近50a来福建海坛海峡动力地貌演变过程

doi:10.11978/2022036

Abstract

Abstract:

The Haitan Strait in Fujian province is an important channel for the southward transportation of material from the Minjiang River and the Zhejiang-Fujian Coastal Current to the Xinghua Bay and the south-central coast of Fujian. The topographic data of the Haitan Strait in the past 50 years was analyzed using GIS tools. The results indicate that strong siltation occurred in the Haitan Strait due to the influence of several catastrophic floods in the Minjiang River Basin during 1964~1975. The Haitan Strait experienced strong erosion during 1975~1990 which is caused by water and soil conservation and reservoir constructions in the Minjiang River Basin. After that, the erosion rate declined gradually and the strait maintained slight scouring. Large-scale artificial sand mining started since 2007 that caused severe erosion in the northern part of the Strait. Before 2007, sediment discharge from the Minjiang River was the main factor restricting the geomorphological evolution of the Haitan Strait. Flood, sand mining and reservoir construction had a direct impact on the geomorphologic evolution of the strait. However, after 2007, large-scale artificial sand mining activities and reclamation projects in the strait have gradually become the main factors to affect its geomorphologic evolution.

Key words: the Haitan Strait, geomorphologic evolution, the Minjiang River, sand excavation

CLC Number:

P737.2

WANG Weibin, YAO Hongyi, YU Guangxin, ZHENG Chengzhong. Dynamic geomorphologic evolution of the Haitan Strait, Fujian province, in the past 50 years[J].Journal of Tropical Oceanography, 2022, 41(4): 105-115.

Figures/Tables 10

Fig. 1

Tab. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Tab. 2

Fig. 7

Fig. 8

References 20

[1]	陈坚, 余兴光, 李东义, 等, 2010. 闽江口近百年来海底地貌演变与成因[J]. 海洋工程, 28(2): 82-89.
	CHEN JIAN, YU XINGGUANG, LI DONGYI, et al, 2010. Characteristics of underwater morphology evolution of the Minjiang Estuary in recent 100 years and its reasons[J]. The Ocean Engineering, 28(2): 82-89. (in Chinese with English abstract)
[2]	高金耀, 金翔龙, 吴自银, 2003. 多波束数据的海底数字地形模型构建[J]. 海洋通报, 22(1): 30-38.
	GAO JINYAO, JIN XIANGLONG, WU ZIYIN, 2003. Construction of submarine DTM from raw multibeam data[J]. Marine Science Bulletin, 22(1): 30-38. (in Chinese with English abstract)
[3]	胡毅, 2011. 台湾海峡西侧近岸沉积及主要河流贡献研究[D]. 青岛: 中国海洋大学.
	HU YI, 2011. Sediment characters and major river contribution to the west side nearshore of the Taiwan Strait[D]. Qingdao: Ocean University of China. (in Chinese with English abstract)
[4]	里丁 H G, 1985. 沉积环境和相[M]. 北京: 科学出版社.
	READING H G, 1985. Sedimentary environments and facies[M]. Beijing: Science Press. (in Chinese)
[5]	刘胜璟, 高建华, 徐笑梅, 等, 2021. 浙闽沿岸泥质区沉积物粒度组分对长江入海输沙量减少的响应[J]. 海洋学报, 43(3): 105-115.
	LIU SHENGJING, GAO JIANHUA, XU XIAOMEI, et al, 2021. Response of sediment grain size composition of the Zhe-Min coastal mud to the sediment load reduction of the Changjiang River entering the sea[J]. Haiyang Xuebao, 43(3): 105-115. (in Chinese with English abstract)
[6]	卢惠泉, 蔡锋, 孙全, 2009a. 福建海坛海峡峡道动力地貌研究[J]. 台湾海峡, 28(3): 417-424.
	LU HUIQUAN, CAI FENG, SUN QUAN, 2009a. Study on the channel dynamic geomorphology of Haitan Strait, Fujian[J]. Journal of Oceanography in Taiwan Strait, 28(3): 417-424. (in Chinese with English abstract)
[7]	卢惠泉, 孙全, 2009b. 海坛海峡海缆路由区工程地质条件及评价[J]. 台湾海峡, 28(1): 96-101.
	LU HUIQUAN, SUN QUAN, 2009b. Evaluation of the engineering geology condition in Haitan Strait in Fujian, China[J]. Journal of Oceanography in Taiwan Strait, 28(1): 96-101. (in Chinese with English abstract)
[8]	邵恒方, 1993. 福建三大河流沙量及其变化分析[J]. 水文, (S1): 42-45. (in Chinese)
[9]	汤军健, 温生辉, 陈楚汉, 2006. 海坛海峡二维潮流场数值模拟[J]. 台湾海峡, 25(4): 533-540.
	TANG JUNJIAN, WEN SHENGHUI, CHEN CHUHAN, 2006. Numerical simulation of two-dimensional tidal current model for Haitan Strait[J]. Journal of Oceanography in Taiwan Strait, 25(4): 533-540. (in Chinese with English abstract)
[10]	汪家君, 1995. 近代历史海图与港口航道工程[J]. 海洋通报, (3): 11-18.
	WANG JIAJUN, 1995. Modern historic chart and port and waterway engineering[J]. Marine Science Bulletin, (3): 11-18. (in Chinese with English abstract)
[11]	吴承强, 2011. 福建近岸海域海底地貌研究[D]. 青岛: 中国海洋大学.
	WU CHENGQIANG, 2011. Study on submarine morphology of Fujian offshore[D]. Qingdao: Ocean University of China. (in Chinese with English abstract)
[12]	武晶, 2019. 闽江含沙量变化及其对下游河道影响的分析[J]. 水利科技, (2): 4-6. (in Chinese)
[13]	吴自银, 阳凡林, 罗孝文, 等, 2017. 高分辨率海底地形地貌: 探测处理理论与技术[M]. 北京: 科学出版社.
	WU ZIYIN, YANG FANLIN, LUO XIAOWEN, et al, 2017. High-resolution submarine geomorphology -theory and technology for surveying and post-processing[M]. Beijing: Science Press. (in Chinese)
[14]	徐勇航, 陈坚, 王爱军, 等, 2013. 台湾海峡表层沉积物中黏土矿物特征及物质来源[J]. 沉积学报, 31(1): 120-129.
	XU YONGHANG, CHEN JIAN, WANG AIJUN, et al, 2013. Clay minerals in surface sediments of the Taiwan Strait and their provenance[J]. Acta Sedimentologica Sinica, 31(1): 120-129. (in Chinese with English abstract)
[15]	杨留柱, 杨莉玲, 潘洪州, 等, 2019. 人类活动影响下的钦州湾近期滩槽冲淤演变特征[J]. 热带海洋学报, 38(6): 41-50.
	YANG LIUZHU, YANG LILING, PAN HONGZHOU, et al, 2019. Characteristics of recent evolution in Qinzhou Bay influenced by human activities[J]. Journal of Tropical Oceanography, 38(6): 41-50. (in Chinese with English abstract)
[16]	姚弘毅, 郑承忠, 徐乐, 等, 2018. 近期福建海坛海峡海床冲淤变化及影响因素研究[J]. 渔业研究, 40(5): 329-339.
	YAO HONGYI, ZHENG CHENGZHONG, XU LE, et al, 2018. Study on the recent topographic change in the Haitan Straight of Fujian Province and its influence factors[J]. Journal of Fisheries Research, 40(5): 329-339. (in Chinese with English abstract)
[17]	佚名, 1990. 福建省海岸带和海涂资源综合调查报告[M]. 北京: 海洋出版社. (in Chinese)
[18]	张章新, 2000. 闽江流域水文特性分析[J]. 水文, 20(6): 55-58.
	ZHANG ZHANGXIN, 2000. Analysis of hydrological characteristics of Minjiang River Basin[J]. Hydrology, 20(6): 55-58. (in Chinese with English abstract)
[19]	郑承忠, 1997. 福清湾北部及其以东近岸海域沉积环境和沉积特征[J]. 台湾海峡, 16(4): 386-392.
	ZHENG CHENG ZHONG, 1997. Depositional environment and sedimentary characteristics in northern Fuqing Bay and its eastward coastal area[J]. Journal of Oceanography in Taiwan Strait, 16(4): 386-392. (in Chinese with English abstract)
[20]	DAI ZHIJUN, LIU J T, 2013. Impacts of large dams on downstream fluvial sedimentation: An example of the Three Gorges Dam (TGD) on the Changjiang (Yangtze River)[J]. Journal of Hydrology, 480: 10-18. doi: 10.1016/j.jhydrol.2012.12.003

序号	资料名称	图号	比例尺	投影	深度基准面	测量时间
1	海坛海峡峡部	10609	1:35000	墨卡托投影	当地理论最低潮位面	1964年
2	海坛海峡北部	14131	1:35000	墨卡托投影	当地理论最低潮位面	1975年
3	海坛海峡南部	14151	1:35000	墨卡托投影	当地理论最低潮位面	1975年
4	海坛海峡北部	14131	1:35000	墨卡托投影	当地理论最低潮位面	1990年
5	海坛海峡南部	14151	1:35000	墨卡托投影	当地理论最低潮位面	1990年
6	海坛海峡北部	14131	1:35000	墨卡托投影	当地理论最低潮位面	1999年
7	海坛海峡南部	14151	1:35000	墨卡托投影	当地理论最低潮位面	1999年
8	海坛海峡北部	14131	1:35000	墨卡托投影	当地理论最低潮位面	2007年
9	海坛海峡南部	14151	1:35000	墨卡托投影	当地理论最低潮位面	2007年
10	海坛海峡北部	14131	1:35000	墨卡托投影	当地理论最低潮位面	2015年
11	海坛海峡南部	14151	1:35000	墨卡托投影	当地理论最低潮位面	2015年

时间段	淤积面积/km²	冲刷面积/km²	净冲淤量/(×10⁸m³)	年均冲淤量/(×10⁷m³)	年均冲淤厚度/cm
1964—1975年	150	74	1.15	1.05	4.68
1975—1990年	89	135	-1.31	-0.88	-3.93
1990—1999年	102	122	-0.23	-0.25	-1.12
1999—2007年	111	113	-0.25	-0.31	-1.37
2007—2015年	93	131	-0.88	-1.10	-4.95
1964—2015年	90	134	-1.51	-0.30	-1.32
