台风季节朱家尖岛砂、砾质岬湾海滩的不同沉积地貌动态变化

doi:10.11978/2021091

Abstract

Abstract:

The embayed sandy and gravel beaches are important tourism resources in the coastal zone of islands, with high socio-economic and ecological values and having received study attention for years. This study focuses on five representative embayed beaches on the east coast of the Zhujiajian Island in Zhejiang Province. The beach topography and sediment data were obtained from three field campaigns in the early, middle and late stages of the 2019 typhoon season, and the nearshore hydrodynamic data were also collected and analyzed. Then, the dynamic changes of topography and sediment characteristics of five different embayed beaches were detected. The results show that the five beaches experienced different volume changes during the typhoon season, i.e., 11.93 m³·m^-1(Dashali), -54.41 m³·m^-1(Dongsha), -19.75 m³·m^-1(Qiansha), 2.19 m³·m^-1(Wushitang) and -1.96 m³·m^-1(Xiaowushitang), respectively. The gravel beaches were more stable than the sandy beaches, and the sandy beach without human activity is less eroded during the typhoon season. The mean grain size of surficial sediments on Dashali, Dongsha, Qiansha, Wushitang and Xiaowushitang during the typhoon season are 2.47 Փ, 2.24 Փ, 2.64 Փ, -5.96 Փ and -6.03 Փ, respectively, with coarsening and onshore transport being the main performances of their changes. The change of sediment grain size on sandy beaches is more significant than that on the gravel beaches. The sediment grain size, the energy level of typhoon, and the angle between the main wave direction during the typhoon and the beach orientation, and coastal engineering can have impacts on beach morphological variation during typhoon seasons. This research can provide reference for the beach management during typhoon seasons.

Key words: embayed beaches, profile morphology, grain size characteristics, human activities, typhoon season

CLC Number:

P737.13

GUO Junli, SHI Lianqiang, CHEN Shenliang, ZHANG Min, CHANG Yang, ZHANG Daheng. Dynamic variations of different sedimentary geomorphology of sandy and gravel embayed beaches on the Zhujiajian Island during typhoon season[J].Journal of Tropical Oceanography, 2022, 41(4): 82-96.

Figures/Tables 13

Fig. 1

Tab. 1

Fig. 2

Fig. 3

Tab. 2

Fig. 4

Fig. 5

Tab. 3

Fig. 6

Fig. 7

Fig. 8

Tab. 4

Tab. 5

References 50

[1]	蔡锋, 苏贤泽, 夏东兴, 2004. 热带气旋前进方向两侧海滩风暴效应差异研究——以海滩对0307号台风“伊布都”的响应为例[J]. 海洋科学进展, 22(4): 436-445.
	CAI FENG, SU XIANZE, XIA DONGXING, 2004. Study on the difference between storm effects of beaches on two sides of the tropical cyclone track-Taking the responses of beaches to No. 0307 typhoon Imbudo as an example[J]. Advances in Marine Science, 22(4): 436-445 (in Chinese with English abstract)
[2]	蔡锋, 刘根, 2019. 我国海滩养护修复的发展与技术创新[J]. 应用海洋学学报, 38(4): 452-463.
	CAI FENG, LIU GEN, 2019. Beach nourishment development and technological innovations in China: An overview[J]. Journal of Applied Oceanography, 38(4): 452-463. (in Chinese with English abstract)
[3]	陈洪德, 严钦尚, 项立嵩, 1982. 舟山朱家尖岛现代海岸沉积[J]. 华东师范大学学报(自然科学版), (2): 77-91.
	CHEN HONGDE, YAN QINSHANG, XIANG LISONG, 1982. Recent coastal sediments of Zhujiajian Island, Zhoushan Archipelago[J]. Journal of East China Normal University (Natural Science Edition), (2): 77-91. (in Chinese with English abstract)
[4]	程林, 时连强, 夏小明, 等, 2014. 浙江朱家尖岛东沙海滩沉积与地貌动态变化[J]. 海洋地质与第四纪地质, 34(1): 37-44.
	CHENG LIN, SHI LIANQIANG, XIA XIAOMING, et al, 2014. Sedimentation and recent morphological changes at Dongsha beach, Zhujiajian Island, Zhejiang Province[J]. Marine Geology and Quaternary Geology, 34(1): 37-44. (in Chinese with English abstract)
[5]	程武风, 陈沈良, 胡进, 2017. 海南万宁岬湾海岸海滩稳定性研究[J]. 海洋工程, 35(1): 121-128.
	CHENG WUFENG, CHEN SHENLIANG, HU JIN, 2017. Stability of headland bay beaches on the east coast of Hainan Island[J]. The Ocean Engineering, 35(1): 121-128. (in Chinese with English abstract)
[6]	戴志军, 陈子燊, 张清凌, 2001. 波控岬间海滩剖面短期变化过程分析[J]. 热带地理, 21(3): 266-269.
	DAI ZHIJUN, CHEN ZISHEN, ZHANG QINGLING, 2001. An analysis on temporal variation process of a wave-dominated beach profile between headlands[J]. Tropical Geography, 21(3): 266-269. (in Chinese with English abstract)
[7]	戴志军, 李春初, 王文介, 等, 2006. 华南弧形海岸的分形和稳定性研究[J]. 海洋学报, 28(1): 176-180.
	DAI ZHIJUN, LI CHUNCHU, WANG WENJIE, et al, 2006. Research on stability and fractal of arc-shaped coast in South China[J]. Acta Oceanologica Sinica, 28(1): 176-180. (in Chinese with English abstract)
[8]	高抒, 贾建军, 杨阳, 等, 2019. 陆架海岸台风沉积记录及信息提取[J]. 海洋学报, 41(10): 141-160.
	GAO SHU, JIA JIANJUN, et al, 2019. Obtaining typhoon information from sedimentary records in coastal-shelf waters[J]. Haiyang Xuebao, 41(10): 141-160. (in Chinese with English abstract)
[9]	龚昊, 陈沈良, 钟小菁, 等, 2017. 海南岛东北部海滩侵蚀与恢复对连续台风的复杂响应[J]. 海洋学报, 39(5): 68-77.
	GONG HAO, CHEN SHENLIANG, ZHONG XIAOJING, et al, 2017. Complicated responses of beach erosion and restoration to consecutive typhoons along northeastern Hainan Island, China[J]. Haiyang Xuebao, 39(5): 68-77. (in Chinese with English abstract)
[10]	郭俊丽, 时连强, 童宵岭, 等, 2018. 浙江朱家尖岛东沙海滩对热带风暴“娜基莉”的响应及风暴后的恢复[J]. 海洋学报, 40(9): 137-147.
	GUO JUNLI, SHI LIANQIANG, TONG XIAOLING, et al, 2018. The response to tropical storm Nakri and the restoration of Dongsha beach in Zhujiajian Island, Zhejiang province[J]. Haiyang Xuebao, 40(9): 137-147. (in Chinese with English abstract)
[11]	郭俊丽, 时连强, 陈沈良, 等, 2019. 基于Argus图像的舟山东沙海滩对连续风暴的响应研究[J]. 海洋与湖沼, 50(4): 728-739.
	GUO JUNLI, SHI LIANQIANG, CHEN SHENLIANG, et al, 2019. Response of Dongsha beach in Zhoushan to continuous storms based on Argus images[J]. Oceanologia et Limnologia Sinica, 50(4): 728-739. (in Chinese with English abstract)
[12]	李志龙, 陈子燊, 2006. 岬间砂质海岸平衡形态模型及其在华南海岸的应用[J]. 台湾海峡, 25(1): 123-129.
	LI ZHILONG, CHEN ZISHEN, 2006. Equilibrium shape model of headland-bay and application in South China coasts[J]. Journal of Oceanography in Taiwan Strait, 25(1): 123-129. (in Chinese with English abstract)
[13]	束芳芳, 蔡锋, 戚洪帅, 等, 2019. 不同沉积物养护海滩对台风响应的差异性研究[J]. 海洋学报, 41(7): 103-115.
	SHU FANGFANG, CAI FENG, QI HONGSHUAI, et al, 2019. Study on various response to typhoon of nourished beaches with different sediments[J]. Haiyang Xuebao, 41(7): 103-115. (in Chinese with English abstract)
[14]	童宵岭, 时连强, 夏小明, 等, 2014. 1211号台风对浙江象山皇城海滩剖面的影响分析[J]. 海洋工程, 32(1): 84-90.
	TONG XIAOLING, SHI LIANQIANG, XIA XIAOMING, et al, 2014. Response of sedimentary and geomorphic characteristics to 1211 typhoon on Zhejiang Huangcheng beach[J]. The Ocean Engineering, 32(1): 84-90. (in Chinese with English abstract)
[15]	王爱军, 高抒, 杨旸, 2004. 浙江朱家尖岛砾石海滩沉积物分布及形态特征[J]. 南京大学学报(自然科学), 40(6): 747-759.
	WANG AIJUN, GAO SHU, 2004. Sediment distribution and shape characteristics of gravel beaches, Zhujiajian Island, Zhejiang province[J]. Journal of Nanjing University (Natural Sciences), 40(6): 747-759. (in Chinese with English abstract)
[16]	夏小明, 2014. 中国海岛志-第2册-浙江卷, 舟山群岛南部[M]. 北京: 海洋出版社. (in Chinese)
[17]	许浩恩, 陈海燕, 赵璐, 2009. 浙江影响热带气旋的几个统计特征[J]. 浙江气象, 30(2): 4-8, 21. (in Chinese)
[18]	曾春华, 朱士兵, 李志强, 等, 2020. 基于高频观测数据的徐闻青安湾海滩对台风“贝碧嘉”的响应研究[J]. 海洋学报, 42(11): 100-111.
	ZENG CHUNHUA, ZHU SHIBING, LI ZHIQIANG, et al, 2020. Response of the Qing’an Bay beach in Xuwen to Typhoon Bebinca based on high frequency observation data[J]. Haiyang Xuebao, 42(11): 100-111. (in Chinese with English abstract)
[19]	张国栋, 王益友, 朱静昌, 等, 1987. 现代滨岸风暴沉积——以舟山普陀岛、朱家法岛为例[J]. 沉积学报, 5(2): 17-28.
	ZHANG GUODONG, WANG YIYOU, ZHU JINGCHANG, et al, 1987. Modern coastal storm deposits of Putuo Island and Zhujiajian Island, Zhoushan[J]. Acta Sedimentologica Sinica, 5(2): 17-28. (in Chinese with English abstract)
[20]	朱士兵, 李志强, 2019. 雷州半岛南部海滩对1720号台风(卡努)的响应研究[J]. 热带海洋学报, 38(1): 96-104.
	ZHU SHIBING, LI ZHIQIANG, 2019. Study on beach response to Typhoon Khanun (NO. 1720) along southern Leizhou Peninsula[J]. Journal of Tropical Oceanography, 38(1): 96-104. (in Chinese with English abstract)
[21]	庄振业, 王永红, 包敏, 等, 2009. 海滩养护过程和工程技术[J]. 中国海洋大学学报(自然科学版), 39(5): 1019-1024.
	ZHUANG ZHENYE, WANG YONGHONG, BAO MIN, et al, 2009. Beach nourishment process and engineering technology[J]. Periodical of Ocean University of China, 39(5): 1019-1024. (in Chinese with English abstract)
[22]	ANTHONY E J, 2013. Storms, shoreface morphodynamics, sand supply, and the accretion and erosion of coastal dune barriers in the southern North Sea[J]. Geomorphology, 199: 8-21. doi: 10.1016/j.geomorph.2012.06.007
[23]	BENN D I, BALLANTYNE C K, 1993. The description and representation of particle shape[J]. Earth Surface Processes and Landforms, 18(7): 665-672. doi: 10.1002/esp.3290180709
[24]	BURVINGT O, MASSELINK G, SCOTT T, et al, 2018. Climate forcing of regionally-coherent extreme storm impact and recovery on embayed beaches[J]. Marine Geology, 401: 112-128. doi: 10.1016/j.margeo.2018.04.004
[25]	CAI FENG, DEAN R G, LIU JIANHUI, 2011. Beach nourishment in China: Status and prospects[C]// Coastal Engineering Proceedings, Shanghai.
[26]	CARVER R E, 1971. Procedures in sedimentary petrology[M]. New York: Wiley-Interscience.
[27]	CASTELLE B, MARIEU V, BUJAN S, et al, 2015. Impact of the winter 2013-2014 series of severe Western Europe storms on a double-barred sandy coast: Beach and dune erosion and megacusp embayments[J]. Geomorphology, 238: 135-148. doi: 10.1016/j.geomorph.2015.03.006
[28]	CASTELLE B, TURNER I L, BERTIN X, et al, 2009. Beach nourishments at Coolangatta Bay over the period 1987-2005: Impacts and lessons[J]. Coastal Engineering, 56(9): 940-950. doi: 10.1016/j.coastaleng.2009.05.005
[29]	COOPER J A G, MCKENNA J, 2008. Social justice in coastal erosion management: The temporal and spatial dimensions[J]. Geoforum, 39(1): 294-306. doi: 10.1016/j.geoforum.2007.06.007
[30]	COSTAS S, ALEJO I, VILA-CONCEJO A, et al, 2005. Persistence of storm-induced morphology on a modal low-energy beach: A case study from NW-Iberian Peninsula[J]. Marine Geology, 224(1-4): 43-56. doi: 10.1016/j.margeo.2005.08.003
[31]	DAI ZHIJUN, DU JINZHOU, LI CHUNCHU, et al, 2007. The configuration of equilibrium beach profile in South China[J]. Geomorphology, 86(3-4): 441-454. doi: 10.1016/j.geomorph.2006.09.016
[32]	DOBKINS J E, FOLK R L, 1970. Shape development on Tahiti-Nui[J]. Journal of Sedimentary Petrology, 40(4): 1167-1203.
[33]	FOLK R L, WARD W C, 1957. Brazos River bar [Texas]: A study in the significance of grain size parameters[J]. Journal of Sedimentary Research, 27(1): 3-26. doi: 10.1306/74D70646-2B21-11D7-8648000102C1865D
[34]	GE ZHENPENG, DAI ZHIJUN, PANG WENHONG, et al, 2017. LIDAR-based detection of the post-typhoon recovery of a meso-macro-tidal beach in the Beibu Gulf, China[J]. Marine Geology, 391: 127-143. doi: 10.1016/j.margeo.2017.08.008
[35]	GUO JUNLI, SHI LIANGQIANG, PAN SHUNQI, et al, 2020. Monitoring and evaluation of sand nourishments on an embayed beach exposed to frequent storms in eastern China[J]. Ocean and Coastal Management, 195: 105284. doi: 10.1016/j.ocecoaman.2020.105284
[36]	HAERENS P, BOLLE A, TROUW K, et al, 2012. Definition of storm thresholds for significant morphological change of the sandy beaches along the Belgian coastline[J]. Geomorphology, 143-144: 104-117. doi: 10.1016/j.geomorph.2011.09.015
[37]	HAMM L, CAPOBIANCO M, DETTE H H, et al, 2002. A summary of European experience with shore nourishment[J]. Coastal Engineering, 47(2): 237-264. doi: 10.1016/S0378-3839(02)00127-8
[38]	HANSON H, BRAMPTON A, CAPOBIANCO M, et al, 2002. Beach nourishment projects, practices, and objectives—a European overview[J]. Coastal Engineering, 47(2): 81-111. doi: 10.1016/S0378-3839(02)00122-9
[39]	HARLEY M D, ANDRIOLO U, ARMAROLI C, et al, 2014. Shoreline rotation and response to nourishment of a gravel embayed beach using a low-cost video monitoring technique: San Michele-Sassi Neri, Central Italy[J]. Journal of Coastal Conservation, 18(5): 551-565. doi: 10.1007/s11852-013-0292-x
[40]	KOMAR P D, 1976. Beach processes and sedimentation[M]. Englewood Cliffs: Prentice-Hall.
[41]	KUANG CUIPING, MAO XIAODAN, GU JIE, et al, 2019. Morphological processes of two artificial submerged shore-parallel sandbars for beach nourishment in a nearshore zone[J]. Ocean and Coastal Management, 179: 104870. doi: 10.1016/j.ocecoaman.2019.104870
[42]	LOUREIRO C, FERREIRA Ó, COOPER J A G, 2012. Geologically constrained morphological variability and boundary effects on embayed beaches[J]. Marine Geology, 329-331: 1-15. doi: 10.1016/j.margeo.2012.09.010
[43]	LUO SHILONG, LIU YUHENG, JIN RUIFANG, et al, 2016. A guide to coastal management: Benefits and lessons learned of beach nourishment practices in China over the past two decades[J]. Ocean and Coastal Management, 134: 207-215. doi: 10.1016/j.ocecoaman.2016.10.011
[44]	MASSELINK G, SCOTT T, POATE T, et al, 2016. The extreme 2013/2014 winter storms: hydrodynamic forcing and coastal response along the southwest coast of England[J]. Earth Surface Processes and Landforms, 41(3): 378-391. doi: 10.1002/esp.3836
[45]	PETERSON C H, BISHOP M J, JOHNSON G A, et al, 2006. Exploiting beach filling as an unaffordable experiment: Benthic intertidal impacts propagating upwards to shorebirds[J]. Journal of Experimental Marine Biology and Ecology, 338(2): 205-221. doi: 10.1016/j.jembe.2006.06.021
[46]	POWERS M C, 1953. A new roundness scale for sedimentary particles[J]. Journal of Sedimentary Petrology, 23(2): 117-119.
[47]	PRODGER S, RUSSELL P, DAVIDSON M, et al, 2016. Understanding and predicting the temporal variability of sediment grain size characteristics on high-energy beaches[J]. Marine Geology, 376: 109-117. doi: 10.1016/j.margeo.2016.04.003
[48]	QI HONGSHUAI, CAI FENG, LEI GANG, et al, 2010. The response of three main beach types to tropical storms in South China[J]. Marine Geology, 275(1-4): 244-254. doi: 10.1016/j.margeo.2010.06.005
[49]	SEYMOUR R, GUZA R T, O’REILLY W, et al, 2005. Rapid erosion of a small southern California beach fill[J]. Coastal Engineering, 52(2): 151-158. doi: 10.1016/j.coastaleng.2004.10.003
[50]	SNEED E D, FOLK R L, 1958. Pebbles in the lower Colorado River, Texas a study in particle morphogenesis[J]. The Journal of Geology, 66(2): 114-150. doi: 10.1086/626490

台风名称	最强等级	生成时间	消亡时间	影响研究区域的时间范围
丹娜丝(Danas)	强热带风暴	7月15日17时	7月21日20时	7月19日7时—7月19日17时
利奇马(Lekima)	超强台风	8月4日14时	8月13日11时	8月9日16时—8月10日1时
玲玲(Lingling)	超强台风	9月1日20时	9月8日10时	9月6日13时—9月6日17时
塔巴(Tapah)	台风	9月18日23时	9月23日8时	9月21日11时—9月22日5时

剖面		单宽体积变化量/(m³·m^-1)
剖面		台风季节前期	台风季节后期	整个台风季节
大沙里	YA02	-10.72	27.29	16.58
	YA04	2.67	8.39	11.06
	YA06	30.98	13.30	44.28
	YA08	2.26	11.55	13.81
	YA10	-2.32	-23.79	-26.10
	平均值	4.57	7.35	11.93
东沙	DS05	3.49	-57.03	-53.54
	DS11	-77.77	-46.40	-124.17
	DS17	-80.73	-2.65	-83.39
	DS22	-9.22	-32.45	-41.67
	DS26	-1.67	-5.66	-7.33
	DS30	-9.03	-6.95	-15.97
	平均值	-35.68	-18.82	-54.51
千沙	QS01	5.40	-13.97	-8.57
	QS05	18.82	-41.74	-22.92
	QS09	27.22	-9.72	-9.72
	QS13	-43.02	-66.08	-10.91
	QS17	-4.91	-41.73	-46.63
	平均值	0.70	-34.65	-19.75

剖面		单宽体积变化量/(m³·m^-1)
剖面		台风季节前期	台风季节后期	整个台风季节
乌石塘	WST01	2.67	-0.07	2.59
	WST02	5.31	-3.63	1.68
	WST03	4.88	0.16	5.04
	WST04	2.32	-2.90	-0.58
	平均值	3.80	-1.61	2.18
小乌石塘	XWST01	1.80	1.16	2.96
	XWST02	0.21	-6.47	-6.27
	XWST03	6.05	0.28	6.33
	XWST04	2.57	-13.42	-10.85
	平均值	2.66	-4.61	-1.96

剖面		2019年7月18日			2019年8月31日			2019年9月24日
剖面		MPS	OPI	DRI	MPS	OPI	DRI	MPS	OPI	DRI
乌石塘	WST01	0.26	-1.94	0.46	0.20	-2.90	0.41	0.23	-2.22	0.42
	WST02	0.23	-2.31	0.42	0.20	-2.87	0.39	0.24	-2.04	0.42
	WST03	0.25	-1.34	0.46	0.23	-2.28	0.41	0.26	-2.47	0.40
	WST04	0.30	-1.89	0.43	0.22	-1.84	0.44	0.22	-2.08	0.43
	平均值	0.26	-1.87	0.44	0.21	-2.47	0.41	0.23	-2.20	0.42
小乌石塘	XWST01	0.23	-2.43	0.41	0.23	-0.12	0.50	0.22	-1.82	0.44
	XWST02	0.29	-0.71	0.47	0.27	-0.74	0.48	0.31	-1.09	0.46
	XWST03	0.28	-1.74	0.43	0.27	-0.59	0.47	0.34	-0.37	0.48
	XWST04	0.37	-0.03	0.51	0.21	-2.07	0.43	0.33	0.06	0.51
	平均值	0.29	-1.23	0.46	0.25	-0.88	0.47	0.30	-0.80	0.47

海滩	样方位置	2019年7月18日			2019年8月31			2019年9月24日
海滩	样方位置	MPS	OPI	DRI	MPS	OPI	DRI	MPS	OPI	DRI
乌石塘	剖面起点	0.25	-1.82	0.45	0.21	-2.87	0.41	0.22	-2.59	0.40
	砾石堤顶	0.26	-2.90	0.40	0.22	-2.21	0.42	0.24	-2.12	0.42
	潮间带	0.28	-0.89	0.47	0.21	-2.33	0.42	0.25	-1.90	0.43
小乌石塘	剖面起点	0.28	-1.61	0.44	0.25	-0.65	0.48	0.30	-1.07	0.47
	砾石堤顶	0.28	-1.61	0.44	0.22	-0.58	0.48	0.28	-1.10	0.46
	潮间带	0.33	-0.46	0.49	0.26	-1.41	0.45	0.33	-0.24	0.50
