基于实测数据的台湾海峡中部波浪特征分析 *

doi:10.11978/2020035

Abstract

Abstract:

Using the measured wave data in 2017 in the central Taiwan Strait, we analyze the basic features of wave, including spectral features, and their relationships with wind. The regression relationship among important characteristic wave parameters and the appropriate wave spectrum form are also investigated. The results are as follows. 1) The most frequently occurring wave direction is NE, and the strong wave direction is NNE. The monthly average significant wave height varies from 0.87 to 2.98 m. The wave height is the smallest in July and the highest in December. The wave period has similar inter-month change to wave height. 2) Mixed waves dominated by wind wave and single-peaked spectra make up the majority. The wave height is positively correlated with the wind speed as a whole. Strong wave is mainly generated by typhoons and strong northeast monsoon. 3) There are good linear correlations between mean wave period and most characteristic period parameters. The significant wave height and its corresponding wave period are strongly linearly related in the directions of NNE and NE. 4) Compared with the Jonswap spectrum, the Code spectrum 1 is more reasonable for the fitting of sea wave spectrum in this area. A spectrum in the form of Code spectrum 1 is given, which is fitted by significant wave height and spectral peak period. These results can provide references for ocean engineering design and numerical simulation of wave.

Key words: Taiwan Strait, wave characteristics, wave spectrum, wave parameter, fitting analysis

CLC Number:

P731.22

XU Xiao, TAO Aifeng, LI Xueding, ZHENG Xiangjing, LIN Yinan. Analysis of Wave Characteristics in the Central Taiwan Strait Based on Measured Data[J].Journal of Tropical Oceanography, 2021, 40(1): 12-20.

Figures/Tables 8

Fig. 1

Fig. 2

Tab. 1

Tab. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

References 21

[1]	陈剑桥, 2018. 三种典型路径下的台湾海峡台风浪特征研究[J]. 海洋预报, 35(6):1-12.
	CHEN JIANQIAO, 2018. Study on the characteristics of typhoon waves under three typical paths in Taiwan Strait[J]. Marine Forecasts, 35(6):1-12 (in Chinese with English abstract).
[2]	冯卫兵, 彭向丽, 张少兰, 2009. 南黄海近岸海域风浪统计分析[C]// 第十四届中国海洋(岸)工程学术讨论会论文集(上). 呼和浩特: 中国海洋工程学会(in Chinese).
[3]	冯兴如, 李近元, 尹宝树, 等, 2018. 海南东方近岸海域海浪观测特征研究[J]. 热带海洋学报, 37(3):1-8.
	FENG XINGRU, LI JINYUAN, YIN BAOSHU, et al, 2018. Characteristics of ocean waves in coastal area of Dongfang, Hainan Island based on observations[J]. Journal of Tropical Oceanography, 37(3):1-8 (in Chinese with English abstract).
[4]	郭婷婷, 高文洋, 高艺, 等, 2010. 台湾海峡气候特点分析[J]. 海洋预报, 27(1):53-58.
	GUO TINGTING, GAO WENYANG, GAO YI, 2010. An analysis of the climate characteristics for Taiwan Strait[J]. Marine Forecasts, 27(1):53-58 (in Chinese with English abstract).
[5]	黄必桂, 石新刚, 谢波涛, 等, 2016. 基于实测资料的南海海浪周期关系研究[J]. 海洋学研究, 34(3):6-10.
	HUANG BIGUI, SHI XINGANG, XIE BOTAO, et al, 2016. Study on the relationships of ocean wave periods in the South China Sea based on the observed data[J]. Journal of Marine Sciences, 34(3):6-10 (in Chinese with English abstract).
[6]	李水清, 赵栋梁, 2012. 风浪和涌浪分离方法的比较[J]. 海洋学报, 34(2):23-29.
	LI SHUIQING, ZHAO DONGLIANG, 2012. Comparisons on partitioning techniques to identify wind-wave and swell[J]. Acta Oceanologica Sinica, 34(2):23-29 (in Chinese with English abstract).
[7]	林伊楠, 陶爱峰, 李雪丁, 等, 2019. 台湾海峡风涌浪分离方法研究[J]. 海洋学报, 41(11):25-34.
	LIN YI’NAN, TAO AIFENG, LI XUEDING, et al, 2019. Study on separation method of wind-wave and swell in the Taiwan Strait[J]. Acta Oceanologica Sinica, 41(11):25-34 (in Chinese with English abstract).
[8]	祁祥礼, 郑向阳, 谌业良, 2018. 渤海湾中部波浪特征分析[J]. 水道港口, 39(3):288-293.
	QI XIANGLI, ZHENG XIANGYANG, SHEN YELIANG, 2018. Analysis of wave characteristic in the middle part of the Bohai Bay[J]. Journal of Waterway and Harbor, 39(3):288-293 (in Chinese with English abstract).
[9]	谢辛, 李燕初, 阮海林, 等, 2013. 基于T/P卫星高度计资料的台湾岛周边海域风浪的分布和时间变化特征[J]. 应用海洋学学报, 32(1):102-107.
	XIE XIN, LI YANCHU, RUAN HAILIN, et al, 2013. Characteristic and temporal variations of the wind wave fields over the adjacent waters of Taiwan island based on T/P satellite altimeter data[J]. Journal of Applied Oceanography, 32(1):102-107 (in Chinese with English abstract).
[10]	杨斌, 张俊彪, 叶钦, 等, 2017. 杭州湾中部实测波谱特性分析[C]// 第十八届中国海洋(岸)工程学术讨论会论文集(上). 舟山: 中国海洋工程学会(in Chinese).
[11]	杨斌, 杨忠良, 叶钦, 等, 2018. 杭州湾中部实测波浪特性分析[J]. 海洋工程, 36(3):96-103.
	YANG BIN, YANG ZHONGLIANG, YE QIN, et al, 2018. Analysis on wave characteristics of central Hangzhou Bay[J]. The Ocean Engineering, 36(3):96-103 (in Chinese with English abstract).
[12]	袁凯瑞, 商少平, 谢燕双, 等, 2014. 台湾海峡台风浪的数值模拟[J]. 厦门大学学报(自然科学版), 53(3):413-417.
	YUAN KAIRUI, SHANG SHAOPING, XIE YANSHUANG, et al, 2014. The simulation of typhoon waves in Taiwan Strait[J]. Journal of Xiamen University (Natural Science), 53(3):413-417 (in Chinese with English abstract).
[13]	张国友, 张绪东, 俞慕耕, 2002. 台湾海区的风浪特点及分布规律[J]. 海洋通报, 21(1):23-30.
	ZHANG GUOYOU, ZHANG XUDONG, YU MUGENG, 2002. Characteristics and distribution pattern of wind and wave in sea area of Taiwan[J]. Marine Science Bulletin, 21(1):23-30 (in Chinese with English abstract).
[14]	郑崇伟, 陈璇, 李崇银, 2016. 台湾岛周边海域的波候观测[J]. 解放军理工大学学报(自然科学版), 17(5):473-479.
	ZHENG CHONGWEI, CHEN XUAN, LI CHONGYIN, 2016. Observation of wave climate in surrounding waters of Taiwan Island[J]. Journal of PLA University of Science and Technology (Natural Science Edition), 17(5):473-479 (in Chinese with English abstract).
[15]	中华人民共和国交通运输部, 2015. JTS 145-2015 港口与航道水文规范[S]. 北京: 人民交通出版社: 30-31.
	Ministry of Transport of the People's Republic of China, 2015. JTS 145-2015 Code of hydrology for harbour and waterway[S]. Beijing: People's Communications Press: 30-31(in Chinese).
[16]	FENG WEIBIN, YANG BIN, CAO HAIJING, et al, 2012. Study on wave spectra in south coastal waters of Jiangsu[J]. Applied Mechanics and Materials, 212- 213:193-200.
[17]	GERLING T W, 1992. Partitioning sequences and arrays of directional ocean wave spectra into component wave systems[J]. Journal of Atmospheric and Oceanic Technology, 9(4):444-458.
[18]	GODA Y, 1979. A review on statistical interpretation of wave data[J]. Report of the Port and Harbour Research Institute, 18(1):5-32.
[19]	HASSELMANN K, OLBERS D, 1973. Measurements of wind-wave growth and swell decay during the Joint North Sea Wave Project (JONSWAP)[J]. Ergänzung zur Deutches Hydrographisches Institut, A(8):1-95.
[20]	LONGUET-HIGGINS M S, 1952. On the statistical distribution of the heights of sea waves[J]. Journal of Marine Research, 11(3):245-266.
[21]	TAO AIFENG, YAN JIN, PEI YE, et al, 2017. Swells of the East China Sea[J]. Journal of Ocean University of China, 16(4):674-682.

	月份												全年
	1	2	3	4	5	6	7	8	9	10	11	12	全年
小浪频率/%	0.1	0.3	0.5	2.6	2.6	2.1	4.1	1.4	2.1	0.3	0.0	0	16.1
轻浪频率/%	1.6	1.2	2.3	2.5	2.3	4.5	3.5	5.2	3.1	0.4	0.5	0.5	27.6
中浪频率/%	3.4	2.4	3.9	2.0	3.6	1.8	0.6	1.8	2.0	2.5	3.9	2.6	30.5
大浪频率/%	3.2	3.6	1.8	0.6	0.0	0.0	0.3	0.2	1.1	4.3	2.8	4.1	22.0
巨浪频率/%	0.4	0.3	0.2	0.1	0.0	0.0	0.0	0.0	0.0	1.0	0.4	1.4	3.8

位置	测站	月均有效波高/m				月均平均周期/s				大浪频率/%
位置	测站	2月	5月	8月	11月	2月	5月	8月	11月	2月	5月	8月	11月
海峡以北	马祖	2.1	1.3	1.3	2.0	5.6	5.2	5.1	5.3	26	6	14	25
海峡中部	2号标	2.3	1.0	1.0	2.5	6.4	5.4	5.3	6.4	50	0	2	48
海峡以南	东沙岛	2	1.2	1.6	2.6	5.9	5.1	5.6	6.1	26	6	18	58
