卷积神经网络在近岸表层海温预报中的应用

doi:10.11978/2023037

Abstract

Abstract:

Concerning the low sea surface temperature (SST) prediction accuracy of numerical modeling and empirical methods in near-shore stations, we consider sea surface temperature prediction as forecasting of multivariate time series data, construct the sea surface temperature time series model of near-shore stations by convolutional neural network (CNN) to predict the maximum, minimum and mean sea surface temperature for the next day, and compare CNN model with empirical forecast method and long short-term memory (LSTM) model through experiment. The experimental results show that compared with empirical forecast method, the mean absolute error (MSE) of CNN model on daily maximum SST forecast drops 0.14℃ to 0.36℃, root mean squared error (RMSE) drops 0.21℃ to 0.49℃, the MSE of CNN model on daily minimum SST forecast drops 0.17℃ to 0.36℃, RMSE drops 0.24℃ to 0.63℃, the MSE of CNN model on daily mean SST forecast is 0.30℃, RMSE is 0.47℃, its forecast performance is as good as LSTM model in the testing set. It shows that the application of CNN to SST modeling is feasible, improve the accuracy of sea surface temperature prediction which can compare favorably with LSTM model.

Key words: sea surface temperature, near-shore stations, multivariate time series, CNN

WENG Shaojia, CAI Jinhai, PANG Yunxi, LUO Rongzhen. Application of convolutional neural network to sea surface temperature prediction in the coastal waters[J].Journal of Tropical Oceanography, 2024, 43(1): 40-47.

Figures/Tables 6

Fig. 1

Fig. 2

Fig. 3

Fig. 4

Fig. 5

Tab.1

References 20

[1]	匡晓迪, 王兆毅, 张苗茵, 等, 2016. 基于BP神经网络方法的近岸数值海温预报释用技术[J]. 海洋与湖沼, 47(6): 1107-1115.
	KUANG XIAODI, WANG ZHAOYI, ZHANG MIAOYIN, et al, 2016. An interpretation scheme of numerical near-shore sea-water temperature forecast based on BPNN[J]. Oceanologia et Limnologia Sinica, 47(6): 1107-1115 (in Chinese with English abstract).
[2]	李燕, 张建华, 刘钦政, 等, 2007. 单站海温短期预报自动化[J]. 海洋预报, 2007, 24(4): 33-41.
	LI YAN, ZHANG JIANHUA, LIU QINZHENG, et al, 2007. The automation of single sea station's surface sea temperature short term forecasting[J]. Marine Forecasts, 24(4): 33-41 (in Chinese with English abstract).
[3]	王兆毅, 李云, 王旭, 2020. 中国近岸海域基础预报单元海温预报指导产品研制[J]. 海洋预报, 37(4): 59-65.
	WANG ZHAOYI, LI YUN, WANG XU, 2020. Development of forecast guidance product for sea temperature of basic forecast units in the Chinese coastal waters[J]. Marine Forecasts, 37(4): 59-65 (in Chinese with English abstract).
[4]	许金电, 蔡尚湛, 宣莉莉, 等, 2014. 粤东至闽南沿岸海域夏季上升流的调查研究[J]. 热带海洋学报, 33(2): 1-9. doi: 10.11978/j.issn.1009-5470.2014.02.001
	XU JINDIAN, CAI SHANGZHAN, XUAN LILI, et al, 2014. Observational study on summertime upwelling in coastal seas between eastern Guangdong and southern Fujian[J]. Journal of Tropical Oceanography, 33(2): 1-9 (in Chinese with English abstract).
[5]	张建华, 2003. 海温预报知识讲座第一讲: 海水温度预报概况[J]. 海洋预报, 20(4): 81-85 (in Chinese).
[6]	张建华, 2004. 海温预报知识讲座第二讲: 数理统计方法在海温预报中的应用[J]. 海洋预报, 21(1): 85-90.
	ZHANG JIANHUA, 2004. Lecture on sea surface temperature prediction: lecture 2 application of mathematical Statistics method in sea surface temperature prediction[J]. Marine Forecasts, 21(1): 85-90 (in Chinese with English abstract).
[7]	张雪薇, 韩震, 2022. 基于ConvGRU深度学习网络模型的海表面温度预测[J]. 大连海洋大学学报, 37(3): 531-538.
	ZHANG XUEWEI, HAN ZHEN, 2022. Prediction of sea surface temperature based on ConvGRU deep learning network model[J]. Journal of Dalian Ocean University, 37(3): 531-538 (in Chinese with English abstract).
[8]	张云翼, 江毓武, 2012. 汕尾外侧冷水跨陆架输送的形成机制[J]. 厦门大学学报(自然科学版), 51(4): 746-752.
	ZHANG YUNYI, JIANG YUWU, 2012. The Mechanism of cold water cross-shelf transport in the continental shelf off Shanwei[J]. Journal of Xiamen University (Natural Science), 51(4): 746-752 (in Chinese with English abstract).
[9]	郑泽宇, 梁博文, 2017. TensorFlow: 实战Google深度学习框架[M]. 北京: 电子工业出版社: 6-9 (in Chinese).
[10]	朱贵重, 胡松, 2019. 基于LSTM-RNN的海水表面温度模型研究[J]. 应用海洋学学报, 38(2): 191-197.
	ZHU GUICHONG, HU SONG, 2019. Study on sea surface temperature model based on LSTM-RNN[J]. Journal of Applied Oceanography, 38(2): 191-197 (in Chinese with English abstract).
[11]	庄桦, 2014. 沿岸海域海温研究进展[J]. 中国水运, 14(2): 194-195 (in Chinese).
[12]	BAI SHAOJIE, KOLTER J Z, KOLTUN V, (2018-04-19) [2023-05-30]. An empirical evaluation of generic convolutional and recurrent networks for sequence modeling[EB/OL]. https://arxiv.org/abs/1803.01271v2
[13]	FAWAZ H I, FORESTIER G, WEBER J, et al, 2019. Deep learning for time series classification: a review[J]. Data mining and knowledge discovery, 33: 917-963. doi: 10.1007/s10618-019-00619-1
[14]	HINTON G, DENG LI, YU DONG, et al, 2012. Deep neural networks for acoustic modeling in speech recognition: the shared views of four research groups[J]. IEEE Signal Processing Magazine, 29(6): 82-97.
[15]	SHELHAMER E, LONG J, DARRELL T, 2017. Fully convolutional networks for semantic segmentation[J]. IEEE Transactions on Pattern Analysis and Machine Intelligence, 39(4): 640-651. doi: 10.1109/TPAMI.2016.2572683 pmid: 27244717
[16]	RAWAT W, WANG ZENGHUI, 2017. Deep convolutional neural networks for image classification: a comprehensive review[J]. Neural Computation, 29(9): 2352-2449. doi: 10.1162/NECO_a_00990 pmid: 28599112
[17]	SHIH SHUNYAO, SUN FANKENG, LEE H Y, 2019. Temporal pattern attention for multivariate time series forecasting[J]. Machine Learning, 108: 1421-1441. doi: 10.1007/s10994-019-05815-0
[18]	SUTSKEVER I, VINYALS O, LE Q V, 2014. Sequence to sequence learning with neural networks[C]// Proceedings of the conference on advances in neural information processing systems, 2: 3104-3112.
[19]	YAO GUANGLE, LEI TAO, ZHONG JIANDAN, 2019. A review of Convolutional-Neural-Network-based action recognition[J]. Pattern Recognition Letters, 118(2): 14-22. doi: 10.1016/j.patrec.2018.05.018
[20]	ZHENG GANG, LI XIAOFENG, ZHANG RONGHUA, et al, 2020. Purely satellite data-driven deep learning forecast of complicated tropical instability waves[J]. Science Advances, 6(29): eaba1482. doi: 10.1126/sciadv.aba1482

月份	日最高SST/ ℃						日最低SST/ ℃						日平均SST/ ℃
	CNN预报		LSTM预报		人工经验预报		CNN预报		LSTM预报		人工经验预报		CNN预报		LSTM预报
	MAE	RMSE	MAE	RMSE	MAE	RMSE	MAE	RMSE	MAE	RMSE	MAE	RMSE	MAE	RMSE	MAE	RMSE
1月	0.21	0.28	0.22	0.30	0.24	0.31	0.17	0.23	0.15	0.21	0.30	0.37	0.14	0.22	0.11	0.19
2月	0.31	0.51	0.30	0.50	0.36	0.59	0.19	0.26	0.17	0.25	0.29	0.37	0.18	0.24	0.15	0.21
3月	0.35	0.44	0.40	0.53	0.40	0.53	0.18	0.25	0.17	0.24	0.29	0.37	0.18	0.25	0.19	0.28
4月	0.35	0.45	0.33	0.43	0.40	0.57	0.27	0.38	0.26	0.36	0.31	0.46	0.26	0.37	0.27	0.38
5月	0.48	0.60	0.50	0.63	0.53	0.64	0.39	0.50	0.42	0.52	0.47	0.65	0.39	0.49	0.33	0.46
6月	0.54	0.67	0.49	0.62	0.91	1.15	0.79	1.13	0.74	1.15	1.28	1.78	0.54	0.74	0.54	0.71
7月	0.63	0.80	0.61	0.76	0.88	1.06	1.12	1.45	1.05	1.41	1.36	1.75	0.78	0.97	0.77	0.92
8月	0.41	0.52	0.41	0.51	0.68	0.83	0.45	0.72	0.44	0.71	0.62	0.85	0.32	0.41	0.34	0.44
9月	0.33	0.48	0.38	0.51	0.53	0.78	0.33	0.47	0.37	0.51	0.48	0.72	0.32	0.44	0.30	0.46
10月	0.22	0.29	0.21	0.26	0.46	0.56	0.08	0.13	0.10	0.15	0.20	0.30	0.12	0.16	0.18	0.22
11月	0.24	0.30	0.26	0.31	0.34	0.45	0.14	0.19	0.14	0.19	0.35	0.56	0.15	0.20	0.17	0.24
12月	0.19	0.23	0.20	0.26	0.30	0.40	0.21	0.29	0.24	0.33	0.38	0.46	0.17	0.25	0.18	0.24
全年	0.36	0.49	0.36	0.49	0.50	0.70	0.36	0.63	0.36	0.63	0.53	0.87	0.30	0.47	0.30	0.45
