	HE HONGJU, 1987. Tidal characteristics along South China Sea coast[J]. Tropic Oceanography, 6(2): 37-45 (in Chinese with English abstract).
[4]	侯杰昌, 吴世才, 杨子杰, 等, 1997. 海洋表面流的高频雷达遥感[J]. 地球物理学报, 40(1): 18-26.
	HOU JIECHANG, WU SHICAI, YANG ZIJIE, et al, 1997. Remote sensing of ocean surface currents by HF Radar[J]. Acta Geophysica Sinica, 40(1): 18-26 (in Chinese with English abstract).
[5]	李立, 许金电, 靖春生, 等, 2002. 南海海面高度、动力地形和环流的周年变化——TOPEX/Poseidon卫星测高应用研究[J]. 中国科学, 32(12): 978-986.
	LI LI, XU JINDIAN, JING CHUNSHENG, et al, 2003. Annual variation of sea surface height, dynamic topography and circulation in the South China Sea[J]. Science in China Series D: Earth Sciences, 46(2): 127-138.
[6]	沈育疆, 胡定明, 梅丽明, 等, 1985. 南海潮汐数值计算[J]. 海洋湖沼通报, 1985(1): 1-11.
	SHEN YUJIANG, HU DINGMING, MEI LIMING, et al, 1985. Numerical computation of the tides in the South China Sea[J]. Transactions of Oceanology and Limnology, 1985(1): 1-11 (in Chinese with English abstract).
[7]	伍伯瑜, 1990. 珠江口以西陆架海域环流研究Ⅲ[J]. 台湾海峡, 9(2): 118-126.
	WU BOYU, 1990. A Study on the circulation in shelf waters west to Zhujiang River mouth Ⅲ. Shelf circulation model[J]. Journal of Oceanography in Taiwan Strait, 9(2): 118-126 (in Chinese with English abstract).
[8]	吴雄斌, 杨绍麟, 程丰, 等, 2003. 高频地波雷达东海海洋表面矢量流探测试验[J]. 地球物理学报, 46(3): 340-346.
	WU XIONGBIN, YANG SHAOLIN, CHENG FENG, et al, 2003. Ocean surface currents detection at the eastern China Sea by HF surface wave radar[J]. Chinese Journal of Geophysics, 46(3): 340-346 (in Chinese with English abstract).
[9]	严金辉, 陈达森, 2005. 粤西水东单点系泊海域潮流和低频流特征[J]. 海洋湖沼通报, 2005(3): 8-15.
	YAN JINHUI, CHEN DASEN, 2005. The characteristics of low frequency currents in the area of Shuidong anchored floating whelf in the west of Guangdong coastal waters[J]. Transaction of Oceanology and Limnology, 2005(3): 8-15 (in Chinese with English abstract).
[10]	杨士瑛, 鲍献文, 陈长胜, 等, 2003. 夏季粤西沿岸流特征及其产生机制[J]. 海洋学报, 25(6): 1-8.
	YANG SHIYING, BAO XIANWEN, CHEN CHANGSHENG, et al, 2003. Analysis on characteristics and mechanism of current system in west coast of Guangdong Province in the summer[J]. Acta Oceanologica Sinica, 25(6): 1-8 (in Chinese with English abstract).
[11]	俞慕耕, 1984. 南海潮汐特征的初步探讨[J]. 海洋学报, 6(3): 15-22.
	YU, MUGENG, 1984. A preliminary study of tidal characteristics in the South China Sea[J]. Acta Oceanologica Sinica, 6(3): 293-300 (in Chinese).
[12]	章卫胜, 宋志尧, 张金善, 等. 中国近海潮波运动特征分析[C]//第十二届中国海岸工程学术研讨会论文集. 北京: 中国海洋工程学会, 2005.
[13]	郑有任, 张娟, 吴日升, 2012. 南海北部沿岸海域潮汐的调和分析[J]. 台湾海峡, 31(4): 549-556.
	ZHENG YOUREN, ZHANG JUAN, WU RISHENG, 2012. Tidal analysis along the coast of the northern South China Sea[J]. Journal of Oceanography in Taiwan Strait, 31(4): 549-556 (in Chinese with English abstract).
[14]	中华人民共和国交通部, 1988. 港口工程技术规范(1987) 上卷[M]. 北京: 人民交通出版社: 393-399.
[15]	周浩, 文必洋, 2002. 高频地波雷达生成海洋表面矢量流图[J]. 海洋与湖沼, 33(1): 1-7.
	ZHOU HAO, WEN BIYANG, 2002. Mapping ocean surface vector currents by dual HF ground wave radars[J]. Oceanologia et Limnologia Sinica, 33(1): 1-7 (in Chinese with English abstract).
[16]	朱大勇, 邵浩, 李炎, 等, 2007. OSMAR高频地波雷达福建示范系统径向流数据质量分析[J]. 台湾海峡, 26(1): 7-16.
	ZHU DAYONG, SHAO HAO, LI YAN, et al, 2007. Quality analyses of radial currents measured by a demonstration system of OSMAR HF radar in Fujian Province[J]. Journal of Oceanography in Taiwan Strait, 26(1): 7-16 (in Chinese with English abstract).
[17]	BARRICK D E, EVANS M W, WEBER B L, 1977. Ocean surface currents mapped by radar[J]. Science, 198(4313): 138-144.
[18]	CROMBIE D D, 1955. Doppler spectrum of sea echo at 13.56 Mc./s.[J]. Nature, 175(4459): 681-682.
[19]	FANG GUOHONG, 1986. Tide and tidal current charts for the marginal seas adjacent to China[J]. Chinese Journal of Oceanology and Limnology, 4(1): 1-16.
[20]	FANG GUOHONG, KWOK Y K, YU KEJUN, et al, 1999. Numerical simulation of principal tidal constituents in the South China Sea, Gulf of Tonkin and Gulf of Thailand[J]. Continental Shelf Research, 19(7): 845-869.
[21]	LIPA B, BARRICK D, 1983. Least-squares methods for the extraction of surface currents from CODAR crossed-loop data: Application at ARSLOE[J]. IEEE Journal of Oceanic Engineering, 8(4): 226-253.
[22]	PAWLOWICZ R, BEARDSLEY B, LENTZ S, 2002. Classical tidal harmonic analysis including error estimates in MATLAB using T_TIDE[J]. Computers & Geosciences, 28(8): 929-937.
[23]	STEWART R H, JOY J W, 1974. HF radio measurements of surface currents[J]. Deep Sea Research and Oceanographic Abstracts, 21(12): 1039-1049.
[24]	ZU TINGTING, GAN JIANPING, EROFEEVA S Y, 2008. Numerical study of the tide and tidal dynamics in the South China Sea[J]. Deep Sea Research Part I: Oceanographic Research Papers, 55(2): 137-154.

观测仪器	O₁		K₁		M₂		S₂		M₄		MS₄		特征值 F	特征值G
观测仪器	长轴/(m·s^-1)	迟角/(°)	长轴/(m·s^-1)	迟角/(°)	长轴/(m·s^-1)	迟角/(°)	长轴/(m·s^-1)	迟角/(°)	长轴/(m·s^-1)	迟角/(°)	长轴/(m·s^-1)	迟角/(°)	特征值 F	特征值G
ADCP	0.129	232	0.104	252	0.219	232	0.077	282	0.024	216	0.013	269	1.06	0.17
雷达(6月)	0.116	207	0.061	224	0.191	234	0.063	280	0.012	193	0.016	209	0.93	0.15
雷达(11月)	0.102	220	0.094	250	0.129	229	0.065	64	0.015	150	0.014	119	1.52	0.22
