面向典型海洋现象观测的水下滑翔机应用综述

doi:10.11978/2021066

Abstract

Abstract:

As a buoyancy-driven autonomous underwater observation platform, the underwater glider has characteristics of sustainability, robustness and autonomy. It is one of the important underwater vehicles to construct an ocean observation technology system. In this paper, the underwater glider's development history, operation mode and special sensors are introduced in detail. Based on the oceanographic literature at home and abroad, the application of underwater gliders for observing typical marine phenomena is summarized. The characteristics of the underwater glider, such as stability, long duration, high resolution, and low cost, meet the needs of long-time and carefully stereoscopic observations of mesoscale eddies, internal waves, turbulence, boundary flows, and fronts. The robustness and autonomy make it adapt to severe ocean conditions, such as typhoons, earthquakes and crude oil leakage before and after. The characteristics of stable operation and low noise also make it a good platform for acoustic monitoring and detection. Through comparative analysis and research on the application status of the underwater glider (networking) at home and abroad, we conclude that the sensor, data processing system and networking of the domestic underwater glider need to be further improved. Finally, we summarize and look forward to the application of underwater gliders for observing ocean phenomena at home and abroad.

Key words: underwater glider, ocean phenomenon, observation and detection, sensor

CLC Number:

P715

YANG Shaoqiong, CHENG Dan, CHEN Guangyao, LUO Chenyi, NIU Wendong, MA Wei, FA Shuai. Review on the application of underwater gliders for observing typical ocean phenomena[J].Journal of Tropical Oceanography, 2022, 41(3): 54-74.

Figures/Tables 16

Fig. 1

Tab. 1

Tab. 2

Application of underwater gliders for observing mesoscale eddies"

海域	时间	AUG类型	机构	中尺度涡相关	相关文献
巴伦支海	2017/7	Slocum	苏格兰海洋科学协会	水体特征	Porter et al, 2020
白令海峡	2017/8—9	Seaglider	华盛顿州太平洋海洋环境实验室	生产力	Ladd et al, 2020
加利福尼亚	2003/8—2009/1		加利福尼亚合作海洋渔业调查	与加利福尼亚海流关系	Pelland et al, 2013
阿拉斯加湾	2005/8—10		美国华盛顿大学	水体特征	Martin et al, 2009
夏威夷海	2005/2—7		美国伍兹霍尔海洋研究所	生产力	Nicholson et al, 2008
南海	2015/4—6	Seawing	自然资源部第二海洋研究所	垂直温盐、非对称湍流混合结构	Liu et al, 2019; Qi et al, 2020
	2017/7—8		中国科学院南海海洋研究所	三维结构	Shu et al, 2019
	2007—2017		中山大学	边缘海面温度锋面	Qiu et al, 2020
南海	2015/5	Petrel-II	中山大学	形状不对称原因	Qiu et al, 2019
	2017/7—8		天津大学	动力模型	Wang et al, 2020a
	2017/8—29		天津大学	三维结构、水下滑翔机组网最佳配置、源头	Li et al, 2018, 2019, 2020
塔斯曼海西部	2009—2010	Seaglider	悉尼海洋科学研究所	水体入侵	Baird and Ridgway, 2012
罗弗顿盆地中部	2012/7—2015/7	Seaglider	中国科学院南海海洋研究所	结构、演变	Yu et al, 2017
伊尔明格海	2006	Spray	美国斯克里普斯海洋研究所	结构和水文特征	Fan et al, 2013
拉布拉多海	2004/9		丹麦法罗海洋研究所	结构和水文特征	Hátún et al, 2007
拉布拉多海	2005/1		英国国家海洋中心	密度特征	Frajka—Williams et al, 2014
巴利阿里海域	2007/7—2008/6	Slocum	西班牙地中海高级研究院	温盐结构	Bouffard et al, 2010
	2009/12		西班牙地中海高级研究院	热通量交换	Ruiz et al, 2012
	2014/9—12		“Algerian Basin Circulation Unmanned Survey”观测项目	源头、演化及生产力	Cotroneo et al, 2016
利古里亚海	2010/7	Slocum	意大利国家海洋和实验地球物理研究所	与强风关系	Poulain et al, 2020
利古里亚海	2013/6	Slocum	挪威卑尔根大学	生产力	Bosse et al, 2017
利翁湾	2012—2015	Slocum	法国佩皮尼昂大学	源头	De Madron et al, 2017

Tab. 2

Fig. 2

Tab. 3

Fig. 3

Fig. 4

Tab. 4

Tab. 5

Fig. 5

Tab. 6

Application of underwater gliders for observing boundary current"

海域	时间	AUG类型	机构	边界流相关	相关文献
斯瓦尔巴群岛	2018/9—11	Seaglider	挪威卑尔根大学地球物理研究所	暖大西洋边界流	Kolås et al, 2020
美国南加州	2006—2009	Spray	美国斯克里普斯海洋研究所	加利福尼亚环流	Todd et al, 2011
吕宋海峡	2012/6—2013/6	Seaglider	美国华盛顿大学	黑潮	Lien et al, 2014
菲律宾海	2009/6—2014/1	Spray	美国斯克里普斯海洋研究所	北赤道洋流	Schönau et al, 2015
菲律宾东岸	2009/9—2013/10		棉兰老洋流观测项目	棉兰老洋流	Schönau et at, 2017
所罗门海	2007—2010		Consortium on the Ocean's Role in Climate	新几内亚海岸潜流	Davis et al, 2012
所罗门群岛	2005/7—10		新喀里多尼亚发展研究所	南赤道洋流	Gourdeau et al, 2008
秘鲁南部	2008/10—11	Slocum	法国索邦大学	秘鲁上升流	Pietri et al, 2013
美国北卡罗来纳州附近	2004—2009	Spray	美国伍兹霍尔海洋研究所	墨西哥湾流	Todd et al, 2016; Todd, 2017;
美国东海岸	2004—2020	Spray	美国麻省理工学院-伍兹霍尔海洋学院海洋学联合项目	墨西哥湾流	Heiderich et al, 2020
澳大利亚东南部	2008—2014	Slocum	澳大利亚新南威尔士大学	东澳大利亚洋流	Schaeffer et al, 2015
非洲东南海岸	2015/4	Seaglider	阿古拉斯大陆架滑翔机实验	阿古拉斯洋流	Krug et al, 2017
罗科尔深海高原	2014/6—2016/6	Seaglider	苏格兰海洋科学协会	北大西洋洋流	Houpert et al, 2018
印度洋塞舌尔丹尼斯岛	2018/3—6	Spray	美国伍兹霍尔海洋研究所	赤道环流	Todd, 2020a
加拉帕戈斯群岛西部	2013/10—2016/10	Spray	美国斯克利普斯海洋学研究所	赤道潜流、南赤道洋流	Rudnick et al, 2021
加拉帕戈斯群岛西部	2013/1—2016/12	Spray	美国麻省理工学院-伍兹霍尔海洋学院海洋学联合项目	赤道洋流系统	Jakoboski et al, 2020

Tab. 6

Fig. 6

Tab. 7

Application of underwater gliders for observing water quality and hydrology"

海域	时间	AUG类型	机构	水质特征	相关文献
南加州海岸	2006/9—10	Spray	美国斯克里普斯海洋研究所	叶绿素	Todd et al, 2009
南加州中部	2010/2—6	Slocum	美国宇航局戈达德航天飞行中心	浮游植物	Seegers et al, 2015
澳大利亚东南部	2008/7—12	Slocum	悉尼科技大学	叶绿素	Baird et al, 2011
冰岛南部	2008/4	Seaglider	美国伍兹霍尔海洋研究所	水华	Mahadevan et al, 2012
北海	2013		英国东安格利亚大学	温盐	Sheehan et al, 2020
凯尔特海	2015/4		英国南安普敦大学	硝酸盐	Vincent et al, 2018
波克潘深海平原	2012—2013		英国环境、渔业和水产养殖科学中心	水华	Binetti et al, 2020
维戈近海	2010/6—8		英国东安格利亚大学	浮游植物	Rollo et al, 2020
新泽西州	2006/4—9	Slocum	美国罗格斯大学	温盐季节变化	Castelao et al, 2008b
华盛顿州	2003/9—2007/12	Seaglider	美国缅因大学	水华	Perry et al, 2008
中大西洋湾	2003/10—2004/11	Slocum	美国罗格斯大学	温盐年际变化	Castelao et al, 2008a
中大西洋湾	2003/10	Slocum	美国罗格斯大学	水华	Schofield et al, 2008
中大西洋湾	2006/3—4、2007/7—10	Spray	美国伍兹霍尔海洋研究所	水平温盐变化	Todd et al, 2013
中大西洋湾	2006—2008	Slocum	美国罗格斯大学	水华	Xu et al, 2013
	2005			浮游植物	Xu et al, 2011
	2018/5—2019/11			碳酸盐	Wright et al, 2020
大西洋斯科舍陆架	2015	Slocum	加拿大达尔豪斯大学	浮游动物	Ruckdeschel et al, 2020
亚得里亚海坑	2013—2016	Seaglider、Slocum	意大利国家海洋和实验地球物理研究所	盐度变化	Kokkini et al, 2020
罗特尼斯岛	2009、2010、2011、2015、2016	Slocum	西澳大学海洋研究所	叶绿素	Chen et al, 2020
南极威德尔海	2012/1—3	Seaglider	英国东安格利亚大学	生产力	Biddle et al, 2015
北极白令海	2019/9	Petrel	天津大学	温度、溶解氧	杨绍琼等, 2021

Tab. 7

Fig. 7

Tab. 8

Fig. 8

References 149
