基于逐步订正的国产卫星遥感海表温度数据融合*

doi:10.11978/2025015

热带海洋学报 ›› 2025, Vol. 44 ›› Issue (6): 1-11.doi: 10.11978/2025015CSTR: 32234.14.2025015

所属专题：海洋大数据及应用

• 海洋水文学 • 下一篇

基于逐步订正的国产卫星遥感海表温度数据融合^*

牛浩然¹^,²(), 王喜冬¹^,²(), 高振博¹^,², 陈志强³

¹ 河海大学, 自然资源部海洋灾害预报技术重点实验室, 江苏南京 210024
² 河海大学海洋学院, 江苏南京 210024
³ 中国科学院南海海洋研究所, 广东广州 510301

收稿日期:2025-01-25 修回日期:2025-03-18 出版日期:2025-11-10 发布日期:2025-12-03
通讯作者: 王喜冬。email: xidong_wang@hhu.edu.cn
作者简介:
牛浩然(2000—), 男, 安徽省阜阳市人, 硕士研究生, 从事海气相互作用研究。email: 221311040013@hhu.edu.cn
基金资助:
国家自然科学基金(41776004)

Domestic satellite sea surface temperature data fusion based on successive corrections^*

NIU Haoran¹^,²(), WANG Xidong¹^,²(), GAO Zhenbo¹^,², CHEN Zhiqiang³

¹ Key Laboratory of Marine Hazards Forecasting, Ministry of Natural Resources, Hohai University, Nanjing 210024, China
² College of Oceanography, Hohai University, Nanjing 210024, China
³ South China Sea Institute of Oceanology, Chinese Academy of Sciences, Guangzhou 510301, China

Received:2025-01-25 Revised:2025-03-18 Online:2025-11-10 Published:2025-12-03
Contact: WANG Xidong. email: xidong_wang@hhu.edu.cn
Supported by:
National Natural Science Foundation of China(41776004)

摘要/Abstract

摘要：

海表温度(sea surface temperature, SST)作为大气海洋圈层的重要环境变量之一, 对于海洋学的研究具有重要意义。本文基于国产海洋(HaiYang, HY)和风云(FengYun, FY)卫星遥感SST数据, 利用逐步订正数据融合方法, 研制了“海上丝绸之路”沿线海域自主化、高时空分辨率卫星SST融合产品。首先利用iQuam实测数据开展了海洋卫星和风云卫星的SST观测数据精度评估, 同时对HY-1C和HY-1D卫星进行了偏差校正; 其次, 利用HY-1C、HY-1D、HY-2B、FY-3D、FY-3E和FY-4B的SST数据以及多尺度逐步订正融合算法, 制作了2024年4月至6月“海上丝绸之路”沿线海域逐日0.1°×0.1°分辨率SST融合产品; 最后, 利用iQuam实测数据评估了融合产品精度。结果发现, 融合产品平均偏差为0.08℃, 均方根误差为0.67℃, 产品精度较好。不同SST融合产品的功率谱分析结果表明, 本文生成的SST融合产品较OISST (optimum interpolation sea surface temperature)产品在刻画100km以小尺度特征上更有优势, 与OSTIA产品在50~100km尺度上性能相当, 体现了融合产品良好的应用潜力。

关键词: 海表温度, 国产卫星, 逐步订正, 数据融合

Abstract:

As one of the important environmental variables in the atmosphere-ocean system, sea surface temperature (SST) is of significant importance for oceanographic research. This paper utilizes domestic HaiYang (HY) and FengYun (FY) satellites remote sensing SST data to develop an autonomous, high spatiotemporal resolution satellite SST fusion product for the “Maritime Silk Road” region using the successive corrections method. First, the accuracy of SST observation data from HY and FY satellites was evaluated using iQuam in-situ data, with bias correction performed on HY-1C and HY-1D. Next, SST data from HY-1C, HY-1D, HY-2B, FY-3D, FY-3E, and FY-4B, along with a multi-scale successive corrections fusion algorithm, were used to create a daily 0.1°×0.1° resolution SST fusion product for the “Maritime Silk Road” region from April to June 2024. Finally, the accuracy of the fusion product was assessed using iQuam in-situ data. The results showed that the fusion product had an average bias of 0.08°C and a root mean square error (RMSE) of 0.67°C, indicating good accuracy. Power spectral analysis of different SST fusion products demonstrated that the SST fusion product generated in this study outperforms the Optimum Interpolation Sea Surface Temperature (OISST) in capturing small-scale features at the 100 km scale and shows comparable performance to the Operational Sea Surface Temperature and Sea Ice Analysis (OSTIA) at the 50-100 km scale, reflecting its good application potential.

Key words: sea surface temperature, domestic satellite, successive corrections, data fusion

中图分类号:

P714.1

牛浩然, 王喜冬, 高振博, 陈志强. 基于逐步订正的国产卫星遥感海表温度数据融合^*[J]. 热带海洋学报, 2025, 44(6): 1-11.

NIU Haoran, WANG Xidong, GAO Zhenbo, CHEN Zhiqiang. Domestic satellite sea surface temperature data fusion based on successive corrections^*[J]. Journal of Tropical Oceanography, 2025, 44(6): 1-11.

图/表 14

图1

图2

表1

图3

图4

图5

图6

图7

表2

图8

图9

表3

图10

图11

参考文献 29

[1]	何子康, 王喜冬, 陈志强, 等, 2021. 利用海洋温度剖面与海表盐度反演盐度剖面方法研究[J]. 热带海洋学报, 40(6): 41-51. doi: 10.11978/2020141
	HE ZIKANG, WANG XIDONG, CHEN ZHIQIANG, et al, 2021. Reconstructing salinity profile using temperature profile and sea surface salinity[J]. Journal of Tropical Oceanography, 40(6): 41-51 (in Chinese with English abstract). doi: 10.11978/2020141
[2]	柳雯俊, 2020. 基于优化神经网络的海温融合与三维模型研究[D]. 武汉: 华中科技大学.
	LIU WENJUN, 2020. Research on sea surface temperature fusion and 3D model based on optimized neural network[D]. Wuhan: Huazhong University of Science and Technology (in Chinese with English abstract).
[3]	刘伊格, 2019. 渤海和黄海海表温度变化及成因分析[D]. 南京: 南京大学.
	LIU YIGE, 2019. Sea surface temperature change and cause analysis in the Bohai Sea and the Yellow Sea[D]. Nanjing: Nanjing University (in Chinese with English abstract).
[4]	苗春生, 程远, 王坚红, 等, 2015. 中国风云卫星与海洋卫星近海SST资料融合技术及应用研究[J]. 地球科学进展, 30(10): 1127-1143. doi: 10. 11867/ j. issn. 1001-8166. 2015. 10. 1127
	MIAO CHUNSHENG, CHENG YUAN, WANG JIANHONG, et al, 2015. Data fusion of offshore SST from China FY and HY2 satellites and its application[J]. Advances in Earth Science, 30(10): 1127-1143 (in Chinese with English abstract). doi: 10. 11867/ j. issn. 1001-8166. 2015. 10. 1127
[5]	齐庆华, 蔡榕硕, 2019. 中国近海海表温度变化的极端特性及其气候特征研究[J]. 海洋学报, 41(7): 36-51.
	QI QINGHUA, CAI RONGSHUO, 2019. Analysis on climate characteristics of sea surface temperature extremes in coastal China seas[J]. Haiyang Xuebao, 41(7): 36-51 (in Chinese with English abstract).
[6]	石绥祥, 夏登文, 于戈, 2005. 基于D-S理论的卫星遥感海表面温度和同化数据融合方法[J]. 海洋学报(中文版), 27(4): 31-37.
	SHI SUIXIANG, XIA DENGWEN, YU GE, 2005. Method of fusing the data reversed from satellite remote-sensing with the assimilation data for sea surface temperature based on D-S theory[J]. Acta Oceanologica Sinica, 27(4): 31-37 (in Chinese with English abstract).
[7]	王艳珍, 管磊, 曲利芹, 2010. 卡尔曼滤波在卫星红外、微波海表温度数据融合中的应用[J]. 中国海洋大学学报(自然科学版), 40(12): 126-130.
	WANG YANZHEN, GUAN LEI, QU LIQIN, 2010. Merging sea surface temperature observed by satellite infrared and microwave radiometers using Kalman filter[J]. Periodical of Ocean University of China, 40(12): 126-130 (in Chinese with English abstract).
[8]	徐宾, 宇婧婧, 张雷, 等, 2018. 全球海表温度融合研究进展[J]. 气象科技进展, 8(1): 164-170.
	XU BIN, YU JINGJING, ZHANG LEI, et al, 2018. Research progress of global sea surface temperature fusion[J]. Advances in Meteorological Science and Technology, 8(1): 164-170 (in Chinese with English abstract).
[9]	奚萌, 2011. 基于最优插值算法的红外和微波遥感海表温度数据融合[D]. 北京: 国家海洋环境预报研究中心.
	XI MENG, 2011. Merging infrared radiometer and microwave radiometer sea surface temperature data based on the optimum interpolation[D]. Beijing: National Marine Environmental Forcasting Center (in Chinese with English abstract).
[10]	杨梦, 孙伟富, 姜远驰, 2024. 东南亚海域HY-1C SST数据评估与校正[J]. 数字海洋与水下攻防, 7(1): 87-97.
	YANG MENG, SUN WEIFU, JIANG YUANCHI, 2024. Assessment and correction of HY-1C SST data in the Southeast Asian sea area[J]. Digital Ocean & Underwater Warfare, 7(1): 87-97 (in Chinese with English abstract).
[11]	张慧, 2006. 基于小波变换的AVHRR和AMSR-E卫星海表温度数据融合[D]. 青岛: 中国海洋大学.
	ZHANG HUI, 2006. Merging AVHRR and AMSR-E sea surface temperature data based on wavelet transform[D]. Qingdao: Ocean University of China (in Chinese with English abstract).
[12]	BARNES S L, 1973. Mesoscale objective map analysis using weighted time series observations[Z]. NOAA Technical Memorandum ERL NSSL: 62.
[13]	BRETHERTON F P, DAVIS R E, FANDRY C B, 1976. A technique for objective analysis and design of oceanographic experiments applied to MODE-73[J]. Deep Sea Research and Oceanographic Abstracts, 23(7): 559-582. doi: 10.1016/0011-7471(76)90001-2
[14]	CHAO YI, LI ZHIJIN, FARRARA J D, et al, 2009. Blending sea surface temperatures from multiple satellites and in situ observations for coastal oceans[J]. Journal of Atmospheric and Oceanic Technology, 26(7): 1415-1426. doi: 10.1175/2009JTECHO592.1
[15]	CRESSMAN G P, 1959. An operational objective analysis system[J]. Monthly Weather Review, 87(10): 367-374. doi: 10.1175/1520-0493(1959)087<0367:AOOAS>2.0.CO;2
[16]	DASH P, IGNATOV A, MARTIN M, et al, 2012. Group for High Resolution Sea Surface Temperature (GHRSST) analysis fields inter-comparisons: Part 2: Near real time web-based level 4 SST Quality Monitor (L4-SQUAM)[J]. Deep Sea Research Part II: Topical Studies in Oceanography, 77: 31-43.
[17]	GENTEMANN C L, DONLON C J, STUART-MENTETH A, et al, 2003. Diurnal signals in satellite sea surface temperature measurements[J]. Geophysical Research Letters, 30(3): 1140.
[18]	KALMAN R E, 1960. A new approach to linear filtering and prediction problems[J]. Journal of Basic Engineering, 82(1): 35-45. doi: 10.1115/1.3662552
[19]	KAWAI Y, WADA A, 2007. Diurnal sea surface temperature variation and its impact on the atmosphere and ocean: a review[J]. Journal of Oceanography, 63(5): 721-744. doi: 10.1007/s10872-007-0063-0
[20]	LI AIHUA, BO YANCHEN, ZHU YUXIN, et al, 2013. Blending multi-resolution satellite sea surface temperature (SST) products using Bayesian maximum entropy method[J]. Remote Sensing of Environment, 135: 52-63. doi: 10.1016/j.rse.2013.03.021
[21]	LI JIE, XING QIANGUO, LI XUERONG, et al, 2024. Monitoring off-shore fishing in the northern Indian Ocean based on satellite automatic identification system and remote sensing data[J]. Sensors, 24(3): 781. doi: 10.3390/s24030781
[22]	PING BO, SU FENZHEN, MENG YUNSHAN, 2015. Reconstruction of satellite-derived sea surface temperature data based on an improved DINEOF algorithm[J]. IEEE Journal of Selected Topics in Applied Earth Observations and Remote Sensing, 8(8): 4181-4188. doi: 10.1109/JSTARS.4609443
[23]	REYNOLDS R W, SMITH T M, LIU CHUNYING, et al, 2007. Daily high-resolution-blended analyses for sea surface temperature[J]. Journal of Climate, 20(22): 5473-5496. doi: 10.1175/2007JCLI1824.1
[24]	REYNOLDS R W, CHELTON D B, 2010. Comparisons of daily sea surface temperature analyses for 2007-08[J]. Journal of Climate, 23(13): 3545-3562. doi: 10.1175/2010JCLI3294.1
[25]	STARK J D, DONLON C J, MARTIN M J, et al, 2007. OSTIA:an operational, high resolution, real time, global sea surface temperature analysis system[C]// OCEANS 2007 - Europe. Aberdeen: IEEE: 1-4.
[26]	WANG MINGQING, WANG DANNI, XIANG YANFEI, et al, 2023. Fusion of ocean data from multiple sources using deep learning: Utilizing sea temperature as an example[J]. Frontiers in Marine Science, 10: 1112065. doi: 10.3389/fmars.2023.1112065
[27]	XU FENG, IGNATOV A, 2014. In situ SST quality monitor (iQuam)[J]. Journal of Atmospheric and Oceanic Technology, 31(1): 164-180. doi: 10.1175/JTECH-D-13-00121.1
[28]	ZHANG HAO, LI ZHENGQIANG, DE LEEUW G, et al, 2024. High spatiotemporal resolution sea surface temperature from MERSI and AGRI sensors based on spatial and temporal adaptive sea surface temperature fusion model[J]. IEEE Transactions on Geoscience and Remote Sensing, 62: 1-13.
[29]	ZHOU WEI, CHENG YANJIE, WANG SUJUAN, et al, 2013. Evaluation and preprocess of Chinese Fengyun-3A sea surface temperature experimental product for data assimilation[J]. Atmospheric and Oceanic Science Letters, 6(3): 128-132. doi: 10.1080/16742834.2013.11447068

卫星	匹配数	平均偏差/℃	绝对偏差/℃	均方根误差/℃	相关系数
HY-1C	9725	-1.45	1.65	2.08	0.75
HY-1D	9572	-1.23	1.52	1.98	0.70
HY-2B	2328	-1.25	1.38	1.73	0.81
FY-3D	3877	-0.36	0.72	0.94	0.88
FY-3E	7935	0.04	0.47	0.63	0.94
FY-4B	24712	-0.39	0.59	0.77	0.94

卫星	平均偏差/℃	均方根误差/℃	绝对偏差/℃
HY-1C	0.13	1.11	0.83
HY-1D	0.09	1.08	0.82

	融合产品	OISST
平均偏差/℃	0.08	-0.14
绝对偏差/℃	0.47	0.37
均方根误差/℃	0.67	0.52
相关系数	0.96	0.97
