潮优型河口动力对水深变化的响应机制研究——以葡萄牙Guadiana河口为例*

doi:10.11978/2019037

Abstract

Abstract:

Quantifying the impacts of human-induced (such as dredging for navigational channels) or natural (such as global sea level rise) interventions on estuarine environment is an important issue for estuary and coastal studies. For given simplified geometry and dynamics, analytical models are capable of rapidly identify the influence of human-induced or natural interventions on estuarine environment, which are invaluable tools for exploring response of tidal dynamics to external forcing. In this study, a one-dimensional hydrodynamic analytical model was used to explore the response of tidal dynamics in terms of different constituents to variation of tidally averaged water depth (mimicking the channel dredging and deposition) in the Guadiana estuary in Portugal, building on previous studies on nonlinear frictional interaction between different tidal constituents. The results show that the influence of variable depth on tidal dynamics in the seaward reach (x=0-60 km) is stronger compared to that in the landward reach (x=60-78 km). In particular, the influence of variable depth on the predominant semi-diurnal tides (M₂, S₂, N₂) is larger than that on diurnal tides (K₁, O₁). Analytical results also indicate that the basic tidal dynamic pattern along the estuary is more or less the same for a less intensive dredging of less than 2 m, while the pattern may substantially change for an intensive dredging activity. In addition, the channel bed deposition will weaken the tidal dynamics with a decrease of tidal amplitude, velocity amplitude, tidal wave celerity, and the phase lag between velocity and the elevation also decreases.

Key words: tidal dynamics, channel dredging, channel deposition, analytical model, Guadiana estuary

CLC Number:

P731

ZHANG Ping, XIE Meifang, YANG Hao, CAI Huayang, Ou Suying, YANG Qingshu. Response of tidal dynamics to the variation of water depth: case study of Guadiana estuary in Portugal[J].Journal of Tropical Oceanography, 2020, 39(1): 1-11.

Figures/Tables 8

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Tab. 1

Fig. 6

Fig. 7

References 39

[1]	丁芮, 陈学恩, 曲念东 , 2016. 珠江口及邻近海域潮汐环流数值模拟Ⅱ——河口水交换和物质输运分析[J]. 中国海洋大学学报, 46(7):1-10.
	DING RUI, CHEN XUEEN, QU NIANDONG , 2016. Three-dimensional high-resolution numerical study of the tide and circulation in the Pearl River Estuary and its adjacent waters Part Ⅱ: estuarine mass transport and water exchange[J]. Periodical of Ocean University of China, 46(7):1-10 (in Chinese with English abstract).
[2]	李薇, 苏正华, 徐弋琅 , 等, 2018. 考虑泥沙减阻效应的潮波理论模型及其在钱塘江河口的应用[J]. 应用基础与工程科学学报, 26(5):954-964.
	LI WEI, SU ZHENGHUA, XU YILANG , et al, 2018. Analytical study of tidal wave movement based on sediment-induced drag reduction and its application to the Qiantang estuary[J]. Journal of Basic Science and Engineering, 26(5):954-964 (in Chinese with English abstract).
[3]	刘伟东, 张心凤, 蒋星科 , 2007. 珠海港高栏港区疏浚对港区泥沙回淤的影响分析[J]. 人民珠江, 28(2):15-16, 42.
	LIU WEIDONG, ZHANG XINFENG, JIANG XINGKE , 2007. Analysis of the dredging work influence on the siltation in Gaolan Area of Zhuhai Harbor[J]. Pearl River, 28(2):15-16, 42 (in Chinese with English abstract).
[4]	刘俊勇, 徐峰俊 , 2006. 广州港出海航道疏浚工程对珠江口水动力及河势稳定影响研究[J]. 人民珠江, 27(4):11-14.
	LIU JUNYONG, XU FENGJUN , 2006. Influence study of Guangzhou harbor seagoing waterway dredging work on the hydrodynamic situation and the river stability of the Pearl River Mouth[J]. Pearl River, 27(4):11-14 (in Chinese with English abstract).
[5]	庞启秀, 徐金环 , 2005. 河口疏浚对环境的影响[J]. 中国港湾建设, (2):8-10.
	PANG QIXIU, XU JINHUAN , 2005. Influence of estuarine dredging on environment[J]. China Harbour Engineering, (2):8-10 (in Chinese with English abstract).
[6]	郑志华, 徐碧华 , 2008. 航道疏浚中悬浮泥沙对海水水质和海洋生物影响的数值研究[J]. 上海船舶运输科学研究所学报, 31(2):105-110.
	ZHENG ZHIHUA, XU BIHUA , 2008. Numerical study of suspended particulate matter impact on sea water quality and marine creatures in process of waterway dredging[J]. Journal of SSSRI, 31(2):105-110 (in Chinese with English abstract).
[7]	AMIN M , 1983. On perturbations of harmonic constants in the Thames Estuary[J]. Geophysical Journal of the Royal Astronomical Society, 73(3):587-603
[8]	BONALDO D, BENETAZZO A, BERGAMASCO A , et al, 2014. Sediment transport modifications induced by submerged artificial reef systems: a case study for the Gulf of Venice[J]. Oceanological and Hydrobiological Studies, 43(1):7-20. doi: 10.2478/s13545-014-0112-4
[9]	CAI HUAYANG , 2014. A new analytical framework for tidal propagation in estuaries[D]. Delft, the Netherlands: Delft University of Technology.
[10]	CAI HUAYANG, TOFFOLON M, SAVENIJE H H G , 2016. An analytical approach to determining resonance in semi- closed convergent tidal channels[J]. Coastal Engineering Journal, 58(3):1650009.
[11]	CAI HUAYANG, HUANG JINGZHENG, NIU LIXIA , et al, 2018a. Decadal variability of tidal dynamics in the Pearl River Delta: spatial patterns, causes, and implications for estuarine water management[J]. Hydrological Processes, 32(25):3805-3819. doi: 10.1002/hyp.v32.25
[12]	CAI HUAYANG, MARCO T, SAVENIJE H H G , et al, 2018b. Frictional interactions between tidal constituents in tide-dominated estuaries[J]. Ocean Science, 14(4):769-782. doi: 10.5194/os-14-769-2018
[13]	CHANT R J, SOMMERFIELD C K, TALKE S A , 2018. Impact of channel deepening on tidal and gravitational circulation in a highly engineered estuarine basin[J]. Estuaries and Coasts, 41(6):1587-1600. doi: 10.1007/s12237-018-0379-6
[14]	CHERNETSKY A S, SCHUTTELAARS H M, TALKE S A , 2010. The effect of tidal asymmetry and temporal settling lag on sediment trapping in tidal estuaries[J]. Ocean Dynamics, 60(5):1219-1241. doi: 10.1007/s10236-010-0329-8
[15]	CODIGA D , 2000. "UTide" unified tidal analysis and prediction functions[M]. Environmental Decision Making for New Developments: An Alternative Approach.
[16]	DE JONGE V N, SCHUTTELAARS H M, VAN BEUSEKOM J E E , et al, 2014. The influence of channel deepening on estuarine turbidity levels and dynamics, as exemplified by the Ems estuary[J]. Estuarine, Coastal and Shelf Science, 139:46-59. doi: 10.1016/j.ecss.2013.12.030
[17]	DOODSON A T , 1924. Perturbations of Harmonic Tidal Constants[J]. Proceedings of the Royal Society A: Containing Papers of a Mathematical and Physical Character, 106(739):513-526.
[18]	DRONKERS J J , 1964. Tidal computations in rivers and coastal waters[M]. Amsterdam: North Holland Publishing Company.
[19]	ENSING E, DE SWART H E, SCHUTTELAARS H M , 2015. Sensitivity of tidal motion in well-mixed estuaries to cross-sectional shape, deepening, and sea level rise: an analytical study[J]. Ocean Dynamics, 65(7):933-950. doi: 10.1007/s10236-015-0844-8
[20]	FALCÃO M, SANTOS M N, DRAGO T , et al, 2009. Effect of artificial reefs (southern Portugal) on sediment-water transport of nutrients: importance of the hydrodynamic regime[J]. Estuarine, Coastal and Shelf Science, 83(4):451-459. doi: 10.1016/j.ecss.2009.04.028
[21]	FAMILKHALILI R, TALKE S A , 2016. The effect of channel deepening on tides and storm surge: a case study of Wilmington, NC[J]. Geophysical Research Letters, 43(17):9138-9147. doi: 10.1002/2016GL069494
[22]	FANG GUOHONG , 1987. Nonlinear effects of tidal friction[J]. Acta Oceanological Sinica, 6(S1):109-126.
[23]	GAREL E, PINTO L, SANTOS A , et al, 2009. Tidal and river discharge forcing upon water and sediment circulation at a rock-bound estuary (Guadiana estuary, Portugal)[J]. Estuarine, Coastal and Shelf Science, 84(2):269-281. doi: 10.1016/j.ecss.2009.07.002
[24]	GODIN G , 1991. Compact approximations to the bottom friction term, for the study of tides propagating in channels[J]. Continental Shelf Research, 11(7):579-589. doi: 10.1016/0278-4343(91)90013-V
[25]	GODIN G , 1999. The propagation of tides up rivers with special considerations on the upper saint Lawrence River[J]. Estuarine, Coastal and Shelf Science, 48(3):307-324. doi: 10.1006/ecss.1998.0422
[26]	HEAPS N S , 1978. Linearized vertically-integrated equations for residual circulation in coastal seas[J]. Deutsche Hydrografische Zeitschrift, 31(5):147-169.
[27]	INOUE R, GARRETT C , 2007. Fourier representation of quadratic friction[J]. Journal of Physical Oceanography, 37(3):593-610. doi: 10.1175/JPO2999.1
[28]	JALÓN-ROJAS I, SCHMID S, SOTTOLICHIO A , et al, 2016. Tracking the turbidity maximum zone in the Loire Estuary (France) based on a long-term, high-resolution and high-frequency monitoring network[J]. Continental Shelf Research, 117:1-11. doi: 10.1016/j.csr.2016.01.017
[29]	JAY D A, LEFFLER K, DEGENS S , 2011. Long-term evolution of Columbia River tides[J]. Journal of Waterway, Port, Coastal, and Ocean Engineering, 137(4):182-191. doi: 10.1016/j.envpol.2017.10.003 pmid: 29037494
[30]	JEFFREYS H S , 1970. The earth: its origin, history and physical constitution[M]. 4th ed. London: Cambridge University Press.
[31]	PINGREE R D , 1983. Spring tides and quadratic friction[J]. Deep Sea Research Part A. Oceanographic Research Papers, 30(9):929-944.
[32]	PRANDLE D , 1997. The influence of bed friction and vertical eddy viscosity on tidal propagation[J]. Continental Shelf Research, 17(11):1367-1374. doi: 10.1016/S0278-4343(97)00013-7
[33]	RALSTON D K, TALKE S, GEYER W R , et al, 2019. Bigger tides, less flooding: effects of dredging on barotropic dynamics in a Highly Modified Estuary[J]. Journal of Geophysical Research: Oceans, 124(1):196-211. doi: 10.1029/2018JC014313
[34]	TALKE S A, DE SWART H E, DE JONGE V N , 2009. An idealized model and systematic process study of oxygen depletion in Highly Turbid Estuaries[J]. Estuaries and Coasts, 32(4):602-620. doi: 10.1007/s12237-009-9171-y
[35]	TOFFOLON M, SAVENIJE H H G , 2011. Revisiting linearized one-dimensional tidal propagation[J]. Journal of Geophysical Research: Oceans, 116(C7):C07007.
[36]	VELLINGA N E, HOITINK A J F, VAN DER VEGT M , et al, 2014. Human impacts on tides overwhelm the effect of sea level rise on extreme water levels in the Rhine-Meuse delta[J]. Coastal Engineering, 90:40-50. doi: 10.1016/j.coastaleng.2014.04.005
[37]	WINTERWERP J C , 2011. Fine sediment transport by tidal asymmetry in the high-concentrated Ems River: indications for a regime shift in response to channel deepening[J]. Ocean Dynamics, 61(2-3):203-215. doi: 10.1007/s10236-010-0332-0
[38]	WINTERWERP J C, WANG ZHENGBING, VAN BRAECKEL A , et al, 2013. Man-induced regime shifts in small estuaries—II: a comparison of rivers[J]. Ocean Dynamics, 63(11-12):1293-1306. doi: 10.1007/s10236-013-0663-8
[39]	ZHU JUN, WEISBERG R H, ZHENG LIANYUAN , et al, 2015. Influences of channel deepening and widening on the tidal and Nontidal Circulations of Tampa Bay[J]. Estuarine and Coast, 38(1):132-150.

		半日分潮			全日分潮
		M₂	N₂	S₂	K₁	O₁
流速参数(μ)	ψ₁/σ₁	-0.14/-35.89	-0.13/-39.92	-0.12/-39.07	-0.04/-21.07	-0.03/-18.30
	ψ₂/σ₂	0.04/10.74	0.06/17.90	0.05/16.36	0.002/0.78	-0.001/-0.36
	ψ₃/σ₃	0.06/14.76	0.10/30.82	0.08/27.34	-0.003/-1.75	-0.007/-3.49
	ψ₄/σ₄	0.02/4.99	0.10/31.15	0.08/25.88	-0.02/-12.55	-0.03/-14.48
潮波振幅衰减率参数(δ)	ψ₁/σ₁	-0.37/-15.95^*	-0.40/-3.01^*	-0.41/-2.91^*	-0.49/-4.87^*	-0.48/-5.16^*
	ψ₂/σ₂	0.13/5.66^*	0.17/1.259^*	0.17/0.18^*	0.12/-1.22^*	0.12/-1.23^*
	ψ₃/σ₃	0.22/9.46^*	0.30/2.27^*	0.29/2.10^*	0.19/1.93^*	0.18/1.92^*
	ψ₄/σ₄	0.29/12.36^*	0.44/3.32^*	0.43/3.04^*	0.25/2.47^*	0.23/2.45^*
波速参数(λ)	ψ₁/σ₁	0.28/28.96	0.28/24.86	0.30/25.90	0.56/46.13	0.60/48.86
	ψ₂/σ₂	-0.17/-16.81	-0.16/-14.14	-0.17/-14.67	-0.26/-21.12	-0.26/-21.57
	ψ₃/σ₃	-0.34/-34.19	-0.34/-30.07	-0.35/-30.87	-0.48/-39.70	-0.49/-40.23
	Ψ₄/σ₄	-0.67/-68.13	-0.732/-65.03	-0.75/-65.48	-0.87/-71.11	-0.87/-71.41
水位与流速之间的相位差(?)	ψ₁/σ₁	-9.50/-12.85	-11.84/-15.08	-12.45/-15.04	-1.50/-1.67	-1.07/-1.19
	ψ₂/σ₂	4.27/5.76	4.32/5.50	3.28/3.97	0.16/0.18	0.12/0.13
	ψ₃/σ₃	7.79/10.53	7.15/9.10	4.99/6.03	0.24/0.27	0.42/0.19
	ψ₄/σ₄	12.86/17.39	10.04/12.78	6.51/7.86	0.32/0.35	0.23/0.26
