人工生态礁体群对非平整岛礁孤立波水动力特性影响的试验研究

doi:10.11978/2024101

Abstract

Abstract:

The special geomorphological structure of coral reefs causes most of the incident waves to break at the reef edge, thus effectively reducing the intensity of waves on the reef apron and protecting the coastal area. However, the increasing human activities on the reefs, such as coral sand blowing and shore defense construction, not only threaten the fragile ecosystems of the reefs, but also significantly affect the complex wave evolution characteristics of the reefs. Nowadays, the construction of islands and reefs is facing the dual needs of promoting the ecological restoration of islands and reefs and improving the characteristics of wave protection and resistance of islands and reefs. Based on a physical model test, this paper systematically investigates the evolution of solitary wave hydrodynamic characteristics of island reefs with the existence of artificial ecological reef groups and analyzes the influence of wave height, water depth, reef body opening diameter and other factors. The experimental results show that the existence of artificial ecological reefs will have a significant impact on the propagation and evolution characteristics of island-type solitary waves. There is a complex interaction between the incident wave and the artificial reef, and the presence of the reef enhances the reflective strength of the incident wave. In addition, the complex vortex field inside the artificial reef body will consume more incident wave energy, resulting in a lower transmission coefficient of the incident wave on the reef pads, which better protects the coast.

Key words: artificial ecological reef complex, coral reefs, uneven reefs, solitary waves, wave reflection

CLC Number:

P731.22

WANG Chao, QU Ke, WANG Xu, GAO Rongze, WANG Aoyu. Influences of artificial fish reef on wave hydrodynamics of solitary wave on an uneven fringing reef[J].Journal of Tropical Oceanography, 2025, 44(2): 30-38.

Figures/Tables 12

Fig. 1

Tab. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Fig. 6

Fig. 7

Fig. 8

Fig. 9

Fig. 10

Fig. 11

References 23

[1]	李俊杰, 屈科, 王旭, 2023. 采掘坑对孤立波岸礁水动力特性影响的三维数值模拟研究[J]. 热带海洋学报, 42(6): 42-51.
	LI JUNJIE, QU KE, WANG XU, 2023. Three-dimensional numerical simulation of the influence of excavation pit on the hydrodynamic characteristics of solitary wave on fringing reef[J]. Journal of Tropical Oceanography, 42(6): 42-51 (in Chinese with English abstract).
[2]	龙丽娟, 杨芳芳, 韦章良, 2019. 珊瑚礁生态系统修复研究进展[J]. 热带海洋学报, 38(6): 1-8. doi: 10.11978/2019066
	LONG LIJUAN, YANG FANGFANG, WEI ZHANGLIANG, 2019. A review on ecological restoration techniques of coral reefs[J]. Journal of Tropical Oceanography, 38(6): 1-8 (in Chinese with English abstract). doi: 10.11978/2019066
[3]	梅弢, 高峰, 2013. 波浪在珊瑚礁坪上传播的水槽试验研究[J]. 水道港口, 34(1): 13-18.
	MEI TAO, GAO FENG, 2013. Flume experiment research on law of wave propagation in reef flat[J]. Journal of Waterway and Harbor, 34(1): 13-18 (in Chinese with English abstract).
[4]	CASTRO-SANGUINO C, BOZEC Y M, CALLAGHAN D, et al, 2022. Coral composition and bottom-wave metrics improve understanding of the patchiness of cyclone damage on reefs[J]. Science of the Total Environment, 804: 150178.
[5]	FANG KEZHAO, XIAO LI, LIU ZHONGBO, et al, 2022. Experiment and RANS modeling of solitary wave impact on a vertical wall mounted on a reef flat[J]. Ocean Engineering, 244: 110384.
[6]	GOURLAY M R, 1996. Wave set-up on coral reefs. 1. Set-up and wave-generated flow on an idealised two dimensional horizontal reef[J]. Coastal Engineering, 27(3-4): 161-193.
[7]	GRADY A E, MOORE L J, STORLAZZI C D, et al, 2013. The influence of sea level rise and changes in fringing reef morphology on gradients in alongshore sediment transport[J]. Geophysical Research Letters, 40(12): 3096-3101.
[8]	HUANG JIANJUN, LOWE R J, GHISALBERTI M, et al, 2024. Wave transformation across impermeable and porous artificial reefs[J]. Coastal Engineering, 189: 104488.
[9]	KELLER K, SMITH J A, LOWRY M B, et al, 2017. Multispecies presence and connectivity around a designed artificial reef[J]. Marine and Freshwater Research, 68(8): 1489-1500.
[10]	MADSEN P A, SCHÄFFER H A, 2010. Analytical solutions for tsunami runup on a plane beach: single waves, N -waves and transient waves[J]. Journal of Fluid Mechanics, 645: 27-57.
[11]	MAHMOUDI KURDISTANI S, ARISTODEMO F, FRANCONE A, et al, 2021. Formula for the maximum reference pressure at the interface of the breakwater core and filter layer[J]. Coastal Engineering journal, 63(4): 532-544.
[12]	MORI N, TAKAHASHI T, THE 2011 TOHOKU EARTHQUAKE TSUNAMI JOINT SURVEY GROUP, 2012. Nationwide post event survey and analysis of the 2011 Tohoku earthquake tsunami[J]. Coastal Engineering Journal, 54(1): 1250001.
[13]	NING YUE, LIU WEIJIE, SUN ZHILIN, et al, 2019. Parametric study of solitary wave propagation and runup over fringing reefs based on a Boussinesq wave model[J]. Journal of Marine Science and Technology, 24(2): 512-525.
[14]	QU KE, LIU TIEWEI, CHEN LONG, et al, 2022. Study on transformation and runup processes of tsunami-like wave over permeable fringing reef using a nonhydrostatic numerical wave model[J]. Ocean Engineering, 243: 110228.
[15]	QU KE, SUN W Y, TANG HANSONG, et al, 2019. Numerical study on hydrodynamic load of real-world tsunami wave at highway bridge deck using a coupled modeling system[J]. Ocean Engineering, 192: 106486.
[16]	QUIROGA P D, CHEUNG K F, 2013. Laboratory study of solitary-wave transformation over bed-form roughness on fringing reefs[J]. Coastal engineering, 80: 35-48.
[17]	SILVA R, MENDOZA E, MARIÑO-TAPIA I, et al, 2016. An artificial reef improves coastal protection and provides a base for coral recovery[J]. Journal of Coastal Research, 75(S1): 467-471.
[18]	SYNOLAKIS C E, BERNARD E N, 2006. Tsunami science before and beyond Boxing Day 2004[J]. Philosophical Transactions of the Royal Society A: Mathematical, Physical and Engineering Sciences, 364(1845): 2231-2265.
[19]	TITOV V, RABINOVICH A B, MOFJELD H O, et al, 2005. The global reach of the 26 December 2004 Sumatra tsunami[J]. Science, 309(5743): 2045-2048. pmid: 16123264
[20]	WANG XU, QU KE, MEN JIA, et al, 2023. Influence of excavation pits on the wave hydrodynamics of fringing reefs under regular waves[J]. Journal of Marine Science and Engineering, 11(7): 1464.
[21]	YAO YU, HUANG ZHENHUA, HE WENRUN, et al, 2018a. Wave-induced setup and wave-driven current over Quasi-2DH reef-lagoon-channel systems[J]. Coastal Engineering, 138: 113-125.
[22]	YAO YU, HE FANG, TANG ZHENGJIANG, et al, 2018b. A study of tsunami-like solitary wave transformation and run-up over fringing reefs[J]. Ocean Engineering, 149: 142-155.
[23]	ZHU GANCHENG, REN BING, WEN HONGJIE, et al, 2019. Analytical and experimental study of wave setup over permeable coral reef[J]. Applied Ocean Research, 90: 101859.

工况编号	入射波高/m	礁坪水深/m	壁面开孔率	布置排数	工况编号	入射波高/m	礁坪水深/m	壁面开孔率	布置排数
A1	0.02	0.050	\	\	C5	0.10	0.050	0.2	6
A2	0.04	0.050	\	\	D1	0.06	0	0.2	6
A3	0.06	0.050	\	\	D2	0.06	0.025	0.2	6
A4	0.08	0.050	\	\	D3	0.06	0.075	0.2	6
A5	0.10	0.050	\	\	E1	0.06	0.050	0.1	6
B1	0.06	0	\	\	E2	0.06	0.050	0.3	6
B2	0.06	0.025	\	\	F1	0.06	0.050	0.2	1
B3	0.06	0.075	\	\	F2	0.06	0.050	0.2	2
C1	0.02	0.050	0.2	6	F3	0.06	0.050	0.2	3
C2	0.04	0.050	0.2	6	F4	0.06	0.050	0.2	4
C3	0.06	0.050	0.2	6	F5	0.06	0.050	0.2	5
C4	0.08	0.050	0.2	6
