两种蔷薇珊瑚骨骼微结构观察及钙化过程分析

doi:10.11978/2016015

Abstract

Abstract:

Montipora is the second species-rich scleractinian genus that is widely distributed in the Indo-Pacific Ocean. Montipora digitata and Montipora fragilis, two species of branching Montipora, from the South China Sea were selected in this study, and its skeletal microstructures and calcification processes were observed and analyzed using Scanning Electron Microscopy (SEM) combined with Energy Dispersive Spectrometer (EDS). The results showed that the two species of Montipora skeletal basic elements were substantially the same (including calice, septum, theca, dissepiment, etc.), but there were many differences in details. Coenosteum surface of M. digitata was glabrous and recticular formation with shorter spines (about 40 μm) and each calices (about 1 mm) were separated by big interval. The septa of the first cycle was poorly developed except that the shape of its direct septum was sheet. In addition, teeth along the margin of septa developed well and had flat shape. The coenosteum surface of M. fragilis was tuberculate and recticular formation with many small spines (about 100 μm) and irregular nodular ridge between the calices. Compared with M. digitata, the first-cycle septa of M. fragilis had degenerated teeth. Main ingredients of the two kinds of coral skeletons were aragonite crystals, with most being tufted-crystals and a few being pebble-crystals. EDS analysis showed that the components of calcium carbonate from the skeleton were not directly generated, but formed in the following four processes: 1) the calcium was concentrated to develop calcium point; 2) calcium combined with carbon and oxygen, and the content of carbon was higher than that of oxygen; 3) aragonite crystals tended to look regular, and the content of carbon decreased and that of oxygen increased; and 4) a lot of aragonite crystals gathered into sclerodermite in orderly arrangement to form mature skeleton.

Key words: Montipora digitata, Montipora fragilis, skeletal microstructure, calcification process

Taonian GENG, Xuemei YAO, Ying ZHANG, Xialing XIE, Min CUI, Daoming LIN. Skeletal microstructure observations and calcification process analysis of two species of Montipora[J].Journal of Tropical Oceanography, 2017, 36(1): 56-64.

Figures/Tables 8

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

Tab. 1

References 34

[1]	聂宝符, 梁美桃, 朱袁智, 等, 1991. 南海礁区现代造礁珊瑚类骨骼细结构的研究[M]. 北京: 中国科学技术出版社: 1-5.
[2]	施祺, 孙东怀, 张叶春, 2004. 珊瑚骨骼生长特征的数字影像分析[J]. 海洋通报, 23(4): 19-24.
	SHI QI, SUN DONGHUAI, ZHANG YECHUN, 2004. Digital image analysis of coral skeletal growth characteristics[J]. Marine Science Bulletin, 23(4): 19-24 (in Chinese with English abstract).
[3]	谢露华, 韦刚健, 2008. 南海北部滨珊瑚微结构的SEM分析及其对气候记录重建的意义[J]. 海洋地质与第四纪地质, 28(3): 1-8.
	XIE LUHUA, WEI GANGJIAN, 2008. SEM studies on the microstructure of Porites coral from the northern south china sea: implications for paleoclimate record reconstruction[J]. Marine Geology & Quaternary Geology, 28(3): 1-8 (in Chinese with English abstract).
[4]	叶承, 黄晖, 张成龙, 2013. 鹿角杯形珊瑚骨骼构造和显微结构的研究[J]. 热带海洋学报, 32(2): 102-111.
	YE CHENG, HUANG HUI, ZHANG CHENGLONG, 2013. Skeletal architecture and microstructure of calcifying coral Pocillopora damicornis[J]. Journal of Tropical Oceanography, 32(2): 102-111 (in Chinese with English abstract).
[5]	张爱华, 董明, 阮小林, 等, 2010. 稳定同位素示踪技术应用研究进展[J]. 中国卫生检验杂志, 20(10): 2652-2654.
[6]	张江勇, 余克服, 2008. 珊瑚骨骼生长研究评述[J]. 地质论评, 54(3): 362-372.
	ZHANG JIANGYONG, YU KEFU, 2008. Review on the study of coral skeletal growth[J]. Geological Review, 54(3): 362-372 (in Chinese with English abstract).
[7]	邹仁林, 2001. 中国动物志腔肠动物门珊瑚虫纲石珊瑚目造礁石珊瑚[M]. 北京: 科学出版社: 9-18.
[8]	ADAMIANO A, GOFFREDO S, DUBINSKY Z, et al, 2014. Analytical pyrolysis-based study on intra-skeletal organic matrices from Mediterranean corals[J]. Analytical and Bioanalytical Chemistry, 406(24): 6021-6033.
[9]	ALLEMAND D, TAMBUTTÉ É, GIRARD J P, et al, 1998. Organic matrix synthesis in the scleractinian coral Stylophora pistillata: role in biomineralization and potential target of the organotin tributyltin[J]. The Journal of Experimental Biology, 201(13): 2001-2009.
[10]	ALLISON N, COHEN I, FINCH A A, et al, 2014. Corals concentrate dissolved inorganic carbon to facilitate calcification[J]. Nature Communications, 5: 5741.
[11]	BARNES D J, 1970. Coral skeletons: an explanation of their growth and structure[J]. Science, 170(3964): 1305-1308.
[12]	BELCHER A M, WU X H, CHRISTENSEN R J, et al, 1996. Control of crystal phase switching and orientation by soluble mollusc-shell proteins[J]. Nature, 381(6577): 56-58.
[13]	BRYAN W H, HILL D, 1941. Spherulitic crystallization as a mechanism of skeletal growth in the Hexacorals[J]. Proceedings of the Royal Society of Queensland, 52(9): 78-91.
[14]	CLODE P L, MARSHALL A T, 2003. Variation in skeletal microstructure of the coral Galaxea fascicularis: effects of an aquarium environment and preparatory techniques[J]. The Biological Bulletin, 204(2): 138-145.
[15]	CUIF J P, DAUPHIN Y, GAUTRET P, 1997. Biomineralization features in scleractinian coral skeletons: source of new taxonomic criteria[J]. Boletin-Real Sociedad Espanola de Historia Natural: Sección Geológica, 92(1-4): 129-141.
[16]	DAUPHIN Y, CUIF J P, MASSARD P, 2006. Persistent organic components in heated coral aragonitic skeletons-implications for palaeoenvironmental reconstructions[J]. Chemical Geology, 231(1-2): 26-37.
[17]	FALINI G, ALBECK S, WEINER S, et al, 1996. Control of aragonite or calcite polymorphism by mollusk shell macromolecules[J]. Science, 271(5245): 67-69.
[18]	FALINI G, FERMANI S, GOFFREDO S, 2015. Coral biomineralization: a focus on intra-skeletal organic matrix and calcification[J]. Seminars in Cell & Developmental Biology, 46: 17-26.
[19]	GAUTRET P, CRUIT J P, FREIWALD A, 1997. Composition of soluble mineralizing matrices in zooxanthellate and non- zooxanthellate scleractinian corals: biochemical assessment of photosynthetic metabolism through the study of a skeletal feature[J]. Facies, 36(1): 189-194.
[20]	GOLDBERG W M, 2001. Desmocytes in the calicoblastic epithelium of the stony coral Mycetophyllia reesi and their attachment to the skeleton[J]. Tissue and Cell, 33(4): 388-394.
[21]	GOREAU T F, 1959. The physiology of skeleton formation in corals. I. A method for measuring the rate of calcium deposition by corals under different conditions[J]. The Biological Bulletin, 116(1): 59-75.
[22]	JELL J S, 1974. The microstructure of some scleractinian corals[C]//Proceedings of the Second International Coral Reef Symposium. Brisbane, Australia: Great Barrier Reef Committee, 2: 301-320.
[23]	JONES R J, HOEGH-GULDBERG O, 2001. Diurnal changes in the photochemical efficiency of the symbiotic dinoflagellates (Dinophyceae) of corals: photoprotection, photoinactivation and the relationship to coral bleaching[J]. Plant, Cell and Environment, 24(1): 89-99.
[24]	MASS T, DRAKE J L, HARAMATY L, et al, 2012. Aragonite precipitation by “proto-polyps” in coral cell cultures[J]. PLoS One, 7(4): e35049.
[25]	NOTHDURFT L D, WEBB G E, 2007. Microstructure of common reef-building coral genera Acropora, Pocillopora, Goniastrea and Porites: constraints on spatial resolution in geochemical sampling[J]. Facies, 53(1): 1-26.
[26]	OGILVIE M M, 1896. Microscopic and systematic study of madreporarian types of corals[J]. Philosophical Transactions of the Royal Society B: Biological Sciences, 187: 83-345.
[27]	SORAUF J E, 1972. Skeletal microstructure and microarchitecture in Scleractinia (Coelenterata)[J]. Palaeontology, 15(1): 88-107.
[28]	STOLARSKI J, 2003. Three-dimensional micro- and nanostructural characteristics of the scleractinian coral skeleton: a biocalcification proxy[J]. Acta Palaeontologica Polonica, 48(4): 497-530.
[29]	SUMIDA K, HU M, FURUKAWA S, et al, 2016. Structuralization of Ca2+-based metal-organic frameworks prepared via coordination replication of calcium carbonate[J]. Inorganic chemistry, 55(7): 3700-3705.
[30]	TAMBUTTÉ É, ALLEMAND D, MUELLER E, et al, 1996. A compartmental approach to the mechanism of calcification in hermatypic corals[J]. Journal of Experimental Biology, 199(5): 1029-1041.
[31]	TAMBUTTÉ É, ALLEMAND D, ZOCCOLA D, et al, 2007. Observations of the tissue-skeleton interface in the scleractinian coral Stylophora pistillata[J]. Coral Reefs, 26(3): 517-529.
[32]	WEINER S, ADDADI L, 1991. Acidic macromolecules of mineralized tissues: the controllers of crystal formation[J]. Trends in Biochemical Sciences, 16: 252-256.
[33]	WISE JR S W, 1970. Scleractinian coral exoskeletons: surface microarchitecture and attachment scar patterns[J]. Science, 169(3949): 978-980.
[34]	ZOCCOLA D, TAMBUTTÉ E, SÉNÉGAS-BALAS F, et al, 1999. Cloning of a calcium channel α1 subunit from the reef-building coral, Stylophora pistillata[J]. Gene, 227(2): 157-167.

元素	重量比				原子比
元素	A	B	C	D	A	B	C	D
C	0	34.61	20.10	18.13	0	57.83	36.32	28.30
O	0	17.10	30.09	49.89	0	21.46	40.81	58.45
Ca	79.05	38.16	38.76	26.65	92.28	19.11	20.98	12.47
I	20.95	10.12	11.06	5.33	7.72	1.60	1.89	0.79
