XRF岩心扫描估算海洋沉积物有机碳含量的适用性

doi:10.11978/2021041

Abstract

Abstract:

The Bromine (Br) intensity collected by the non-destructive X-ray fluorescence (XRF) core scanner has been used to estimate the content of organic carbon in marine sediment in high speeds. However, the accuracy of this estimation and the effectiveness of various calibration methods need to be carefully evaluated. In this study, two gravity cores from the Arabian Sea and South China Sea, where the organic contents and their source components are different in sediment, are selected to investigate the correlation between the total organic carbon (TOC) content and the Br intensity by the core scanner. This study also analyzes the influence of water content and evaluates the effectiveness of different calibration methods used to estimate the TOC content according to the Br intensity. A good correlation is found between the Br intensity and the TOC in marine sediment with high organic carbon contents, no matter whether the Br intensity is calibrated or not. However, the estimation of sedimentary TOC content should be cautiously used when terrigenous organic matter is high.

Key words: core scanning techniques, Br counts, total organic carbon content, estimation

CLC Number:

P736.21

WU Lanjun, LI Gang. The estimation of organic contents in marine sediments based on bromine intensity by the XRF scanner[J].Journal of Tropical Oceanography, 2022, 41(2): 112-120.

Figures/Tables 7

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

References 39

[1]	谢永清, 龙江平, 乔吉果, 等, 2013. 运用岩芯扫描仪划分沉积相的可行性分析[J]. 热带海洋学报, 32(4): 30-35.
	XIE YONGQING, LONG JIANGPING, QIAO JIGUO, et al, 2013. Feasibility of sedimentary facies discrimination by core scanner[J]. Journal of Tropical Oceanography, 32(4): 30-35 (in Chinese with English Abstract).
[2]	BERG R D, SOLOMON E A, 2016. Geochemical constraints on the distribution and rates of debromination in the deep subseafloor biosphere[J]. Geochimica et Cosmochimica Acta, 174: 30-41. doi: 10.1016/j.gca.2015.11.003
[3]	BURNETT A P, SOREGHAN M J, SCHOLZ C A, et al, 2011. Tropical East African climate change and its relation to global climate: a record from Lake Tanganyika, Tropical East Africa, over the past 90+ kyr[J]. Palaeogeography, Palaeoclimatology, Palaeoecology, 303(1-4): 155-167. doi: 10.1016/j.palaeo.2010.02.011
[4]	CALEY T, ZARAGOSI S, BOURGET J, et al, 2013. Southern Hemisphere imprint for Indo-Asian summer monsoons during the last glacial period as revealed by Arabian Sea productivity records[J]. Biogeosciences, 10(11): 7347-7359. doi: 10.5194/bg-10-7347-2013
[5]	CALVERT S E, PRICE N B, 1999. Geochemistry of Namibian shelf sediments: coastal upwelling its sediment record, Part A: responses of the sedimentary regime to present coastal upwelling[R]. NATO ASI Series: Plenum Press: 337-375.
[6]	COWIE G L, MOWBRAY S, LEWIS M, et al, 2009. Carbon and nitrogen elemental and stable isotopic compositions of surficial sediments from the Pakistan margin of the Arabian Sea[J]. Deep Sea Research Part Ⅱ: Topical Studies in Oceanography, 56(6-7): 271-282.
[7]	CROUDACE I W, ROTHWELL R G, 2015. Micro-XRF studies of sediment cores[M]. New York: Springer: 373-390.
[8]	DEPLAZES G, LÜCKGE A, STUUT J B W, et al, 2014. Weakening and strengthening of the Indian monsoon during Heinrich events and Dansgaard-Oeschger oscillations[J]. Paleoceanography, 29(2): 99-114. doi: 10.1002/2013PA002509
[9]	DIRKSEN J P, HENNEKAM R, GEERKEN E, et al, 2019. A novel approach using time-depth distortions to assess multicentennial variability in deep-sea oxygen deficiency in the eastern Mediterranean Sea during Sapropel S5[J]. Paleoceanography and Paleoclimatology, 34(5): 774-786. doi: 10.1029/2018PA003458
[10]	FORTIN D, FRANCUS P, GEBHARDT A C, et al, 2013. Destructive and non-destructive density determination: method comparison and evaluation from the Laguna Potrok Aike sedimentary record[J]. Quaternary Science Reviews, 71: 147-153. doi: 10.1016/j.quascirev.2012.08.024
[11]	GE LIANGQUAN, LAI WANCHANG, LIN YANCHANG, 2005. Influence of and correction for moisture in rocks, soils and sediments on in situ XRF analysis[J]. X-Ray Spectrometry, 34(1): 28-34. doi: 10.1002/(ISSN)1097-4539
[12]	GREGORY B R B, PATTERSON R T, REINHARDT E G, et al, 2019. An evaluation of methodologies for calibrating Itrax X-ray fluorescence counts with ICP-MS concentration data for discrete sediment samples[J]. Chemical Geology, 521: 12-27. doi: 10.1016/j.chemgeo.2019.05.008
[13]	GRIBBLE G W, 1998. Naturally occurring organohalogen compounds[J]. Accounts of Chemical Research, 31(3): 141-152. doi: 10.1021/ar9701777
[14]	HANEBUTH T J J, HENRICH R, 2009. Recurrent decadal-scale dust events over Holocene western Africa and their control on canyon turbidite activity (Mauritania)[J]. Quaternary Science Reviews, 28(3-4): 261-270. doi: 10.1016/j.quascirev.2008.09.024
[15]	HE WEI, LIU JIANGUO, HUANG YUN, et al, 2020. Sea level change controlled the sedimentary processes at the Makran continental margin over the past 13,000 yr[J]. Journal of Geophysical Research: Oceans, 125(3): e2019JC015703.
[16]	HENDY I L, PEDERSEN T F, 2005. Is pore water oxygen content decoupled from productivity on the California Margin? Trace element results from ocean drilling program hole 1017E, San Lucia slope, California[J]. Paleoceanography, 20(4): PA4026.
[17]	HENNEKAM R, DE LANGE G, 2012. X-ray fluorescence core scanning of wet marine sediments: methods to improve quality and reproducibility of high-resolution paleoenvironmental records[J]. Limnology and Oceanography: Methods, 10(12): 991-1003. doi: 10.4319/lom.2012.10.991
[18]	HUNT J E, WYNN R B, MASSON D G, et al, 2011. Sedimentological and geochemical evidence for multistage failure of volcanic island landslides: a case study from Icod landslide on north Tenerife, Canary Islands[J]. Geochemistry, Geophysics, Geosystems, 12(12): Q12007.
[19]	HUNT J E, WYNN R B, TALLING P J, et al, 2013. Frequency and timing of landslide-triggered turbidity currents within the Agadir Basin, offshore NW Africa: are there associations with climate change, sea level change and slope sedimentation rates?[J]. Marine Geology, 346: 274-291. doi: 10.1016/j.margeo.2013.09.004
[20]	ITAMBI A C, VON DOBENECK T, MULITZA S, et al, 2009. Millennial-scale northwest African droughts related to Heinrich events and Dansgaard-Oeschger cycles: evidence in marine sediments from offshore Senegal[J]. Paleoceanography, 24(1): PA1205.
[21]	JIA GUODONG, PENG PINGAN, FANG DIANYONG, 2002. Burial of different types of organic carbon in core 17962 from South China Sea since the last glacial period[J]. Quaternary Research, 58(1): 93-100. doi: 10.1006/qres.2002.2346
[22]	JIAN ZHIMIN, WANG LUEJIANG, KIENAST M, et al, 1999. Benthic foraminiferal paleoceanography of the South China Sea over the last 40,000 years[J]. Marine Geology, 156(1-4): 159-186. doi: 10.1016/S0025-3227(98)00177-7
[23]	KANDASAMY S, LIN BAOZHI, LOU J Y, et al, 2018. Estimation of marine versus terrigenous organic carbon in sediments off southwestern Taiwan using the bromine to total organic carbon ratio as a proxy[J]. Journal of Geophysical Research: Biogeosciences, 123(10): 3387-3402. doi: 10.1029/2018JG004674
[24]	KIDO Y, KOSHIKAWA T, TADA R, 2006. Rapid and quantitative major element analysis method for wet fine-grained sediments using an XRF microscanner[J]. Marine Geology, 229(3-4): 209-225. doi: 10.1016/j.margeo.2006.03.002
[25]	KYLANDER M E, AMPEL L, WOHLFARTH B, et al, 2011. High resolution X‐ray fluorescence core scanning analysis of Les Echets (France) sedimentary sequence: new insights from chemical proxies[J]. Journal of Quaternary Science, 26(1): 109-117. doi: 10.1002/jqs.1438
[26]	LI GANG, RASHID H, ZHONG LIFENG, et al, 2018. Changes in deep water oxygenation of the South China Sea since the last glacial period[J]. Geophysical Research Letters, 45(17): 9058-9066. doi: 10.1029/2018GL078568
[27]	MARSHALL M H, LAMB H F, HUWS D, et al, 2011. Late pleistocene and holocene drought events at Lake Tana, the source of the Blue Nile[J]. Global and Planetary Change, 78(3-4): 147-161. doi: 10.1016/j.gloplacha.2011.06.004
[28]	MARTINEZ P, BERTRAND P, SHIMMIELD G B, et al, 1999. Upwelling intensity and ocean productivity changes off Cape Blanc (northwest Africa) during the last 70,000 years: geochemical and micropalaeontological evidence[J]. Marine Geology, 158(1-4): 57-74. doi: 10.1016/S0025-3227(98)00161-3
[29]	PEARCE T J, JARVIS I, 1995. High-resolution chemostratigraphy of Quaternary distal turbidites: a case study of new methods for the analysis and correlation of barren sequences[J]. Geological Society, London, Special Publications, 89: 107-143. doi: 10.1144/GSL.SP.1995.089.01.07
[30]	PEDERSEN T F, PRICE N B, 1980. The geochemistry of iodine and bromine in sediments of the Panama Basin[J]. Journal of Marine Research, 38(3): 397-411.
[31]	PHEDORIN M A, GOLDBERG E L, 2005. Prediction of absolute concentrations of elements from SR XRF scan measurements of natural wet sediments[J]. Nuclear Instruments and Methods in Physics Research Section A: Accelerators, Spectrometers, Detectors and Associated Equipment, 543(1): 274-279. doi: 10.1016/j.nima.2005.01.240
[32]	REBOLLEDO L, SEPÚLVEDA J, LANGE C B, et al, 2008. Late Holocene marine productivity changes in Northern Patagonia- Chile inferred from a multi-proxy analysis of Jacaf channel sediments[J]. Estuarine, Coastal and Shelf Science, 80(3): 314-322. doi: 10.1016/j.ecss.2008.08.016
[33]	REICHART G J, LOURENS L J, ZACHARIASSE W J, 1998. Temporal variability in the northern Arabian Sea oxygen minimum zone (OMZ) during the last 225,000 years[J]. Paleoceanography, 13(6): 607-621. doi: 10.1029/98PA02203
[34]	SCHULTE S, MANGELSDORF K, RULLKÖTTER J, 2000. Organic matter preservation on the Pakistan continental margin as revealed by biomarker geochemistry[J]. Organic Geochemistry, 31(10): 1005-1022. doi: 10.1016/S0146-6380(00)00108-X
[35]	SEKI A, TADA R, KUROKAWA S, et al, 2019. High-resolution Quaternary record of marine organic carbon content in the hemipelagic sediments of the Japan Sea from bromine counts measured by XRF core scanner[J]. Progress in Earth and Planetary Science, 6(1): 1-12. doi: 10.1186/s40645-018-0244-z
[36]	TJALLINGII R, RÖHL U, KÖLLING M, et al, 2007. Influence of the water content on X-ray fluorescence core-scanning measurements in soft marine sediments[J]. Geochemistry, Geophysics, Geosystems, 8(2): Q02004.
[37]	VAN PÉE K H, 1996. Biosynthesis of halogenated metabolites by bacteria[J]. Annual Review of Microbiology, 50: 375-399. doi: 10.1146/micro.1996.50.issue-1
[38]	WELTJE G J, TJALLINGII R, 2008. Calibration of XRF core scanners for quantitative geochemical logging of sediment cores: theory and application[J]. Earth and Planetary Science Letters, 274(3-4): 423-438. doi: 10.1016/j.epsl.2008.07.054
[39]	ZIEGLER M, JILBERT T, DE LANGE G J, et al, 2008. Bromine counts from XRF scanning as an estimate of the marine organic carbon content of sediment cores[J]. Geochemistry, Geophysics, Geosystems, 9(5): Q05009.
