双船双方位角地震探测技术方法及应用效果

doi:10.11978/2017033

Abstract

Abstract:

In Dongsha slope of the South China Sea, shallow fracture and reefs are numerous. Shallow Cenozoic is composed of carbonate rocks. The internal structure of deep Mesozoic is complex, with a lot of fracture. The conventional single vessel narrow azimuth seismic section shows poor reflection quality in deep sea. Dual vessels can be used to design flexible observation geometry, such as dual-azimuth seismic exploration. For the same reflection point lighting, this method of dual-azimuth seismic exploration is better than the narrow azimuth detection beneath the high acoustic velocity layer and the steep dip angle layer. Through key technology research and development, the dual-azimuth seismic acquisition was carried out by using single source and two streamers on both sides. We successfully implemented the experiment for the deep target seismic exploration in the South China Sea.

Key words: dual-vessel seismic survey, dual-azimuth, observation geometry, acquisition parameter, synthetic array profile

CLC Number:

P715.3

Shuji YANG, Chenglong WEI, Zhongliang WU, Xielai LIU, Ce YANG, Cong WANG. Dual-azimuth seismic survey technology and application using dual vessels[J].Journal of Tropical Oceanography, 2018, 37(1): 98-104.

Figures/Tables 7

Fig. 1

Fig. 2

Tab. 1

Fig. 3

Fig. 4

Fig. 5

Fig. 6

References 13

[1]	胡家赋, 易峰, 薛玖红, 等, 2015. 双船地震实时状态观测系统设计与实现[J]. 海洋测绘, 35(5): 51-55.
	HU JIAFU, YI FENG, XUE JIUHONG, et al, 2015. Design and implementation of real-time state controlling system for dual-vessel seismic surveys[J]. Hydrographic Surveying and Charting, 35(5): 51-55 (in Chinese with English abstract).
[2]	靳春光, 王立明, 2013. ORCA海上综合导航系统的基本原理及应用[J]. 石油仪器, 27(5): 36-40.
	JIN CHUNGUANG, WANG LIMING, 2013. Advantageous characteristics and application of ORCA integrated navigation system[J]. Petroleum Instruments, 27(5): 36-40 (in Chinese with English abstract).
[3]	李欣, 尹成, 葛子建, 等, 2014. 海上地震采集观测系统研究现状与展望[J]. 西南石油大学学报(自然科学版), 36(5): 67-80.
	LI XIN, YIN CHENG, GE ZIJIAN, et al, 2014. Situation and prospects of offshore seismic survey geometry[J]. Journal of Southwest Petroleum University (Science & Technology Edition), 36(5): 67-80 (in Chinese with English abstract).
[4]	李艳青, 2014. 几种双船地震施工方法[J]. 物探装备, 24(5): 298-301.
	LI YANQING, 2014. Several kinds of operation methods for undershooting mode in marine exploration[J]. Equipment for Geophysical Prospecting, 24(5): 298-301 (in Chinese with English abstract).
[5]	韦成龙, 杨蜀冀, 关晓春, 等, 2014. 立体延迟气枪震源分析[J]. 石油地球物理勘探, 49(6): 1027-1033.
	WEI CHENGLONG, YANG SHUJI, GUAN XIAOCHUN, et al, 2014. A delayed up-down sub-array airgun source[J]. Oil Geophysical Prospecting, 49(6): 1027-1033 (in Chinese with English abstract).
[6]	曾宪军, 韦成龙, 翟继锋, 2013. 南海北部海域油气资源调查技术及其应用研究——双船折射/广角反射地震勘探研究[J]. 海洋技术, 32(2): 39-42.
	ZENG XIANJUN, WEI CHENGLONG, ZHAI JIFENG, 2013. Oil and gas resources investigation technique and its application in the northern area of the South China Sea — undershooting refractive wide-angle reflection seismic acquisition[J]. Ocean Technology, 32(2): 39-42 (in Chinese with English abstract).
[7]	郑贵洲, 董文观, 胡家赋, 等, 2015. 基于插件技术的双船实时状态观测系统设计与实现[J]. 海洋技术学报, 34(1): 94-99.
	ZHENG GUIZHOU, DONG WENGUAN, HU JIAFU, et al, 2015. Design and implementation of the double vessel real-time status observing system based on the plug-in technology[J]. Journal of Ocean Technology, 34(1): 94-99 (in Chinese with English abstract).
[8]	朱振华, 曾凡祥, 易峰, 2016. 地震勘探双船作业中导航系统配置简介[J]. 全球定位系统, 41(1): 106-109.
	ZHU ZHENHUA, ZENG FANXIANG, YI FENG, 2016. The introduction about configuration of navigation system in dual vessel seismic survey[J]. GNSS World of China, 41(1): 106-109 (in Chinese with English abstract).
[9]	HILL D, BROWN G, CAMPBELL R, et al, 2009. Survey design considerations for full azimuth acquisition using a single recording vessel[C]//Proceedings of the 11th International Congress of the Brazilian Geophysical Society. Salvador, Bahia, Brazil: Society of Exploration Geophysicists.
[10]	MANCINI F, FAIRHEAD S, KING A, 2010. Data quality uplift from a dual-azimuth acquisition offshore Libya[C]// Proceedings of the 2010 SEG Annual Meeting. Denver, Colorado: Society of Exploration Geophysicists.
[11]	MICHELL S, BILLETTE F J, SHARP J, et al, 2004. Taking advantage of dual-azimuth analysis for model building and imaging over Mad Dog[C]//Proceedings of the SEG Int'l Exposition and 74th Annual Meeting. Denver, Colorado: Society of Exploration Geophysicists.
[12]	MICHELL S, SHARP J, CHERGOTIS D, 2007. Dual-azimuth versus wide-azimuth technology as applied in subsalt imaging of Mad Dog Field — a case study[J]. The Leading Edge, 26(4): 470-478.
[13]	HUANG TONY, XU SHENG, WANG JUAN, et al, 2008. The benefit of TTI tomography for dual azimuth data in Gulf of Mexico[C]//Proceedings of the 2008 SEG Las Vegas Annual Meeting. Las Vegas, Nevada: Society of Exploration Geophysicists.

采集参数	“奋斗四号”船	“探宝号”船
两船相对位置	副船(前)	主船(后)
两船电缆道最小距离/m	2475	2475*
船偏线范围/m	±25	±25*
震源容量/m³	无	0.105
气枪压力/MPa	13.8	13.8*
放炮间隔/m	37.5	37.5*
震源深度/m	无	等效深度8.5m
激发延迟/ms	无	1&4子阵列延迟2ms
电缆道数	360	480
道间距/m	6.25	12.5
电缆深度/m	16	16
最小偏移距/m	2250	225
覆盖次数	30	80
