南海岛礁蒸散发量和降雨入渗量模拟研究

doi:10.11978/2023192

Abstract

Abstract:

Evapotranspiration and soil infiltration, as the basic links in the rainfall water cycle, play an extremely important role in regional hydrological characteristics and water resource utilization. This study takes the Zhaoshu Island as the study area to estimate the potential evapotranspiration in vegetation areas and the actual evaporation in non-vegetation areas based on PM (Penman-Monteith) formula and SEBAL (surface energy balance algorithm for land) formula, respectively, construct a BP(back propagation) neural network model to simulate the potential evapotranspiration in vegetation areas and the actual evaporation in non-vegetation areas of the island, and simulate rainfall infiltration in beaches and bare soil based on the Kostiakov infiltration model and characteristics of precipitation infiltration process. The results show that the determination coefficients (R²) of the two evapotranspiration simulation models are higher than 0.85, and the model efficiency index (EF) are higher than 0.85. The average daily evapotranspiration of each land cover types on the Zhaoshu Island is the highest in May and the lowest in December of a year. The monthly change of potential evapotranspiration in the vegetation area is the most obvious. In areas with high soil sand content, the R² of the Kostiakov infiltration model is generally larger than 0.85. The steady infiltration rate of soil in the Zhaoshu Island is about 0.33 cm·min^-1. Multi-year rainfall data shows that the rainfall intensity in the study area is basically less than the steady infiltration rate, so the rainfall to the ground basically all infiltrates, and the rainfall infiltration in the dry season and the rainy season is significantly different. This study provides a feasible solution for the simulation of evapotranspiration and rainfall infiltration in the South China Sea islands where there is a lack of measured data, and provides data support for the construction of the island precipitation cycle.

Key words: evapotranspiration, BP neural network, infiltration model, rainfall infiltration

CLC Number:

P426.2

ZHAO Yongzhu, YAN Jinfeng, LIU Bei, ZHU Jiang. Simulation study of the evapotranspiration and rainfall infiltration of islands and reefs in the South China Sea[J].Journal of Tropical Oceanography, 2024, 43(6): 37-49.

Figures/Tables 14

Tab. 1

Tab. 2

Tab. 3

Fig.1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Tab. 4

Tab. 5

Empirical parameters of the Kostiakov model"

数据来源	Kostiakov模型		结束时间/min	备注
数据来源	$a$	$b$	结束时间/min	备注
Duan等 (2011)	0.669 1	0.278 9	无相关信息	模拟入渗速率
Ogbe等 (2011) 实验(1)	1.386 8	0.781	208	模拟累积入渗量
Ogbe等 (2011) 实验(2)	1.559 6	0.784	208	模拟累积入渗量
Ogbe等 (2011) 实验(3)	1.517 1	0.785	208	模拟累积入渗量
Bi等 (2014)	1.159	0.588	60~90	模拟入渗速率
Ahaneku等 (2015) 实验(1)	1.318	0.542	150	模拟累积入渗量
Ahaneku等 (2015) 实验(2)	1.013	0.662	150	模拟累积入渗量
Khalid等 (2018)	0.6	0.024	>40	模拟入渗速率
Yang等 (2022)	2.702	0.825	25	模拟累积入渗量

Tab. 5

Fig. 6

Fig. 7

Tab. 6

Tab. 7

References 66

[1]	阿茹·苏里坦, 常顺利, 张毓涛, 2019. 天山林区不同群落土壤水分入渗特性的对比分析与模拟[J]. 生态学报, 39(24): 9111-9118.
	ARU SULTAN, CHANG SHUNLI, ZHANG YUTAO, 2019. Comparative analysis and simulation of soil moisture infiltration characteristics in different communities in the forests of Tianshan Mountains, China[J]. Acta Ecologica Sinica, 39(24): 9111-9118 (in Chinese with English abstract).
[2]	安善涛, 焦磊, 梁伟, 等, 2021. 基于多源数据的黄土高原陆地水循环结构变化分析[J]. 生态学报, 41(17): 6800-6813.
	AN SHANTAO, JIAO LEI, LIANG WEI, et al, 2021. Analysis of changes in land water cycle structure in the Loess Plateau based on multi-source data[J]. Acta Ecologica Sinica, 41(17): 6800-6813 (in Chinese with English abstract).
[3]	曹永强, 王菲, 2021. 河北省植被时空变化及其对气象干旱的响应[J]. 南水北调与水利科技(中英文), 19(4): 708-719, 757.
	CAO YONGQIANG, WANG FEI, 2021. Spatial and temporal variation of vegetation and its response to meteorological drought in Hebei Province[J]. South-to-North Water Transfers and Water Science & Technology, 19(4): 708-719, 757 (in Chinese with English abstract).
[4]	陈晓莹, 2020. 荒漠草原两种典型土壤的水分特征及其影响因素[D]. 银川: 宁夏大学:29-30.
	CHEN XIAOYING, 2020. Water characteristics of two typical soil types in desert steppe and their influencing factors[D]. Yinchuan: Ningxia University: 29-30 (in Chinese with English abstract).
[5]	樊龙凤, 李海英, 黄真理, 等, 2021. 基于人工降水入渗的热带海岛表面砂土层水质变化特征[J]. 土壤, 53(1): 197-208.
	FAN LONGFENG, LI HAIYING, HUANG ZHENLI, et al, 2021. Water quality variation characteristics of sandy layer on surface of tropical islands based on simulated precipitation infiltration[J]. Soils, 53(1): 197-208 (in Chinese with English abstract).
[6]	共产党员网, 2012. 三沙第一个基础设施项目竣工[EB/OL]. (2012-11-11) [2024-02-20]. https://news.12371.cn/2012/11/11/ARTI1352621075787274.shtml.
[7]	韩生生, 刘苏峡, 宋献方, 等, 2021. 西沙赵述岛地表蒸散发实验[J]. 地理研究, 40(1): 172-184. doi: 10.11821/dlyj020190860
	HAN SHENGSHENG, LIU SUXIA, SONG XIANFANG, et al, 2021. Field evapotranspiration experiment in Zhaoshu Island of Xisha Islands, South China Sea[J]. Geographical Research, 40(1): 172-184 (in Chinese with English abstract).
[8]	胡明鉴, 蒋航海, 朱长歧, 等, 2017. 钙质砂的渗透特性及其影响因素探讨[J]. 岩土力学, 38(10): 2895-2900.
	HU MINGJIAN, JIANG HANGHAI, ZHU CHANGQI, et al, 2017. Discussion on permeability of calcareous sand and its influencing factors[J]. Rock and Soil Mechanics, 38(10): 2895-2900 (in Chinese with English abstract).
[9]	简文星, 许强, 童龙云, 2013. 三峡库区黄土坡滑坡降雨入渗模型研究[J]. 岩土力学, 34(12): 3527-3533, 3548.
	JIAN WENXING, XU QIANG, TONG LONGYUN, 2013. Rainfall infiltration model of Huangtupo landslide in Three Gorges Reservoir area[J]. Rock and Soil Mechanics, 34(12): 3527-3533, 3548 (in Chinese with English abstract).
[10]	李可良, 许宏发, 杨殷豪, 等, 2020. 钙质砂渗透性能研究现状及展望[J]. 中国水运(下半月), 20(1): 214-215, 218 (in Chinese).
[11]	刘风华, 代智光, 费良军, 2019. 容重对红壤条件下涌泉根灌水分入渗能力影响[J]. 水土保持学报, 33(1): 86-90, 97.
	LIU FENGHUA, DAI ZHIGUANG, FEI LIANGJUN, 2019. The influence of bulk density on water infiltration capacity in red soil under surge-root irrigation[J]. Journal of Soil and Water Conservation, 33(1): 86-90, 97 (in Chinese with English abstract).
[12]	刘凯, 王磊, 宋乃平, 等, 2013. 毛乌素沙地南缘不同林龄人工柠条林土壤渗透性研究[J]. 干旱区资源与环境, 27(5): 89-94.
	LIU KAI, WANG LEI, SONG NAIPING, et al, 2013. Soil infiltration characteristics of Caragana korshinkii plantation with different ages in south edge of Mu Us Sandy Land[J]. Journal of Arid Land Resources and Environment, 27(5): 89-94 (in Chinese with English abstract).
[13]	刘茜茹, 冯天骄, 王平, 等, 2023. 晋西黄土区长期植被恢复对土壤表层入渗与水分储量差异的影响[J]. 水土保持通报, 43(2): 50-59.
	LIU XIRU, FENG TIANJIAO, WANG PING, et al, 2023. Effect of long-term vegetation restoration on surface soil water infiltration and water storage in loess area of western Province[J]. Bulletin of Soil and Water Conservation, 43(2): 50-59 (in Chinese with English abstract).
[14]	吕炳全, 王国忠, 全松青, 1987. 西沙群岛灰砂岛的沉积特征和发育规律[J]. 海洋地质与第四纪地质, 7(2): 59-69.
	LV BINGQUAN, WANG GUOZHONG, QUAN SONGQING, 1987. Sedimentary characteristics and evolutionary pattern of the sand cays in the Xisha Islands[J]. Marine Geology & Quaternary Geology, 7(2): 59-69 (in Chinese with English abstract).
[15]	马龙龙, 杜灵通, 宫菲, 等, 2019. 基于SEBAL模型的农牧交错区蒸散演变及生态需水规律[J]. 水土保持通报, 39(4): 177-183.
	MA LONGLONG, DU LINGTONG, GONG FEI, et al, 2019. Evapotranspiration evolution and ecological water requirement law in agro-pastoral ecotone based on SEBAL model[J]. Bulletin of Soil and Water Conservation, 39(4): 177-183 (in Chinese with English abstract).
[16]	澎湃新闻, 2017. 南海三沙岛礁引入风光互补新能源海水淡化设备, 化解用水难[EB/OL]. (2017-02-14)[2024-02-20]. https://www.thepaper.cn/newsDetail_forward_1618723.
[17]	汤珊珊, 李占斌, 任宗萍, 等, 2015. 覆沙坡面产流产沙过程试验研究[J]. 水土保持学报, 29(5): 25-28.
	TANG SHNASHAN, LI ZHANBIN, REN ZONGPING, et al, 2015. Experimental study on the process of runoff and sediment yield on sand-covered slope[J]. Journal of Soil and Water Conservation, 29(5): 25-28 (in Chinese with English abstract).
[18]	王海波, 马明国, 2014. 基于遥感和Penman-Monteith模型的内陆河流域不同生态系统蒸散发估算[J]. 生态学报, 34(19): 5617-5626.
	WANG HAIBO, MA MINGGUO, 2014. Estimation of transpiration and evaporation of different ecosystems in an inland river basin using remote sensing data and the Penman-Monteith equation[J]. Acta Ecologica Sinica, 34(19): 5617-5626 (in Chinese with English abstract).
[19]	王红, 2014. 水土保持典型措施对地下水补给生态基流的影响研究[D]. 杨陵: 中国科学院研究生院(教育部水土保持与生态环境研究中心):73.
	WANG HONG, 2014. The impacts of typical measures of soil and water conservation on ecological basic flow recharged from groundwater[D]. Yangling: Research Center for Eco-environments and Soil and Water Conservation, Chinese Academy of Sciences & Ministry of Education: 73 (in Chinese with English abstract).
[20]	王瑞, 唐文浩, 宋玉梅, 等, 2011. 西沙群岛土壤环境质量状况及特征分析[J]. 安徽农业科学, 39(10): 5837-5840.
	WANG RUI, TANG WENHAO, SONG YUMEI, et al, 2011. Analysis on quality status and characteristics of soil environment in Xisha Islands[J]. Journal of Anhui Agricultural Sciences, 39(10): 5837-5840 (in Chinese with English abstract).
[21]	王硕, 白云岗, 王兴鹏, 等, 2021. 和田河沙漠地带河床入渗特征研究[J]. 干旱区资源与环境, 35(8): 114-121.
	WANG SHUO, BAI YUNGANG, WANG XINGPENG, et al, 2021. Water infiltration of Hotan River bed in desert area[J]. Journal of Arid Land Resources and Environment, 35(8): 114-121 (in Chinese with English abstract).
[22]	王韦娜, 张翔, 张立锋, 等, 2019. 蒸渗仪法和涡度相关法测定蒸散的比较[J]. 生态学杂志, 38(11): 3551-3559.
	WANG WEINA, ZHANG XIANG, ZHANG LIFENG, et al, 2019. A comparison study of the evapotranspiration measured by lysimeter and eddy covariance[J]. Chinese Journal of Ecology, 38(11): 3551-3559 (in Chinese with English abstract).
[23]	王新志, 王星, 胡明鉴, 等, 2017. 吹填人工岛地基钙质粉土夹层的渗透特性研究[J]. 岩土力学, 38(11): 3127-3135.
	WANG XINZHI, WANG XING, HU MINGJIAN, et al, 2017. Study of permeability of calcareous silty layer of foundation at an artificial reclamation island[J]. Rock and Soil Mechanics, 38(11): 3127-3135 (in Chinese with English abstract).
[24]	邢建伟, 宋金明, 2023. 南海大气沉降及其生态环境效应[J]. 热带海洋学报, 42(3): 19-39.
	XING JIANWEI, SONG JINMING, 2023. Atmospheric deposition and its eco-environmental effects on the South China Sea[J]. Journal of Tropical Oceanography, 42(3): 19-39 (in Chinese with English abstract).
[25]	熊友胜, 2013. 三峡库区紫色土坡耕地水量平衡研究[D]. 重庆:西南大学:32-33.
	XIONG YOUSHENG, 2013. On water balance of slope farmland in purple soil area of Three Gorges Reservoir Basin[D]. Chongqing: Southwest University: 32-33 (in Chinese with English abstract).
[26]	徐俊增, 彭世彰, 张瑞美, 等, 2006. 基于气象预报的参考作物蒸发蒸腾量的神经网络预测模型[J]. 水利学报, 37(3): 376-379.
	XU JUNZENG, PENG SHIZHANG, ZHANG RUIMEI, et al, 2006. Neural network model for reference crop evapotranspiration prediction based on weather forecast[J]. Journal of Hydraulic Engineering, 37(3): 376-379 (in Chinese with English abstract).
[27]	杨安富, 胡玉麟, 林天, 等, 2022. 中国西沙群岛土系的建立[J]. 土壤学报, 59(3): 667-677.
	YANG ANFU, HU YULIN, LIN TIAN, et al, 2022. Establishment of soil series for Xisha Islands[J]. Acta Pedologica Sinica, 59(3): 667-677 (in Chinese with English abstract).
[28]	赵焕庭, 王丽荣, 袁家义, 2017. 南海诸岛的自然环境、资源与开发——纪念中国政府收复南海诸岛70周年(3)[J]. 热带地理, 37(5): 659-680, 693. doi: 10.13284/j.cnki.rddl.002983
	ZHAO HUANTING, WANG LIRONG, YUAN JIAYI, 2017. Natural environment, resources and development of the South China Sea islands: The 70^th anniversary of recovery of the South China Sea islands (3)[J]. Tropical Geography, 37(5): 659-680, 693 (in Chinese with English abstract).
[29]	赵景波, 马延东, 邢闪, 等, 2011. 腾格里沙漠宁夏回族自治区中卫市沙层水分入渗研究[J]. 水土保持通报, 31(3): 12-16, 70.
	ZHAO JINGBO, MA YANDONG, XING SHAN, et al, 2011. Sand layer water permeability of Tengger Desert in Zhongwei City, Ningxia Hui autonomous region[J]. Bulletin of Soil and Water Conservation, 31(3): 12-16, 70 (in Chinese with English abstract).
[30]	郑超磊, 贾立, 胡光成, 2023. 高分一号卫星遥感数据驱动ETMonitor模型估算16 m分辨率蒸散发及验证[J]. 遥感学报, 27(3): 758-768.
	ZHENG CHAOLEI, JIA LI, HU GUANGCHENG, 2023. Evapotranspiration estimation and validation at 16 m resolution based on ETMonitor model driven by GF-1 satellite remote sensing datasets[J]. National Remote Sensing Bulletin, 27(3): 758-768 (in Chinese with English abstract).
[31]	中国网, 2016. 军民融合力量大三沙市走出岛礁绿化生态发展之路[EB/OL]. (2016-09-29)[2024-02-20]. http://cn.chinagate.cn/environment/2016-09/29/content_393981872.htm.
[32]	周剑, 李新, 王根绪, 等, 2008. 陆面过程模式SIB2与包气带入渗模型的耦合及其应用[J]. 地球科学进展, 23(6): 570-579. doi: 10.11867/j.issn.1001-8166.2008.06.0570
	ZHOU JIAN, LI XIN, WNAG GENXU, et al, 2008. Coupled land surface process pattern SIB2 with the unsaturated seepage model and its application[J]. Advances in Earth Science, 23(6): 570-579 (in Chinese with English abstract). doi: 10.11867/j.issn.1001-8166.2008.06.0570
[33]	周英杰, 刘艳伟, 黄一峰, 等, 2023. 生物质种类和添加量对肥液灌溉土壤入渗特征和养分运移的影响[J]. 华南农业大学学报, 44(4): 585-592.
	ZHOU YINGJIE, LI YANWEI, HUANG YIFENG, et al, 2023. Effects of biomass types and additions on soil infiltration characteristics and nutrient transport in fertilizer irrigation[J]. Journal of South China Agricultural University, 44(4): 585-592 (in Chinese with English abstract).
[34]	ABDEL-SATTAR M, AL-OBEED R S, AL-HAMED S A, et al, 2023. Experimental and modeling evaluation of impacts of different tillage practices on fitting parameters of Kostiakov’s cumulative infiltration empirical equation[J]. Water, 15(14): 2673.
[35]	AHANEKU I E, KALU R K, UGWU E C, 2015. Prediction accuracy of three infiltration equations for a sandy loam soil in Minna, Nigeria[J]. Journal of Agricultural Engineering and Technology, 23(1): 35-47.
[36]	ALEXANDRIS S, KERKIDES P, 2003. New empirical formula for hourly estimations of reference evapotranspiration[J]. Agricultural Water Management, 60(3): 157-180.
[37]	ALLEN R G, PEREIRA L S, RAES D, et al, 1998. Crop evapotranspiration: Guidelines for computing crop water requirements[M]. Rome: FAO:18- 64.
[38]	ALMEDEIJ J, ESEN I I, 2014. Modified Green-Ampt infiltration model for steady rainfall[J]. Journal of Hydrologic Engineering, 19(9): 04014011.
[39]	BAŞAKIN E E, EKMEKCIOĞLU Ö, ÖZGER M, 2023. Providing a comprehensive understanding of missing data imputation processes in evapotranspiration-related research: A systematic literature review[J]. Hydrological Sciences Journal, 68(14): 2089-2104.
[40]	BASTIAANSSEN W G M, MENENTI M, FEDDES R A, et al, 1998a. A remote sensing surface energy balance algorithm for land (SEBAL). 1. Formulation[J]. Journal of Hydrology, 212-213: 198-212.
[41]	BASTIAANSSEN W G M, PELGRUM H, WANG J, et al, 1998b. A remote sensing surface energy balance algorithm for land (SEBAL). : Part 2: Validation[J]. Journal of Hydrology, 212-213: 213-229.
[42]	BI YINLI, ZOU HUI, ZHU CHENWEI, 2014. Dynamic monitoring of soil bulk density and infiltration rate during coal mining in sandy land with different vegetation[J]. International Journal of Coal Science & Technology, 1(2): 198-206.
[43]	CAI JIABING, LIU YU, LEI TINGWU, et al, 2007. Estimating reference evapotranspiration with the FAO Penman-Monteith equation using daily weather forecast messages[J]. Agricultural and Forest Meteorology, 145(1-2): 22-35.
[44]	CHEN JIAHAO, BU JINGYI, SU YANXIN, et al, 2022. Urban evapotranspiration estimation based on anthropogenic activities and modified Penman-Monteith model[J]. Journal of Hydrology, 610: 127879.
[45]	DUAN RUNBIN, FEDLER C B, BORRELLI J, 2011. Field evaluation of infiltration models in lawn soils[J]. Irrigation Science, 29(5): 379-389.
[46]	GEBUL M A, 2022. Simplified approach for determination of parameters for Kostiakov's infiltration equation[J]. Water Practice & Technology, 17(11): 2435-2446.
[47]	GOMIS-CEBOLLA J, JIMENEZ J C, SOBRINO J A, et al, 2019. Intercomparison of remote-sensing based evapotranspiration algorithms over amazonian forests[J]. International Journal of Applied Earth Observation and Geoinformation, 80: 280-294.
[48]	HAO XINGMING, ZHANG SHUHUA, LI WEIHONG, et al, 2018. The uncertainty of Penman‐Monteith method and the energy balance closure problem[J]. Journal of Geophysical Research: Atmospheres, 123(14): 7433-7443.
[49]	HU GUOJIE, TIAN LIMING, ZHAO LIN, et al, 2018. Soil infiltration processes of different underlying surfaces in the permafrost region on the Tibetan Plateau[J]. Hydrological Sciences Journal, 63(11): 1733-1744.
[50]	JHA M K, MAHAPATRA S, MOHAN C, et al, 2019. Infiltration characteristics of lateritic vadose zones: Field experiments and modeling[J]. Soil and Tillage Research, 187: 219-234.
[51]	JOVIC S, NEDELJKOVIC B, GOLUBOVIC Z, et al, 2018. Evolutionary algorithm for reference evapotranspiration analysis[J]. Computers and Electronics in Agriculture, 150: 1-4.
[52]	KHALID M B, ARSHAD M, SHAKOOR A, et al, 2018. Embedment of sandy soil to increase surface irrigation efficiency and crop yield under modeling and experimental approach[J]. Journal of Global Innovations in Agricultural Sciences, 6(3): 88-93.
[53]	KHAN M S, LIAQAT U W, BAIK J, et al, 2018. Stand-alone uncertainty characterization of GLEAM, GLDAS and MOD16 evapotranspiration products using an extended triple collocation approach[J]. Agricultural and Forest Meteorology, 252: 256-268.
[54]	KUMAR M, RAGHUWANSHI N S, SINGH R, et al, 2002. Estimating evapotranspiration using artificial neural network[J]. Journal of Irrigation and Drainage Engineering, 128(4): 224-233.
[55]	LANG DENGXIAO, ZHENG JIANGKUN, SHI JIAQI, et al, 2017. A comparative study of potential evapotranspiration estimation by eight methods with FAO Penman-Monteith method in southwestern China[J]. Water, 9(10): 734.
[56]	LI JUN, WANG ZHONGGEN, LIU CHANGMING, 2015. A combined rainfall infiltration model based on Green-Ampt and SCS‐curve number[J]. Hydrological Processes, 29(11): 2628-2634.
[57]	MEIN R G, LARSON C L, 1973. Modeling infiltration during a steady rain[J]. Water Resources Research, 9(2): 384-394.
[58]	MONTEITH J L, 1965. Evaporation and environment[J]. Symposia of the Society for Experimental Biology, 19: 205-234. pmid: 5321565
[59]	OGBE V B, JAYEOBA O J, ODE S O, 2011. Comparison of four soil infiltration models on a sandy soil in Lafia, southern Guinea Savanna Zone of Nigeria[J]. Production Agriculture and Technology, 7(2): 116-126.
[60]	PAN SHUFEN, PAN NAIQING, TIAN HANQIN, et al, 2020. Evaluation of global terrestrial evapotranspiration using state-of-the-art approaches in remote sensing, machine learning and land surface modeling[J]. Hydrology and Earth System Sciences, 24(3): 1485-1509.
[61]	PENMAN H L, 1948. Natural evaporation from open water, bare soil and grass[J]. Proceedings of the Royal Society A Mathematical, Physical and Engineering Sciences, 193(1032): 120-145.
[62]	PEREIRA A R, 2004. The Priestley-Taylor parameter and the decoupling factor for estimating reference evapotranspiration[J]. Agricultural and Forest Meteorology, 125(3-4): 305-313.
[63]	VAN DEN PUTTE A, GOVERS G, LEYS A, et al, 2013. Estimating the parameters of the Green-Ampt infiltration equation from rainfall simulation data: Why simpler is better[J]. Journal of Hydrology, 476: 332-344.
[64]	WEI GUANGFEI, CAO JINGJING, XIE HUA, et al, 2022. Spatial-temporal variation in paddy evapotranspiration in subtropical climate regions based on the SEBAL model: A case study of the Ganfu Plain irrigation system, southern China[J]. Remote Sensing, 14(5): 1201.
[65]	YANG QING, MA ZHUGUO, ZHENG ZIYAN, et al, 2017. Sensitivity of potential evapotranspiration estimation to the Thornthwaite and Penman-Monteith methods in the study of global drylands[J]. Advances in Atmospheric Sciences, 34(12): 1381-1394.
[66]	YANG XIAOFENG, ZHANG YIMENG, JIA JUNCHAO, et al, 2022. Soil reclamation models by soil water infiltration for refuse dumps in opencast mining area of northern China[J]. Sustainability, 14(23): 15929.

土层深度/cm	砂粒(0.05~2mm)含量/%	粉粒(0.002~0.05mm)含量/%	黏粒(<0.002mm)含量/%	参考文献
0~20	93.3	5.7	0.9	王瑞等(2011)
20~50	97.6	0.8	1.6	王瑞等(2011)
0~25	98.74	1.26	0	韩生生等(2021)
25~40	99.05	0.95	0
40~240	100	0	0
0~20	71.9	25	3.1	杨安富等(2022)
20~30	77.5	18.3	4.2
30~100	98.8	0.8	0.4

风速区间/(mm·s^-1)	风力等级	量化值
0~0.2	0	0
0.3~1.5	1	1
1.6~3.3	2	2
3.4~5.4	3	3
5.5~7.9	4	4
8~10.7	5	5
10.8~13.8	6	6

云量区间/%	天气情况	天气类型指数
0~20	雨天	0.1
20~40	阴天	0.3
40~60	多云	0.5
60~80	晴转多云	0.7
80~100	晴天	0.9

来源	砂粒/%	粉粒/%	黏粒/%	容重/(g·cm^-3)	备注
本研究	>95	<5		1.3
Duan等 (2011)	94	4	2	无相关信息
Ogbe等 (2011)实验(1)	88	3.4	8.6	1.46	0~15cm
Ogbe等 (2011)实验(1)	90	3.4	6.6	1.43	15~30cm
Ogbe等 (2011) 实验(2)	90	1.4	8.6	1.74	0~15cm
Ogbe等 (2011) 实验(2)	92	1.4	6.6	1.75	15~30cm
Ogbe等 (2011) 实验(3)	88	1.4	10.6	1.41	0~15cm
Ogbe等 (2011) 实验(3)	92	1.4	6.6	1.46	15~30cm
Bi等 (2014)	90	7	3	1.58
Ahaneku等 (2015) 实验(1)	87.1	9	3.9	1.6
Ahaneku等 (2015) 实验(2)	87.2	8.6	4.2	1.55
Khalid等 (2018)	90	7	3	无相关信息
Yang等 (2022)	90.33	2.66	7.01	无相关信息

时间	总降雨量/m³	雨强/(cm·min^-1)	沙滩入渗量/m³	裸土入渗量/m³
0~3h	2304.12	0.004	223.35	354.32
3~6h	35137.83	0.068	3406.06	5403.42
6~9h	2304.12	0.004	223.35	354.32
9~24h	0	0	0	0

Simulation study of the evapotranspiration and rainfall infiltration of islands and reefs in the South China Sea

RichHTML

PDF (PC)

Like

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 14

References 66

Related Articles 0

Metrics

Comments

Recommended 0

时间	地类	平均气温	最低气温	最高气温	风力等级	降水量
旱季	不透水面	0.599^*	0.491^*	0.656^*	-0.694^*	-0.277^*
	裸土	0.600^*	0.500^*	0.654^*	-0.649^*	-0.223^*
	植被	0.417^*	0.366^*	0.472^*	-0.469^*	-0.326^*
雨季	不透水面	0.642^*	0.609^*	0.582^*	-0.414^*	-0.423^*
	裸土	0.668^*	0.663^*	0.570^*	-0.284^*	-0.421^*
	植被	0.574^*	0.634^*	0.422^*	-0.010	-0.418^*
